  • Page 1 AX480A AX480A-F AX480A-GF Motherboard Manual Revision A1...
  • Page 2 Introduction FCC Guidelines This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications.
  • Page 3 Motherboard Manual Trademark Recognition Microsoft and Windows are registered trademarks of Microsoft Corp. Other product names mentioned in this manual are the properties of their respective owners and are acknowledged.

  • Page 4: Table Of Contents

    Introduction Contents Static Electricity Precautions............... Chapter 1 - Introduction..............Package Contents................Optional Items................. Before Using the Motherboard............ About this Manual................The Motherboard................Specifications................... Product Features Explained............Chapter 2 - Installation................ The Components of the Motherboard........Quick Installation Guide..............CPU....................System Memory................Expansion Slots................

  • Page 5: Static Electricity Precautions

    Motherboard Manual Static Electricity Precautions It is quite easy to inadvertently damage your PC, motherboard, components or devices even before installing them in your system unit. Static electrical discharge can damage computer components without causing any signs of physical damage. You must take extra care in handling them to ensure against electrostatic build-up.

  • Page 6: Chapter 1 - Introduction

    Introduction Chapter 1 Introduction...

  • Page 7: Package Contents

    Motherboard Manual Package Contents • 1 motherboard • 1 manual • 1 pack of floppy and IDE disk drive shackle cables • 1 ATA/100 IDE disk drive cable • 1 pack of 2 Serial ATA data cables • 1 Serial ATA power cable •...

  • Page 8: About This Manual

    Introduction • Damaged accessories If any of the accessories are damaged, please contact your dealer or sales representative for assistance. Prepare basic system components • If you are installing the motherboard in a new system, you will need at least the following internal components. A CPU DDR SDRAM memory module Storage devices such as hard disk drive, CD-ROM, etc.

  • Page 9: The Motherboard

    Motherboard Manual The Motherboard...

  • Page 10: Specifications

    Introduction Specifications Chipset • North bridge: RADEON XPRESS 200P (RX480) • South bridge: ATI SB400 • AMD Athlon 64 • Socket 939 System bus • 2000MT/s Hyper Transport Memory • 4 184-pin DDR DIMM sockets • Supports dual channel (128-bit wide) memory interface •...
  • Page 11 Motherboard Manual • 1 PS/2 mouse port Rear Panel I/O • 1 PS/2 keyboard port • 1 S/PDIF-in port • 1 S/PDIF-out port • 1 parallel port • 1 COM 1 port • 1 IEEE 1394 port • 1 LAN port •...

  • Page 12: Product Features Explained

    Introduction Product Features Explained AMD Athlon The AMD Athlon 64 CPU provides superior computing for many software applications by allowing both 32-bit and 64-bit applications to run simultaneously on the same platform. This allows the operating system and software to process more data and access a tremendous amount of memory, improving the overall system performance.
  • Page 13 Motherboard Manual Serial ATA Interface with RAID Serial ATA is a storage interface that is compliant with SATA 1.0 specification. With speed of up to 1.5Gbps, it improves hard drive performance faster than the standard parallel ATA whose data transfer rate is 100MB/s. The motherboard allows configuring RAID on SATA drives.
  • Page 14 Introduction S/PDIF S/PDIF is a standard audio file transfer format that transfers digital audio signals to a device without having to be converted first to an analog format. This prevents the quality of the audio signal from degrading whenever it is converted to analog. S/PDIF is usually found on digital audio equipment such as a DAT machine or audio processing device.

  • Page 15: Chapter 2 - Installation

    Motherboard Manual Chapter 2 Installation...

  • Page 16: The Components Of The Motherboard

    Installation The Components of the Motherboard DDR B1 DDR B2 +12V power DDR A1 DDR A2 CPU fan Mouse PS/2 power select (JP1) S/PDIF- S/PDIF- Parallel ATX power COM 1 USB 0-3 IEEE 1394_1 select (JP2) USB 2-3 USB 0-1 RADEON Line-in XPRESS...

