- Page 1 2022/8 ND-LKN100 Digital decoder Ver1.02...
- Page 2 2022/8 ND-LKN100V100 Function: 1. 1. N-regulation use 2. Maximum voltage to 15V 3. 2 function outputs, each output maximum 30mA 4. 1~9999 address number selection 5. Front and rear light 4 kinds of effect output Installation Notes: The above picture is installed correctly...
- Page 3 2022/8 The above picture is installed...
- Page 4 2022/8 If the installation is not plugged in correctly, it will cause the decoder to be defective, please confirm that the installation is correct. # Precautions Please make sure that the current consumption of LED installation does not exceed 30mA. Do not install the decoder track power supply and the light output reversely to prevent the decoder from being burned.
- Page 5 2022/8 CV LIst Illustrate Range Factory setting Short address 1-127 SW Version Reset Long address, Hi byte 192-231 Long address, Low byte 0-255 4: Select short address 34: Select long address Toggle F0, F3, F5 0 = F0 1 = F3 2 = F5 Headlight brightness adjustment 0-39...
