Summary of Contents for Habitat Nomad
- Page 1 Nomad...
- Page 2 Regularly check and ensure that all bolts and fittings are tightend properly. This product is compliant BS4875-7 level 2, EN 14749 Habitat,Argos Limited Sainsbury's Supermarkets Ltd, London EC1N 2HT, UK. Argos (N.1.) Ltd and Sainsbury's (NI) Ltd. Forestside Shopping Centre, Upper Galwally, Belfast, BT8 6FX, UK...
- Page 3 Fittings (Shown to scale) Bag 1...
- Page 4 Hardware...
-
Page 5: Tools Required
Tools required Phillips screwdriver Ruler/tape (small & medium) measure Flat-head screwdriver Eye protection (small & medium) (when using a hammer or glue) Small hammer Large hammer Pencil Mallet Set Square Spirit Level... - Page 6 Panels Top (803 x 397mm) Right Side (950 x 391mm) Bottom (803 x 397mm) Left Side (950 x 391mm) Center (592 x 354mm) Middle (765 x 373mm) Upper Shelf (445 x 294mm) Upper Right Support (340 x 296mm) Shelf (374 x 353mm) Upper Shelf Support (340 x 296mm) Upper Back (765 x 340mm) Lower Back (765 x 340mm)
- Page 14 Finished Edge Product...
- Page 15 Hook Press Once inserted hook into plate then press down arrow point as shown to Insert the hinge complete the hinge fixing hook into the plate Press to clip If needed, rotating screw clockwise if it is hard to insert This step is only needed when you would disassemble the doors.
- Page 16 Hinges Adjustment A. Side to side adjustment by B. Up and down adjustment by C. Front to back adjustment by clockwise or anticlockwise adjusting mounting plate slot. rotating screw clockwise or anticlockwise. adjustment.
- Page 17 4 x 14.5mm Screw x 2 4 x 33mm Screw x 2 Wall Strap x 2 Wall Plug x 2 NOTE WARNING! IN ORDER TO PREVENT OVERTURNING THIS PRODUCT MUST BE USED WITH THE WALL ATTACHMENT DEVICE PROVIDED...