  • Page 17: Quick Installation Guide

    Motherboard Manual Quick Installation Guide • Make sure the PC and all other peripheral devices connected to it has been powered-off. • Disconnect all power cords and cables. Step 1 Install the CPU, CPU fan / heatsink and other system fans. Step 2 Install the DIMM.

  • Page 18: Cpu

    Installation Overview The 939-pin CPU socket on the motherboard is exclusively designed for installing an AMD Athlon 64 CPU. Installing the CPU 1. Make sure the PC and all other peripheral devices connected to it has been powered down. 2. Disconnect all power cords and cables. 3.
  • Page 19 Motherboard Manual 4. Unlock the socket by pushing the lever sideways, away from the socket, then lifting it up to a 90 angle. Make sure the lever is lifted to at least this angle otherwise the CPU will not fit in properly. Lever 5.
  • Page 20 Installation 6. Insert the CPU into the socket until it is seated in place. The CPU will fit in only one orientation and can easily be inserted without exerting any force. Important • Do not force the CPU into the socket. Forcing the CPU into the socket may bend the pins and damage the CPU.
  • Page 21 Motherboard Manual Installing the Fan and Heat Sink The CPU must be kept cool by using a CPU fan with heat sink. Without sufficient air circulation across the CPU and heat sink, the CPU will overheat damaging both the CPU and motherboard. Note •...
  • Page 22 Installation 3. Place the heat sink on top of the CPU. Now hook one side of the retention clip onto the retention module base by fitting the holes on the retention clip into the retaining tabs of the retention module base. Retaining Retention clip Retention module base...
  • Page 23 Motherboard Manual 4. Hook the other side of the retention clip (the one near the retention lever) so that the holes on the retention clip also fit into the retaining tabs of the retention module base. Note • You will not be able to secure the fan and heat sink assembly in place if it did not fit properly onto the retention module base.

  • Page 24: System Memory

    Installation System Memory Overview The 4 DDR (Double Data Rate) sockets support up to 4GB system memory using 184-pin unbuffered non-ECC DDR266/ 333/400 DIMMs. DDR A1 DDR A2 DDR B1 DDR B2 The four DDR DIMM sockets are divided into 2 channels: Channel A - DDR A1 and DDR A2 Channel B - DDR B1 and DDR B2 The supported memory interfaces are:...
  • Page 25 Motherboard Manual Single Channel • DIMMs are on the same channel. • DIMMs in a channel can be identical or completely different. However, we highly recommend using identical DIMMs. • Not all slots need to be populated. Dual Channel • DIMMs of the same memory configu- ration are on different channels.
  • Page 26 Installation Installing a DIMM Important • Power-off the PC and unplug the power cord prior to adding or removing DIMMs. Failure to do so may cause severe damage to the motherboard. 1. Unlock the DIMM socket by pulling the “tabs” that are at the ends of the socket to the side.

  • Page 27: Expansion Slots

    Motherboard Manual Expansion Slots PCI Express x16 PCI Express x1 PCI Express x1 PCI Express x1 PCI slots PCI Express The motherboard allows installing one x16 and three x1 PCI Express cards. Install PCI Express x16 graphics card, that comply to the PCI Express specifications, into the PCI Express x16 slot.
  • Page 28 Installation PCI Express x16 PCI Express x1 PCI Express x1 PCI Express x1 PCI Slots The motherboard is equipped with 2 PCI slots for installing PCI expansion cards. These slots are Bus Master, 32-bit, 33MHz and PCI 2.2 compliant. The slots provide a fast high-bandwidth pathway between the motherboard and expansion cards.
  • Page 29 Motherboard Manual Installing an Expansion Card The steps below assume that the motherboard is already installed in the system chassis. Important • Make sure the PC and all other peripheral devices connected to it has been powered-off. • Disconnect all power cords and cables. Remove the system unit cover.

