Returns & Faulty Items
• If any problem is encountered during or after installation, please call the All LED technical
department to get the problem resolved as soon as possible.
• Please do not just return the item to the outlet you purchased it from, as you are only entitled to
a replacement or refund after the unit has undergone testing and the unit has been confirmed as
having a manufacturing defect/fault. Your statutory rights are not affected.
• The manufacturer will not be deemed liable or held responsible for any damages caused by faults
or manufacturing defects that may be present in any of its products or the misuse or incorrect
installation of this device.
• All goods are supplied under the terms and conditions of All LED LTD, a copy of which may be
obtained upon written request.
Dimensions
General Information
• Interference may occur with other products on the same frequency of 2.4Ghz
• Product may differ in colour from image on box
• Range signal can be reduced when using within materials such as concrete & metal
Environmental Protection
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
Local Authority or retailer for
recycling advice
The manufacturer will not be deemed liable or held responsible for any damages
caused by faults or manufacturing defects that may be present in any of its products
or the misuse or incorrect installation of this device
Your statutory rights are not affected.
SMART-T Smart LIVE/LIVE Rotary Zigbee Dimmer Module
Technical Specifications
Product Code
Operating Voltage (V)
Max Operating Current (A)
Capacity
Minimum Load
Output Current (max)
PF
Efficiency %
Network Standby Power (W)
Class
Body Material
Frame Colour
Switching Cycles
Ingress Protection
ALL LED LTD
Ambient Operating Temperature (°C)
42 Sedgwick Road,
Luton, LU4 9DT
Input Frequency (Hz)
www.allledgroup.com
sales@allledgroup.com
Guarantee
Tel: +44 (0)208 841 9000
Dimming Mode (Trailing or Leading)
INSTALLATION GUIDE
AiQ/DIM250/LL
AiQ/DIM250/LL
220-240VAC
1.14A
5-250W (LED)
5W
1.36A
0.8
80
<0.5W
II
Polycarbonate
White
>20,000 times
IP20
-10°C ~ 40°C
50Hz
2 Years
Trailing
!
PLEASE READ
BEFORE USE!
1
Advertisement
Table of Contents
Related Manuals for All LED AiQ/DIM250/LL
Summary of Contents for All LED AiQ/DIM250/LL
- Page 1 • All goods are supplied under the terms and conditions of All LED LTD, a copy of which may be AiQ/DIM250/LL obtained upon written request.
- Page 2 Pairing Instructions: Factory Reset: 1. Turn on the light, SHORT PRESS the knob FOUR TIMES and LONG PRESS the FIFTH Network Mode: 15 Minutes TIME until the light starts to step up and down in brightness FIVE TIMES to show that the reset is successful.
