Global Industrial 800575 User Manual

Stock chaser with 4-step ladder, 24v
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's manual
Manual del usuario
Manuel de l'utilisateur
Customer Service
Servicio de atención al Cliente
Service à la clientèle
US: 1-800-645-2986
US: 1-800-645-2986
Canada: 888-645-2986
Global Industrial™ Stock Chaser with 4-Step Ladder, 24V
Model: 800575
Operator's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 800575 and is the answer not in the manual?

Questions and answers

Related Manuals for Global Industrial 800575

Summary of Contents for Global Industrial 800575

  • Page 1 User's manual Manual del usuario Manuel de l'utilisateur Customer Service Servicio de atención al Cliente Service à la clientèle US: 1-800-645-2986 US: 1-800-645-2986 Canada: 888-645-2986 Global Industrial™ Stock Chaser with 4-Step Ladder, 24V Model: 800575 Operator’s Manual...
  • Page 2 In case of any discrepancies, consider the actual vehicle as correct and use this manual for reference purposes only. Global Industrial is not liable for errors in this manual or any consequential damage that results from the use of this manual.

  • Page 3: Table Of Contents

    Stock Chaser TABLE OF CONTENTS 1. VEHICLE DESCRIPTION ..............................3 2. GENERAL SAFETY INFORMATION ..........................4 1.1. Safety Warning Labels ............................. 4 3. RECEIVING AND UNPACKING VEHICLE ........................6 4. VEHICLE QUICK SETUP ..............................7 5. VEHICLE SPECIFICATIONS ............................8 5.1.

  • Page 4: Vehicle Description

    Stock Chaser VEHICLE DESCRIPTION The stock chaser is operated by a single standing operator. It may be used to tow or transport suitable goods on its cargo deck. To ensure safe operation, it is imperative to adhere to the operating instructions and appropriate use cases.

  • Page 5: General Safety Information

    Stock Chaser GENERAL SAFETY INFORMATION Safety Warning Labels 1. Operating Instructions Label 2. Off-Road Use Only Label 3. Proper Training Label 4. Pinch Point Warning Label...
  • Page 6 Any unauthorized repairs, modifications, or adjustments could lead to unsafe conditions resulting in severe bodily injury and/or property damage. Any modifications must be approved by the manufacturer. Global Industrial is not responsible for any consequences resulting from unauthorized repairs, modifications, and adjustments.

  • Page 7: Receiving And Unpacking Vehicle

    With assistance, lift cargo deck off the vehicle. Take precaution on pinch points. Refer to “VEHICLE CONTROLS” part of the manual to learn more about vehicle controls before operating vehicle. Refer to QR code or link for model no. 800575 unpacking video and instructions: https://www.globalindustrial.com/p/stock-chaser-with-4-step-ladder-24v...

  • Page 8: Vehicle Quick Setup

    Examine the contents of all packages and accessories that may have come in separate packages along with the vehicle and ensure everything listed on the packing slip is there. Model no. 800575 includes an on-board charging cable. Refer to “Before Operating Vehicle” section of this manual to check that the vehicle is in correct operating condition.

  • Page 9: Vehicle Specifications

    Stock Chaser VEHICLE SPECIFICATIONS Model No. 800575 Passenger Capacity Rated Capacity 990 lbs Towing Capacity 4840 lbs Maximum Speed 7.5 mph Maximum Speed on Slow Mode 4.5 mph Turning Radius (Intersecting Aisle) 50.4" Horsepower 4.29 HP Ground Clearance 2.95” Range 12 miles Battery &...

  • Page 10: Data Name Plate

    Stock Chaser Data Name Plate Do not remove any name plate, warnings, or instructions affixed to your Global Industrial vehicle. Promptly replace any that become damaged or removed. Each vehicle is assigned with a unique serial number. The serial number can be found on the name plate located below the right side of the driver’s seat.

