Summary of Contents for SIP SPEEDO REVCOUNTER 2.1

  • Page 1 SPEEDO REVCOUNTER 2.1...

  • Page 2: Signs And Symbols

    INSTRUCTIONS Thank you for purchasing our new SIP Scootershop Vespa T5. Before use, please read the instructions thoroughly and keep it for future reference. NOTICE 1. The SIP LCD meter runs on AC/DC 12V. 2. For installation, please follow the steps described in this manual.

  • Page 3: Wiring Installation Instructions

    WIRING INSTALLATION INSTRUCTIONS Meter part no. 1 Brown / red +12V DC voltage measurement Brown RPM wire PIN1 : Yellow/ Black (LO) Multiplug for cable PIN2 : Yellow (HI) section from wiring PIN3 : Black (GND) harness. PIN4 : Blue (Turn) PIN5 : Brown (RPM, +12V) PIN1 : Green/ White (Fuel) Multiplug for cable...
  • Page 4 Step 6 Remove handlebar cover, remove speedometer Connect the speedometer cable and other cable and multiplug from speedometer. optional cables to the SIP Speedo Revcounter. Step 3 Step 7 Remove the 6 inner screws from the handlebar Mount the handlebar cover and x it with the cover and speedometer.

  • Page 5: Basic Function

    BASIC FUNCTION Thermometer Average speed A, B Digital speedometer Display range: 0-250˚C (32-482˚F) Display range: 0-199 km/h (0-140 mph) Display range: 0-199 km/h (0~140 mph) Display unit: 1˚C (˚F) Display unit: 1 km/h (mph) Display unit: 1 km/h (1 mph) Riding time A, B Volt Gears...
  • Page 6 BASIC FUNCTION Thermometer Average speed A, B Digital speedometer Display range: 0-250˚C (32-482˚F) Display range: 0-199 km/h (0-140 mph) Display range: 0-199 km/h (0~140 mph) Display unit: 1˚C (˚F) Display unit: 1 km/h (mph) Display unit: 1 km/h (1 mph) Riding time A, B Volt Gears...
  • Page 7 MAIN MENU SWITCHING DESCRIPTION (Right Button) Function switch instruction (Right button) Main display. Press right button once to switch from trip B ● ● Mileage maintenance. Example: Distance = 00001 km. ● Mileage maintenance will count down from setting ● value, when it reaches 0, the screen will blink to indicate mileage reached.
  • Page 8 MAIN MENU SWITCHING DESCRIPTION (Left Button) Function switch instruction (Left button) Example: Press left button once to switch from average speed A Thermometer = 95˚C. ● ● to riding time B. Example: Riding time A = 00:20 min. ● NOTE! Riding time: The riding time is sucessfully reset when the display reads 00:00 Press left button once to switch from Thermometer to...
  • Page 9 Press left button once to switch from average speed B Press left button once to switch from Voltage to Gear. ● ● to Voltage. When blinking, the low voltage limit is exceeded. ● Press left button once to switch from Gear to Digital LCD ●...
  • Page 10 SETTINGS AND FEATURES INDEX SCREEN Features index In the overall main screen, hold the right + left button ● Units and needle gauge settings for 3 seconds to enter into the settings screen. Speed signal settings Tire overall diameter / Speedometer drive ratio settings RPM pulse settings Fuel gauge resistance settings Backlight brightness settings...
  • Page 11 SPEED SIGNAL SETTINGS Press left button once to enter the speed signal Example: Set speed signal from INT to EXT. ● ● settings screen. Press the left button to return to the ADJ 2 menu. ● Example: To set speed signal to EXT. Press the right button to enter the ADJ 3 menu ●...
  • Page 12 Speedometer drive ratio settings / (4.2 Setting is "Int") Speedometer drive - state number of teeth ● Data is received through the speedo shaft. The table below shows some Example: You want to set the transmission ratio ● original data for your reference - make sure to check components, at 0.80.
  • Page 13 Press the right button to enter the ADJ 5 menu ● 4 signals per rotation (Fuel gauge resistance settings). 5 signals per rotation SIP Performance Vape ign. 6 signals per rotation FUEL GAUGE RESISTANCE SETTINGS Press left button once to enter the Fuel gauge Example: Set fuel meter's resistance value from ●...
  • Page 14 BACKLIGHT BRIGHTNESS SETTINGS Press left button once to enter the Backlight Example: Set the backlight brightness from ● ● brightness settings screen. 5 / 5 (100 %) to 3 / 5 (60 %). Press the left button to return to the ADJ 6 menu. ●...
  • Page 15 GEAR LEVEL LEARNING SETTINGS Press left button once to enter the Gear ● learning settings screen. P .S. During actual gear level learning, please select road that is wide and has more straight distance with no tra c light for more accurate settings and tra c safety. Press the right button to choose turn on or o ●...
  • Page 16 POWER TEST SETTINGS (SPEED / DISTANCE) Press left button once to enter the Power test Example: To set distance to 150 m. ● ● (SPEED) settings screen. Press the right button to choose the setting number. ● Now the setting value will blink. NOTE Setting range: 50-1000 m (1 / 32 - 20 / 32 mile).
  • Page 17 4.10 MILEAGE MAINTENANCE SETTINGS Press left button once to enter the Mileage Example: Set the mileage maintenance from 500 ● ● maintenance settings screen. to 800. Press the left button to return to the ADJ 10 menu. ● To set mileage maintenance to (ON). Press the right button to enter the ADJ 11 menu ●...
  • Page 18 4.11 TOTAL MILEAGE Example: Current total internal mileage display is ● 12500 km. Press the right button to enter the ADJ 12 menu ● (Adjustable mileage settings). User unable to adjust or remove total internal mileage. Display range: 0 ~ 99,999 km (mile). NOTE For display only, NO setting.

  • Page 19: Troubleshooting

    Check the battery voltage, replace if necessary. The battery is defective or too weak to supply the speedometer with power. Install a 12V ignition. The SIP tacho does not work The speedometer runs only with 12V DC or AC with my 6V ignition. voltage.
  • Page 20 TROUBLE SHOOTING Symptom Cause Solution Speed is not displayed or Wrong speed pulse set. In adjustment menu 4 you set how many signals of the ignition displayed incorrectly. the speedometer reads. This varies mainly between the original The brown cable for the speed pulse is not and Vespatronic ignition.
  • Page 21 TROUBLE SHOOTING Symptom Cause Solution "FUEL" warning display is Float on the petrol cock defective. When removed, lift the oat on the fuel tap / fuel gauge, then "FUEL" should switch o . If not, renew fuel tap / fuel gauge. always on.
  • Page 22 6.1 SPARE PARTS / OPTIONAL PARTS Fuel Tap SIP Fast Flow Adapter temperature detector for Vespa 50-125/PV/ET3/PK/S/125 V30-33/ AC Ø 14mm, waterproof, 250°( ts SIP VM/VN/VNA-TS/150 VL/VB/GS/VBA-T4/160 GS/ speedometer)(5 pcs) 180 SS/Rally/PX/T5 with lever with reserve Art. No.: KI001R15 Art. No.: 15878100...
  • Page 23 Notes...
  • Page 24 L : SIP-2022-11-04 C : SIP-2024-01-23...