  • Page 30: Jumper

    Installation Jumper Clear CMOS Data 1-2 On: 2-3 On: Default Clear CMOS The Clear CMOS jumper (JP4) is used to clear the RAM data stored in the battery-backed CMOS. If the CMOS data becomes corrupted or you forgot the supervisor or user password, clear the CMOS data to reconfigure the system back to the default values stored in the ROM BIOS.
  • Page 31 Motherboard Manual PS/2 Power Select 1-2 On: 2-3 On: Default Standby The PS/2 power select jumper (JP1) is used to select the power of the PS/2 keyboard/mouse port. Selecting Standby will allow you to use the PS/2 keyboard or PS/2 mouse to wake up the system.
  • Page 32 Installation USB Power Select 1-2 On: 2-3 On: Default Standby 1-2 On: 2-3 On: Default Standby The USB power select jumpers (JP2 for USB 0-3 and JP3 for USB 4-7) are used to select the power of the USB ports. Selecting Standby will allow you to use a USB device to wake up the system.

  • Page 33: Rear Panel I/O

    Motherboard Manual Rear Panel I/O Line-out Line-in RJ45 PS/2 IEEE Parallel Mouse 1394_1 Side R/L Center/ Subwoofer Rear R/L PS/2 S/PDIF-in COM 1 USB 2-3 USB 0-1 Mic-in S/PDIF-out PS/2 Mouse The PS/2 mouse port is used to connect a PS/2 mouse. PS/2 Keyboard The PS/2 keyboard port is used to connect a standard keyboard that has a PS/2 plug.
  • Page 34 Installation The USB ports are used to connect USB 2.0 devices. Line-in The line-in port is used to connect any audio devices such as Hi-fi set, CD player, tape player, AM/FM radio tuner, synthesizer, etc. Line-out The line-out port is used to connect to the front right and front left speakers of the audio system.