  • Page 11: Vehicle Controls

    Stock Chaser VEHICLE CONTROLS...
  • Page 12 Stock Chaser (1) Steering wheel controls the path of the vehicle and operates the same as a conventional automobile steering wheel. (2) Parking brake lever Pressing the button and pulling the lever away from the vehicle engages the parking brake. Pressing the button and pushing the lever towards the vehicle disengages the parking brake. Always apply parking brake before stepping away from the vehicle.
  • Page 13 Stock Chaser (7) Forward/neutral/reverse lever Use this lever to select the direction of travel. Operator must release the accelerator pedal before selecting a direction. In the “up” position, the vehicle direction is set to forward. In the “down” position, the vehicle direction is set to reverse. Return the FNR lever to its center neutral position when vehicle is not in use.

  • Page 14: Vehicle Operation

    Any unauthorized repairs, modifications, or adjustments could lead to unsafe conditions resulting in severe bodily injury and/or property damage. Any modifications must be approved by the manufacturer. Global Industrial is not responsible for any consequences resulting from unauthorized repairs, modifications, and adjustments.
  • Page 15 Stock Chaser Do not allow more passengers than the vehicle is designated for. Drive slowly when making a turn, especially on wet or inclined surfaces. Drive slowly up and down grades. Do not drive on steep hills or inclines. Do not drive on grades that exceed the vehicle’s gradeability. Do not park vehicle on incline/slope.

  • Page 16: Before Operating Vehicle

    Stock Chaser Before Operating Vehicle If any of the following items malfunction or do not work as expected, do not operate vehicle until problem has been corrected. Daily Pre-Operation Checklist Item No. Check content No loose hardware Body and chassis Body and seat are clean and free of damage.

  • Page 17: Operating Vehicle

    Stock Chaser Operating Vehicle 1. Stand on the stock chaser platform. Ensure that the accelerator-brake combination pedal is set to the brake setting (pressed at heel of foot). 2. Insert key, press on operator presence pedal, and turn key to “ON” position. 3.

  • Page 18: Batteries And Charging

    BATTERIES AND CHARGING Charging the Vehicle The Global Industrial stock chaser contains four, 6V deep cycle gel AGM batteries, which are virtually maintenance-free. It is recommended to fully charge the vehicle upon receipt. The charge time of the new batteries is approximately 10-12 hours.

  • Page 19: Charging Indication Lights

    Stock Chaser Charging Indication Lights The charging indication lights are located directly above the on-board charging port. LED Color Indication Flashing red Battery charging Green Fully charged Battery Maintenance Always power off vehicle by removing key and disconnecting batteries before servicing or repairing vehicle.

  • Page 20: Charger Troubleshooting

    Stock Chaser CHARGER TROUBLESHOOTING Charger Error Codes LED Color Indication Potential Cause / Solution Green, red Empty load Battery or charger connections are loose. The battery is reversed. The battery voltage is too low. Red, green, red, 3s pause Overvoltage/overcurrent Restart vehicle and if error light sustains, contact support.

  • Page 21: Maintenance And Repair

    Stock Chaser MAINTENANCE AND REPAIR The following maintenance procedures are based on cases where the warehouse personnel carrier is used 8 hours a day or 200 hours per month. Always power off vehicle by removing key and disconnecting batteries before servicing or repairing vehicle.

  • Page 22: Troubleshooting The Vehicle

    Stock Chaser • Tires are free of damage • No loose hardware Wheels/tires Check wear on tires and • bearings. Replace if necessary. • Replace tires • Replace wheel bearing Brake pedal has firm • pressure with minimal travel. Check brake clearance Ensure that the brace •...

  • Page 23: Vehicle Controls Wire Diagram

    Stock Chaser Vehicle Controls Wire Diagram Troubleshooting with Controller LED Indicators LED display code example 2.4: ☼☼ ☼☼☼☼ means that LED first blinks twice, then turns off, then blinks another four times. 1311 Display Fault Explanation Fault Cause Code 1. Vehicle operation fault creates high Restart vehicle by turning key current spikes switch to ‘OFF’...
  • Page 24 Stock Chaser 1. Operation sequence fault in interlock switch, direction, and key switch. 2. There is circuit broken in interlock Operation sequence switch or direction. Check the operation sequence. fault when starting 3. The delayed time of operation Check the accelerator adjustment the vehicle (SRO) sequence set before is too short.

  • Page 25: Storing The Vehicle

    Stock Chaser FIELD OPEN The connection of the 1. The connection of the field winding Check the connector and unlock field winding is open is an open circuit. the key switch. circuit. 2. The field winding is an open circuit. 1.
