Summary of Contents for drM ND-DE131
- Page 1 2022/3 ND-DE131 Digital decoder Ver1.07...
- Page 2 2022/3 Features 1. Only use N gauge 2. The power high voltage to 15V 3. 28,128 speed operation. 0.8A motor current output, the maximum peak value is 1.5A. 5. 1~9999 Vehicle address selection. Installation Notes Motor contacts...
- Page 3 2022/3 Rail contacts Some DC motors have parallel capacitors at both ends, please remove this capacitor. Do not connect the power and motor terminals in reverse to avoid decoder burns. Reset decoder 1. To reset the factory settings, please write CV8 to 8. After power on again, restore the factory settings.
- Page 4 2022/3 Mid-speed 0-255 SW version Reset / NMRA assigned manufacturer ID for drM : 164 (10100100) Long address, Hi byte 192-231 Long address, Low byte 0-255 Basic settings Bit 0 - Vehicle direction: 0 = Forward, 1 = Reverse Bit 2 – Analog option: 0 = off Bit 4 –Speed curve table:...