  • Page 35: Internal I/O

    Motherboard Manual Internal I/O Serial ATA Connectors SATA 0 SATA 1 SATA 2 SATA 3 Connecting Serial ATA Drives The four Serial ATA connectors are used to connect Serial ATA devices. Connect one end of the Serial ATA data cable to the Serial ATA device and the other end to SATA 0 (J16), SATA 1 (J18), SATA 2 (J21) or SATA 3 (J22).
  • Page 36 Installation 2. Reboot the PC. 3. When the system powers-up, press the <Ctrl> and <S> keys simultaneously to run the RAID BIOS Setting Utility. The utility is used to configure the Serial ATA drives to RAID 0 and RAID 4. Install the ATI Chipset Driver. For steps 1 to 3, refer to chapter 3 for more information.
  • Page 37 Motherboard Manual IDE Connectors IDE 2 IDE 1 Connecting IDE Drives Each IDE connector supports 2 IDE devices, a Master and a Slave. Use an IDE ribbon cable to connect the drives to the motherboard. An IDE ribbon cable have 3 connectors on them, one that plugs into an IDE connector on the motherboard and the other 2 connects to IDE devices.
  • Page 38 Installation Adding a Second IDE Disk Drive When using two IDE drives, one must be set as the master and the other as the slave. Follow the instructions provided by the drive manufacturer for setting the jumpers and/or switches on the drives.
  • Page 39 Motherboard Manual FDD Connector Connecting Floppy Drives The FDD connector supports 2 floppy disk drives. Use a FDD ribbon cable to connect the drives to the motherboard. Insert one end of the floppy disk drive cable into the floppy connector (CN12) on the motherboard and the other end-most connector to the drive you want to designate as Drive A.
  • Page 40 Installation USB Connectors USB 6-7 USB 4-5 Connecting USB Cables USB 4-5 (J19) and USB 6-7 (J20) are used to connect 4 additional USB 2.0 ports. Insert the connector that is attached to the USB port cables to J19 or J20 then install the USB port bracket to an available bracket slot at the rear of the system chassis.
  • Page 41 Motherboard Manual IEEE 1394 Connector Connecting the IEEE 1394 Cable The IEEE 1394 connector (J26) is used to connect an additional 1394 device. Insert the connector that is attached to the 1394 port cable to J26 then install the 1394 port bracket to an available bracket slot at the rear of the system chassis.
  • Page 42 Installation Serial (COM 2) Connector Connecting the Serial Port Cable The serial connector (J30) is for connecting a modem, serial printer, remote display terminal or other serial devices. Insert the connector that is attached to the serial port cable to J30 then install the serial port bracket to an available bracket slot at the rear of the system chassis.
  • Page 43 Motherboard Manual Front Audio Connector Connecting the Front Audio Cable The front audio connector (J15) is used to connect to the audio module that is mounted at the front panel of the system chassis. The audio module is normally equipped with a line-out port and a mic-in port.
  • Page 44 Installation CD-in Connector Right audio Left audio channel channel GND GND Connecting the CD-in Cable The CD-in connector (J17) uses a 4-pin audio cable to connect to the rear of an optical drive.
  • Page 45 Motherboard Manual IR and CIR Connectors IRRX N. C. Ground IRTX CIRRX N. C. 5VSB CIRTX Connecting the CIR/IR Cable The IR (J28) and CIR (J29) connectors are used to connect IR devices. Insert the cable connector from the IR or CIR module to J28 or J29.
  • Page 46 Installation Cooling Fan Connectors CPU fan Sense Power NB fan Power Chassis fan Sense Power Connecting the Cooling Fan Cables The cooling fan connectors are used to connect cooling fans. Insert the CPU fan, NB fan and chassis fan cable connectors to J3, J11 and J23 respectively.
  • Page 47 Motherboard Manual ATX Power Connectors +12V +12V Ground Ground 13 1 +3.3VDC +3.3VDC +3.3VDC -12VDC +5VDC PS_ON# +5VDC PWR_OK +5VSB +5VDC +12VDC +5VDC +12VDC +5VDC +3.3VDC Connecting the Power Cables The motherboard is equipped with a standard 24-pin ATX main power connector (J8) and a 4-pin +12V power connector (CN1) for connecting an ATX12V power supply.
  • Page 48 Installation Speaker Connector Connecting the Speaker Cable The speaker connector (J25) is used to connect to the speaker that is in the system chassis.
  • Page 49 Motherboard Manual Power LED Connector Connecting the Power LED Cable Connect the front panel’s power LED cable to J27. When the system’s power is on, the power LED will light and will blink when the system is in the standby mode. The function of this LED connector is identical to pins 2 and 4 of the front panel connector.
  • Page 50 Installation Front Panel Connector The front panel connector (J24) on the motherboard supports several system indicators and controls that connect to the front panel of the system chassis. This will enable you to determine information about the system’s operational status and provide some system controls.
  • Page 51 Motherboard Manual Power Button Connect the front panel’s power button cable to pins 6 and 8. The power button is used to power on and off the system. You can also configure the system to use the keyboard or mouse to power-on the system, or to respond to power restoration after a power outage occurs.
  • Page 52 Installation Battery The Lithium coin cell battery powers the real-time clock and CMOS memory. It is an auxiliary source of power when the main power is shut off.

  • Page 53: Chapter 3 - Bios Setup

    Motherboard Manual Chapter 3 BIOS Setup...

