Summary of Contents for Inter-m DSP-48

  • Page 1 Operation Manual Digital Speaker Processor DSP-48...
  • Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
  • Page 3: Table Of Contents

    ........................2 Installation Environment ........................2 Important Safety Instructions ....................2 Features ..........................3 Contents and Accessories ....................3 Front Panel ........................4 Rear Panel ........................7 Applications ........................9 Block Diagram .......................10 Specifications .........................12 Service Procedures ........................15 Schematic........................15 Parts List.........................15 Variations and Options ....................15 Warranty ........................15 DSP-48...
  • Page 4: Unpacking

    DIGITAL SPEAKER PROCESSOR Unpacking Unpacking Although your DSP-48 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation.
  • Page 5: Features

    - HIGH PERFORMANCE AUDIO INPUT AND OUTPUT The DSP-48 consists of 4 in, 8 out XLR balanced I/O, and offers high-performance audio with dynamic range of 108 dB or higher and frequency response characteristics with 24-bit 96 kHz sampling rate and 32-bit floating point DSP processing technology.
  • Page 6: Front Panel

    -48 dBFS Green 2. INPUT CHANNEL MUTE BUTTON AND STATUS LED Displays and controls the mute status by input channel. Status LED Color LED Light Mute Unmute 3. OLED DISPLAY Display DSP configuration information, product information, network information, etc. DSP-48...
  • Page 7 Set Limit value Orange LIMIT -6 dBFS Yellow -12 dBFS Yellow -24 dBFS Green -36 dBFS Green 6. OUTPUT MUTE BUTTON AND STATUS LED Displays and controls the mute status by output channel. Status LED Color LED Light Mute Unmute DSP-48...
  • Page 8 Displays the network status of the equipment. Status LED Color LED Light Ethernet OFF Green Ethernet ON Green Data communication Green Blink 8. POWER STATUS LED Displays the power status of the equipment. Status LED Color LED Light Power OFF Blue Power ON Blue DSP-48...
  • Page 9: Rear Panel

    This is the terminal that receives audio input. 5. NETWORK CONNECTION TERMINALS AND STATUS LEDS The terminal that connects the product's Ethernet network. <100 Base-T> <1G Base-T> PIN NO Function PIN NO Function LINK MX(0)+ MX(0)- MX(1)+ MX(2)+ MX(2)- MX(1)- MX(3)+ MX(3)- DSP-48...
  • Page 10 Data Communication Yellow Blink 6. CONTACT INPUT TERMINAL All audio outputs are muted when the contacts are switched on to the Dry Contact input terminal. Status Terminal block pin # CONTACT ※ Refer to the software manual for operation descriptions DSP-48...
  • Page 11: Applications

    DIGITAL SPEAKER PROCESSOR Applications Applications DSP-48 AMPLIFIER AUDIO MIXER MAIN SPEAKER AMPLIFIER AMPLIFIER SUBWOOFER SPEAKER MONITER SPEAKER AMPLIFIER DELAY SPEAKER DSP-48...
  • Page 12: Block Diagram

    DIGITAL SPEAKER PROCESSOR Block Diagram Block Diagram DSP-48...
  • Page 13 DIGITAL SPEAKER PROCESSOR DSP-48...
  • Page 14: Specifications

    DIGITAL SPEAKER PROCESSOR Specifications Specifications DSP-48 Audio processing AD/DA conversion 24-bit Sampling frequency 96kHz Signal processing 32-bit floating point Propagation delay < 3ms A/D Dynamic range < 118dB D/A Dynamic range < 118dB Dynamic range (Input to Output) > 108dB, A-weighting filter...
  • Page 15 DIGITAL SPEAKER PROCESSOR ※ DIMENSIONS DSP-48...
  • Page 16 5. In case of fixing by not using the included screws or screws of the same size, or using insufficient number of screws the manufacturer is not responsible for any safety accidents caused by this. Accessories included for fixing the product - Specification: SCREW M5x0.8P, L=12 - Quantity: 4pcs DSP-48...
  • Page 17: Service

    To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region.
  • Page 18 DIGITAL SPEAKER PROCESSOR DSP-48...
  • Page 20 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
