- Page 1 Operation Manual DPM03 Multifunction Signal Display Monitor eyc-tech DPM03...
-
Page 2: Table Of Contents
Setting RS-485 ModBus Protocol ------------------------------------------------------------- 10 Measurement Programming ------------------------------------------------------------------- 12 Linearity Computation --------------------------------------------------------------------------- 14 Export and Import Configuration ------------------------------------------------------------- 15 Device Information ------------------------------------------------------------------------------- 16 Display and Data Log ----------------------------------------------------------------------------- 17 Inspection and maintenance -------------------------------------------------------------------------- 20 Maintenance ------------------------------------------------------------------------------------------ 20 Troubleshooting -------------------------------------------------------------------------------------- 20 www.eyc-tech.com... -
Page 3: Security Considerations
Solemn Statement : This product cannot be used for any explosion-proof area. Do not use this product in a situation where human life may be affected. eyc-tech will not bear any responsibility for the results produced by the operators！ Warning! ... -
Page 4: Dimension
Signal / Meter Multifunction Signal Display Monitor Dimension Dimension Installation Dimension Connection *Please make sure the product and the device which connect with RS-485 are on common ground, avoid damaged product. Installation www.eyc-tech.com... -
Page 5: Menu Operation
Signal / Meter eyc-tech DPM03 Menu Flowchart Menu Operation Multifunction Signal Display Monitor Error Reaction Power On System Set Point Alarm Hysteresis On Delay Off Delay Hold High Activate Relay 8 8 8 8 8 8 8 8 8 8... - Page 6 Register Type 1000 9600 Mode Station ID Parity Check Stop Bit Address Data Swap 19200 Master None 1 bit Modbus 38400 Slave 0 0 1 Even 2 bits 8 8 8 8 8 57600 115200 Float 0.01 0.001 0.0001 www.eyc-tech.com...
-
Page 7: Configuration Software
Multifunction Signal Display Monitor Configuration Software Application Program Introduction User may download the configuration software on eyc-tech web site. Please decompress the application prior to execute it. Operating System requirements: above Windows 7 SP1. Other application program requirements: above Microsoft Office 2003. Hardware requirements: USB to RS-485 converter. - Page 8 4. Select the corresponding values of com port as following a. Port: Please confirm the connection com port first b. Baud Rate (DPM03 default 9600) Data Frame (device default None Parity Check, 8 data bits, 1 Response Timeout (default 300ms)
-
Page 9: Scan Rs-485 Connection
※Use scan function to connect when forgetting the connection information or having more facilities. Connect the product to PC via RS-485 converter Execute configuration software Click "Interface > Config" Select the corresponding values of com port as fallowing Click "Scan" to execute connection facilities Scan connection facilities and set up www.eyc-tech.com... - Page 10 Signal / Meter Multifunction Signal Display Monitor a. Select Station ID b. Click "CLOSE AND EXPORT" Click "Apply" www.eyc-tech.com...
-
Page 11: Setting Rs-485 Modbus Protocol
Connect successfully a. Show value and trend chart of the measurement b. Show value and tread chart of device MCU temperature c. Show "Open Port, Read successful" Setting RS-485 ModBus Protocol Setting RS-485 connection as step 6.1 Click "Setting" tab www.eyc-tech.com... - Page 12 Signal / Meter Multifunction Signal Display Monitor Select Modbus Protocol parameter a. Station ID：1~247 b. Baud Rate：9600, 19200, 38400, 57600, 115200 c. Data Frame：None-8Bit-1Stop, None-8Bit-2Stop, Even-8Bit-1Stop, Even-8Bit-2Stop, Odd-8Bit-1Stop, Odd-8Bit-1Stop Click "Apply" Execute connection as step 6.2 or 6.3 again www.eyc-tech.com...
-
Page 13: Measurement Programming
-------------------- The following input is valid when RS-485 is selected -------------------- Modbus protocol type, master or slaver station ID Baud rate (valid when the input selects the master node) Parity check Stop bit Register address Register data type Data format, data word high and low exchange Numerical magnification www.eyc-tech.com... - Page 14 High if upscale active, Low if downscale active hysteresis alarm, NONE if disable, HOLD if memory and hold the first alarm until reboot, Action if active when alarm assert, Deaction if inactive when alarm assert relay on delay time (seconds) relay off delay time (seconds) www.eyc-tech.com...
-
Page 15: Linearity Computation
Interpolate output column, device output value (standard value or correction value) Read the interpolation table of the device Clear the interpolation table on configuration software. Note: this action will not modify the interpolation table of the device apply, the interpolation would be written in device www.eyc-tech.com... -
Page 16: Export And Import Configuration
Click the Setting tab to export and import device configuration summary text of device configuration read device configuration write device configuration load device configuration save device configuration export procedure: device connection step b step e import procedure: device connection step d step c www.eyc-tech.com... -
Page 17: Device Information
Input calibration information analog current input calibration points analog voltage input calibration points frequency input calibration points Output calibration information analog voltage output calibration points analog current output calibration points Calibration date www.eyc-tech.com... -
Page 18: Display And Data Log
Y main coordinate, ON or OFF axis X coordinate, ON or OFF axis Y secondary coordinate, ON or OFF legend, ON or OFF measurement data logging, ON or OFF axis X time scale axis Y amplitude scale www.eyc-tech.com... - Page 19 Store measurement data: save the logging data since device is connected A. Click Display > Export B. Specify the path and filename > Save Note: If the specified path and file name are the same, the original file data will be over written www.eyc-tech.com...
- Page 20 II. Log measurement data: start data logging A. Click Display > Log(OFF) B. Specify the path and filename > save Note: If the specified path and file name are the same, the original file data will be over written www.eyc-tech.com...
-
Page 21: Inspection And Maintenance
Wiring length and terminator RS-485 connection" shorter wiring length, replace terminator Range setting error Correct range setting offset (Adj) value Correct or disable offset precision Linear correction Correct or disable linear correction www.eyc-tech.com... - Page 22 Signal / Meter Multifunction Signal Display Monitor eyc-tech Measuring Specialist enhance your capability with sensor technology Air flow | Humidity | Dew point | Differential pressure | Liquid flow Temp. | Pressure | Level | Air quality | Signal meter Tel.：886-2-8221-2471...