  • Page 54: Overview

    BIOS Setup Overview The BIOS is a program that takes care of the basic level of communication between the CPU and peripherals. In contains codes for various advanced features found in this motherboard. The BIOS allows you to configure the system and save the configuration in a battery-backed CMOS so that the data retains even when the power is off.
  • Page 55 Motherboard Manual system by pressing the <Ctrl> <Alt> and <Del> keys simultaneously. Legends Keys Function Right and Left arrows Moves the highlight left or right to select a menu. Moves the highlight up or down Up and Down arrows between submenus or fields. Exits to the BIOS Setup Utility.
  • Page 56 BIOS Setup BIOS Seup - Main This is the first screen that you will see when you enter the BIOS Setup Utility. AMIBIOS This field will show the version and other information about the current BIOS. Processor This field will show the detected type and speed of the processor.
  • Page 57 Motherboard Manual System Date The date format is <day>, <month>, <date>, <year>. Day displays a day, from Sunday to Saturday. Month displays the month, from January to December. Date displays the date, from 1 to 31. Year displays the year, from 1990 to 2098.
  • Page 58 BIOS Setup Advanced Advanced menu comes with several submenus allowing you to configure your system for basic operation. Some entries are defaults required by the motherboard, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.
  • Page 59 Motherboard Manual CPU Configuration The fields in the CPU Configuration submenu will show the CPU information detected by the BIOS. Most of these fields are for testing purposes only. Do not alter the settings in these fields. GART Error Reporting This field is basically for testing purposes only.
  • Page 60 BIOS Setup IDE Configuration Onboard PCI IDE Controller Disabled Disables the onboard IDE controller. Primary Enables the primary IDE only. Secondary Enables the secondary IDE only. Both Enables both primary and secondary IDE. Primary IDE Master, Primary IDE Slave, Secondary IDE Master and Secondary IDE Slave The BIOS can automatically detect the IDE devices connected to the PC.
  • Page 61 Motherboard Manual LBA/Large Mode Auto Automatically enables the LBA mode if the mode is supported by the device. Disabled Select this option if the device was not formatted with LBA mode. Block (Multi-Sector Transfer) Auto Data transfer to and from the device occurs multiple sectors at a time.
  • Page 62 BIOS Setup IDE Detect Time Out (Sec) This field is used to select the duration time for detecting an IDE drive (ATA/ATAPI devices). ATAPI 80Pin Cable Detection This field is used to select the ATAPI device that will detect 80- pin cable connection.
  • Page 63 Motherboard Manual SuperIO Configuration Onboard Floppy Controller This field is used to enable or disable the onboard floppy controller. Floppy Drive Swap When this field is enabled and the system is booting from the floppy drive, the system will boot from drive B instead of drive A. When this field is disabled, the system will boot from drive A.
  • Page 64 BIOS Setup Parallel Port Mode The options are Normal, EPP, ECP and EPP+ECP. These apply to a standard specification and will depend on the type and speed of your device. Refer to your peripheral’s manual for the best option. Normal Allows normal speed operation but in one direction only.
  • Page 65 Motherboard Manual Hardware Health Configuration H/W Health Function This field is used to enable or disable the hardware monitoring function. Temperature Sensor #1, Temperature Sensor #2 and Temperature Sensor #3 These fields will show the detected temperature of the CPU and system.
  • Page 66 BIOS Setup Overclocking Configuration FID/VID Change Auto The system will automatically detect the frequency and voltage. Manual This option allows you to manually select the frequency and voltage. CPU/HT Clock Mhz This field is used to select the CPU clock. Clock Change Reset The options are Enabled and Disabled.
  • Page 67 Motherboard Manual ACPI Configuration ACPI Aware OS This field is used to enable or disable the ACPI function supported by an operating system. ACPI is Advanced Configuration and Power Interface. The OS supports ACPI. The OS does not support ACPI. General ACPI Configuration Highlight this submenu and press <Enter>.
  • Page 68 BIOS Setup C State Support The options are Disabled, C2, and C2 and C3. Advanced ACPI Configuration Highlight this submenu and press <Enter>. ACPI 2.0 Support This field is used to enable or disable ACPI (Advanced Configuration and Power Interface) 2.0. The function should be enabled only in operating systems that support ACPI.
  • Page 69 Motherboard Manual APM Configuration Power Management/APM This field is used to enable or disable the Power Management and Advanced Power Management (APM) functions. Power Button Mode On/Off When the power button is pressed, the system will enter the on/off mode. Suspend When the power button is pressed, the system will enter the Suspend mode.
  • Page 70 BIOS Setup RTC Resume Enabled When Enabled, you can set the date and time you would like the PC to power-on. Set the date and time in the fields below. However, if the system is being accessed by incoming calls or the network prior to the date and time set in these fields, the system will give priority to the incoming calls or network.
  • Page 71 Motherboard Manual Hyper Transport Configuration CPU: RS480-NB HT Link Speed The Hyper Transport link will run at the speed selected in this field if the speed is slower than or equal to the system clock and if the system is capable of running at the selected speed. CPU: RS480-NB HT Link Width The Hyper Transport link will run according to the selected width.
