eyc-tech DPM11 Operation Manual

Signal display monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPM11 and is the answer not in the manual?

Questions and answers

Related Manuals for eyc-tech DPM11

Summary of Contents for eyc-tech DPM11

  • Page 2: Table Of Contents

    5.5 Measurement Programming ................13 5.6 Linearity Computation ................... 17 5.7 Export and Import Configuration ..............18 5.8 Device Information..................19 5.9 Display and Data Log ..................20 ....................24 6.1 Menu Flowchart ..................... 25 6.2 Abbreviation ....................27 ................28 www.eyc-tech.com...
  • Page 3 ⚫ ⚫ ⚫ ⚫ ⚫ ⚫ ⚫ ⚫ ⚫ ⚫ www.eyc-tech.com...
  • Page 4 ■Dimension ■Installation Dimension www.eyc-tech.com...

  • Page 5: Application Program Introduction

    5.1 Application Program Introduction User may download the configuration software on eyc-tech web site. Please decompress the application prior to execute it. Operating System requirements: above Windows XP. Other application program requirements: above Microsoft Office 2003. Hardware requirements: USB to RS-485 converter.
  • Page 6 4. Select the corresponding values of com port as following : a. Port: Please confirm the connection com port first b. Baud Rate (DPM11 default 9600) c. Data Frame (device default None Parity Check, 8 data bits, 1 stop bit) d.
  • Page 7 5. Click "Apply" 6. Connect successfully a. Show value and trend chart of the measurement b. Show value and tread chart of device mcu temperature c. Show "Open Port, Read successful" www.eyc-tech.com...

  • Page 8: Scan Rs-485 Connection

    5.3 Scan RS-485 connection ※Use scan function to connect when forgetting the connection information or having more facilities. 1. Connect the product to PC via RS-485 converter 2. Execute configuration software 3. Click "Interface > Config" www.eyc-tech.com...
  • Page 9 4. Select the corresponding values of com port as fallowing: www.eyc-tech.com...
  • Page 10 5. Click "Scan" to execute connection facilities 6. Scan connection facilities and set up a. Select Station ID b. Click "CLOSE AND EXPORT" 7. Click "Apply" www.eyc-tech.com...
  • Page 11 8. Connect successfully a. Show value and trend chart of the measurement b. Show value and tread chart of device mcu temperature c. Show "Open Port, Read successful" www.eyc-tech.com...

  • Page 12: Setting Rs-485 Modbus Protocol

    5.4 Setting RS-485 ModBus Protocol 1. Setting RS-485 connection as step 5.1 2. Click "Setting" tab www.eyc-tech.com...
  • Page 13 3. Select Modbus Protocol parameter a. Station ID：1~247 b. Baud Rate：9600, 19200, 38400, 57600, 115200 c. Data Frame：None-8Bit-1Stop, None-8Bit-2Stop, Even-8Bit-1Stop, Even-8Bit-2Stop, Odd-8Bit-1Stop, Odd-8Bit-1Stop www.eyc-tech.com...

  • Page 14: Measurement Programming

    Baud rate (valid when the input selects the master node) j. Baud rate (valid when the input selects the slaver node) k. Parity check l. Stop bit m. Register address n. Register data type o. Data high and low exchange p. Numerical magnification q. Number of decimal places www.eyc-tech.com...
  • Page 15 0.5 if take 0.5 seconds for rise time T90 b. output cut-off, disable if set 0 c. output adjustment, the actual output is the analog input plus the adjustment value d. linear correction, NONE if disable, SQRT if root extraction, INTER if linear interpolation www.eyc-tech.com...
  • Page 16 NONE if disable, HOLD if memory and hold the first alarm until reboot, ACTI if active when alarm assert, DEAC if inactive when alarm assert e. relay on delay time (seconds) f. relay off delay time (seconds) www.eyc-tech.com...
  • Page 17 4. The other items could be found in “Option” tab a. LED brightness, 1 darkest, 10 brightest b. password validation, NO if disable, YES is enable c. new password www.eyc-tech.com...

  • Page 18: Linearity Computation

    Interpolate output column, device output value (standard value or correction value) e. Read the interpolation table of the device f. Clear the interpolation table on configuration software. Note: this action will not modify the interpolation table of the device g. apply, the interpolation would be written in device www.eyc-tech.com...

  • Page 19: Export And Import Configuration

    Click the Setting tab to export and import device configuration a. summary text of device configuration b. read device configuration c. write device configuration d. load device configuration e. save device configuration export procedure: device connection→step b→step e import procedure: device connection→step d→step c www.eyc-tech.com...

  • Page 20: Device Information

    MCU temperature calibration point k. analog current input calibration points l. analog voltage input calibration points (partially applicable) m. analog resistance input calibration points (not applicable for DPM11) Output calibration information n. Analog output calibration points (not applicable for DPM11) o.

  • Page 21: Display And Data Log

    5.9 Display and Data Log Click the Display tab to display the measurement data and start data log function 1. data display: click the “Display” tab www.eyc-tech.com...
  • Page 22 Y secondary coordinate, ON or OFF legend, ON or OFF measurement data logging, ON or OFF axis X time scale axis Y amplitude scale 3. Set the logging time interval a. Click File > Log Interval b. select the logging interval www.eyc-tech.com...
  • Page 23 4. Store/log measurement data 1. store measurement data: save the logging data since device is connected 1-1. click Display > Export 1-2. specify the path and filename > Save www.eyc-tech.com...
  • Page 24 Note: If the specified path and file name are the same, the original file data will be over written 2. log measurement data: start data logginge 2-1. click Display > Log(OFF) 2-2. specify the path and filename > save www.eyc-tech.com...
  • Page 25 Note: If the specified path and file name are the same, the original file data will be over written Button name and location UP button OK button DOWN button DPM status and button function www.eyc-tech.com...

  • Page 26: Menu Flowchart

    Return to previous menu, or leave menu mode Hold DOWN Reserved decrease number or option faster Hold OK 10 seconds Reset Menu Same as "Hold OK 1.5 seconds" Press UP and DOWN Brightness Shortcut Not Available simultaneously 6.1 Menu Flowchart www.eyc-tech.com...
  • Page 27 HI.AL‐High cross-over HOLD-Hold relay at error DPM11 Function Setting Instruction signal tigger alarm ACTI-Activate relay at error LO.AL‐Low cross-over DEAC-Deactivate relay at error NONE-Undefined status at error signal tigger alarm Decimal High Relay off- Relay on- Error setting position setting...

  • Page 28: Abbreviation

    RS-485 unit ID  RS-485 baud rate .Ch RS-485 parity check .i RS-485 stop bit . RS-485 register type  RS-485 register swap ul RS-485 register value multiplier  Adjust  Advanced . Enable Password . New Password www.eyc-tech.com...
  • Page 29 ⚫Correct protocol setting or refer ⚫Wiring length and “5.3 Scan RS-485 connection” ⚫shorter wiring length, replace terminator terminator ⚫precision ⚫Range setting error ⚫Correct range setting ⚫offset (Adj) value ⚫Correct or disable offset ⚫Linear correction ⚫Correct or disable linear correction www.eyc-tech.com...
  • Page 30 Measuring Specialist enhance your capability with sensor technology Air flow | Humidity | Dew point | Differential pressure | Liquid flow Temp. | Pressure | Level | Air quality | Signal meter...
