Summary of Contents for Habitat Nel 2151885

  • Page 1 Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 19/04/22...
  • Page 2 Safety and Care Advice Product Details NEL TABLE 2151885 BLACK NEL TABLE 4543714 OAK IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Keep children and animals Assemble the item as close We do not to its final position(in the same away from the work area, small recommend the room) as possible.
  • Page 3 Fittings (Shown to scale) Bag 1 Ø10*15mm Nut x 8 M6*70mm Bolt x 8 M6*50mm Bolt x 16 Ø8*30mm Bolt x 8 Spring Washer x 24 Flat Washer x 24 Ø30mm Foot Pad x 4 M4 Alley Key x 1...
  • Page 4: Tools Required

    Tools required Phillips screwdriver (small & medium) Phillips screwdriver (small & medium)
  • Page 5 Panels Top Panel x2 (1900 x 424mm) Support Rail x2 (1620 x 70mm) Side Leg x 2 (850 x 732mm)
  • Page 6 Ø10*15mm Nut x 8 M6*70mm Bolt x 8 Spring Washer x 8 Flat Washer x 8 Ø8*30mm Bolt x 4 Warning! Please do not fully tighten the bolts in this step. Ø10*15mm Nut x 8 M6*70mm Bolt x 8 M6*40mm Bolt x 16 Ø8*30mm Bolt x 8 Spring Washer x 24 Flat Washer x 24...
  • Page 7 M6*50mm Bolt x 16 Ø8*30mm Bolt x 4 Spring Washer x 16 Flat Washer x 16...
  • Page 8 Ø30mm Foot Pad x 4 Peel off the back Fully tighten all the bolts. 100%...
  • Page 9 Rotate Product Assembly is complete.

This manual is also suitable for:

Nel 4543714