  • Page 72 BIOS Setup AMD Cool `N Quiet Configuration Cool N Quiet This field is used to enable or disable the AMD Cool and Quiet function. SMBIOS Configuration Smbios Smi Support The options are Enabled and Disabled.
  • Page 73 Motherboard Manual USB Configuration USB Devices This field is used to enable or disable the USB devices. Legacy USB Support Auto The system will automatically detect USB devices upon boot-up. If the devices were detected, the USB controller legacy mode will be enabled. If no USB devices were detected, the legacy support function will be disabled.
  • Page 74 BIOS Setup PCIPnP Clear NVRAM This field is used to clear the NVRAM during system boot. Plug and Play O/S This field is used to select whether to configure the PCI bus slots using the BIOS or PnP OS. Yes Allows the operating system to configure Plug and Play (PnP) devices not required to boot.
  • Page 75 Motherboard Manual Allocate IRQ to PCI VGA Select Yes for the system to automatically assign an IRQ for the VGA card installed. Your VGA card will need an IRQ only when using the video capture function of the card. If you are not using this function and a new device requires an IRQ, you can set this field to No.
  • Page 76 BIOS Setup Boot Boot Settings Configuration Quick Boot This field is used to speed up Power On Self Test (POST) and allows the BIOS to skip some check items during system boot- up thus shortening the time needed to boot up the system.
  • Page 77 Motherboard Manual Quiet Boot This field is used to enable the OEM logo. Enabled Displays the OEM logo instead of the usual POST messages during system boot-up. Disabled Displays the usual POST messages during system boot-up. AddOn ROM Display Mode Force BIOS During system boot-up, the AddOn ROM screen which is the screen showing the add-...
  • Page 78 BIOS Setup Boot Device Priority Boot Device Priority Select the drive to boot first, second and third in the “1st Boot Device” “2nd Boot Device” and “3rd Boot Device” fields respectively. The BIOS will boot the operating system according to the sequence of the drive selected.
  • Page 79 Motherboard Manual Removable Drives This submenu is used to select the boot sequence of the removable drives such as floppy drive, MO drive, etc.
  • Page 80 BIOS Setup Security Supervisor Password and User Password These fields are used to set a Supervisor password and a User password. If you intend to use both, you must first set the Supervisor password. The Supervisor password is necessary to enter the BIOS Setup utility.
  • Page 81 Motherboard Manual Boot Sector Virus Protection This field protects the boot sector and partition table of the hard disk drive. When this field is enabled, the BIOS will monitor the boot sector and partition table of the hard disk drive. If an attempt is made to write to the boot sector or partition table of the hard disk drive, the BIOS will halt the system and an error message will appear.
  • Page 82 BIOS Setup Chipset NorthBridge Configuration Video Display Devices This field is used to select the type of video output device to be used by the system.
  • Page 83 Motherboard Manual TV Standard This field is used to select the TV’s output standard. Expansion Mode This field is used to enable the text and graphics expansion / central mode selection. Memory Configuration Memclock Mode This field is used to select the memory clock. Auto Sets the memory clock by the code.
  • Page 84 BIOS Setup Bank Interleaving The options are Auto and Disabled. Burst Length The options are 2 Beats, 4 Beats and 8 Beats. Select 4 Beats for 64 Bit Dq. Software Memory Hole This field is used to enable or disable the software memory remapping around memory hole.
  • Page 85 Motherboard Manual SouthBridge Configuration AC97 Audio Device Select Auto for the system to detect the onboard AC97. USB 1.1 OHCI Host Controller This field is used to enable or disable the USB 1.1 port. USB 2.0 EHCI Host Controller This field is used to enable or disable the USB 2.0 EHCI port. OnChip SATA Channel This field is used to enable or disable a SATA channel.
  • Page 86 BIOS Setup SATA IDE Support The options are Option ROM and System BIOS.
  • Page 87 Motherboard Manual ATI RS480 NB Configuration PCIE Reset Delay When this field is Enabled, it allows one second delay before K8 warm reset to work around some external PCIE cards. PCIE SB Payload The options are 16 Bytes, 32 Bytes and 64 Bytes. PCIE DMA WorkAround The options are Disabled, Multi Port and Single Port.
  • Page 88 BIOS Setup Multiport GFX Configuration The options are Enabled and Disabled. PCIE GFX Core Soft Reset The options are Enabled and Disabled. 422 Port Configuration The options are Enabled and Disabled. PCIE GFX Overclocking The options are Enabled and Disabled. ACPI L1 Workaround The options are Enabled and Disabled.
  • Page 89 Motherboard Manual Exit Save Changes and Exit After you are done with the system configuration changes, move the cursor to this field and press <Enter>. Select <OK> to save the changes and exit the setup utility. The modifications you have made will be written into the CMOS memory, and the system will reboot.
  • Page 90 BIOS Setup Discard Changes and Exit If you do not want to save the changes you have made, move the cursor to this field and press <Enter>. Select <OK>. This will allow you to exit the setup utility without the changes being saved to the CMOS memory.
  • Page 91 Motherboard Manual Load Optimal Defaults This field allows the BIOS to automatically set all fields to their respective default settings. This function is designed for maximum system performance but may not work best with some computer applications. Load Fail Safe Defaults This field allows the BIOS to automatically set all fields to their respective default settings.

