ZooZ ZSE41 800LR User Manual

USER MANUAL
OPEN | CLOSE XS SENSOR
ZSE41 800LR
www.getzooz.com
FEATURES
Quick and reliable open/close
Ÿ
alerts sent to your Z-Wave® hub
NEW 800 series chip for faster
Ÿ
communication and more
battery life than ever
Extra small for discreet mounting
Ÿ
Waterproof case available for
Ÿ
outdoor installs (sold separately)
Z-Wave® Long Range for ultra
Ÿ
reliable no-mesh communication
S2 security and SmartStart
Ÿ
Supports OTA firmware updates
Ÿ
SPECIFICATIONS
Model Number: Z
Ÿ
Power: 1 x CR2032 battery
Ÿ
Operating Temperature: 32° –
Ÿ
104° F
Dimensions: 1.9" x 1" x 0.3"
Ÿ
(magnet: 1.26" x 0.3" x 0.3")
Range: Up to 130 feet line of sight
Ÿ
(up to 1 mile with Long Range)
Installation and Use: Indoor or
Ÿ
outdoor with waterproof case
(sold separately)
INSTALLATION
1. POWER THE SENSOR
Use the included triangle
tool to gently open the
sensor's cover and access
the battery.
Pull the tab from under the
battery to activate the sensor.
Don't close the cover just yet.
The LED indicator will start blinking
for around 10 seconds once the
sensor is powered.
The LED indicator doesn't blink
or light up at all?
Make sure the battery is
Ÿ
inserted correctly per the
positive / negative pole marks.
Try a fresh lithium non-
Ÿ
rechargeable battery.
Click the Z-Wave® button 3
Ÿ
times as quickly as possible to
force inclusion/exclusion
mode in case you missed
when it first flashed.
LED INDICATOR
Z-WAVE®
BUTTON
3 x CLICK
TO PAIR
Z-WAVE® CONTROL
1. ADD DEVICE to your hub
Initiate inclusion (pairing) in the
app (or web interface). Not sure
how? ask@getzooz.com
If you're using an S2 hub, it will ask
you to enter the DSK PIN or scan
the QR code printed on the inside
of the back cover of the sensor to
complete SmartStart inclusion.
2. ACTIVATE the sensor
While the hub is looking for new
devices, click the Z-Wave®
button 3 times as quickly as
possible. The LED indicator will
start flashing to confirm inclusion
mode and turn off once inclusion
is completed.
It's best to add your sensor from
the area where it will be installed
so the hub can find the best route
to reach it right away.
Firmware 2.0
SE41 800LR
TIP!
PAGE 1
SmartStart enabled products can be added
into a Z-Wave® network by scanning the
Z-Wave® QR Code present on the product
with a controller providing SmartStart
inclusion. No further action is required and
the SmartStart product will be added
automatically within 10 minutes of being
switched on in the network vicinity.
Choose your hub and scan the QR
code with your phone's camera.
Then click on the link to access the
step-by-step pairing instructions.
S2
SmartThings
Home Assistant
TROUBLESHOOTING
The sensor won't add to your
system? Try this:
1. Initiate EXCLUSION in your hub
and click the Z-Wave® button 3
times as quickly as possible.
2. Click the Z-Wave® button quicker
when adding it.
3. Bring the sensor closer to your
hub, it may be out of range.
4. Double-check if the device is
powered.
5. Get troubleshooting tips specific
to your hub at
www.support.getzooz.com
EXCLUSION (REMOVE DEVICE)
1. Bring the sensor within direct
range of your Z-Wave® hub.
2. Put the Z-Wave® hub into
exclusion mode (not sure how to
do that? ask@getzooz.com).
3. Click the Z-Wave® button 3
times as quickly as possible.
4. Your hub will confirm exclusion
and the sensor will disappear
from your controller's device list.
When your network's primary
controller is missing or otherwise
inoperable, you may need to reset
the device to factory settings
manually. In order to complete the
process, make sure the sensor is
powered, then click the Z-Wave®
button twice and hold it the third
time for 10 seconds. The LED
indicator will blink continuously.
Immediately a er, click the Z-
Wave button twice more to
finalize the reset. The LED
indicator will flash 3 times to
confirm a successful reset.
NOTE: All previously recorded activity and
custom settings will be erased from the
device's memory.
The sensor's wake-up interval is set
to 12 hours by default to save
battery life. Use the Wake Up
Command Class to adjust the
interval. Click the Z-Wave® button
4 times quickly to wake the
sensor up manually. The LED
indicator will flash once to confirm
the device is awake. During wake-
up, the sensor turns the Z-Wave®
radio on for one minute to receive
communication from the hub. Long
wake-up interval will not affect how
o en the sensor reports to your hub
so we recommend leaving the
default setting to conserve battery.
The XS Sensor supports Group 1 for
Lifeline communication and Group
2 with up to 5 devices for basic
on/off control. This device will send
a Basic Set command to Group 2
whenever it detects a change in the
open/close status. It sends an ON
command when OPEN status is
detected and OFF command when
CLOSED status it detected.
Please note that not all Z-Wave®
systems give users access to direct
association settings so if you're
note sure where to find it, please
get in touch with our support and
we'll be happy to help.
Z-Box Hub
FACTORY RESET
WAKE-UP MODE
ASSOCIATION
PAGE 2
Hubitat