  • Page 92: Raid Bios

    BIOS Setup RAID BIOS The RAID BIOS utility is used to configure and manage RAID on Serial ATA drives. After you power up the system and all Serial ATA drives have been detected, the RAID BIOS status message screen will ap- pear.

  • Page 93: Chapter 4 - Drivers And Utilities

    Motherboard Manual Chapter 4 Drivers and Utilities...

  • Page 94: Chipset Drivers

    Drivers and Utilities The CD that came with the system board contains drivers, utili- ties and software applications required to enhance the perform- ance of the system board. Insert the CD into a CD-ROM drive. If the computer supports autorun, the Utility CD screen will automatically appear. If autorun is not enabled, double-click "setup.exe"...
  • Page 95 Motherboard Manual Realtek Audio Driver This installs the Realtek audio driver and its application. Realtek LAN Driver This installs the driver for the onboard Realtek LAN. USB Driver This installs the USB 2.0 driver. ® Windows If your Windows ® XP CD already includes Service Pack 1, the USB 2.0 driver will automatically install when you install the operating system.

  • Page 96: Software Utilities

    Drivers and Utilities Software Utilities The Software Utilities menu contains applications and software supported by the motherboard. Pc-cillin 2004 This installs the Pc-cillin 2004 anti-virus program. The program is the most reliable and convenient way of detecting and protecting your PC from computer viruses. Power Speeder This installs the Power Speeder utility.

  • Page 97: Hardware Information

    Motherboard Manual Hardware Information The Hardware Information menu displays basic information about the motherboard. Contact Us The Contact Us menu displays TUL’s contact information.
  • Page 98 Drivers and Utilities RAID The ATI SB400 chipset allows you to configure RAID (Redundant Array of Independents Disks) on Serial ATA drives. It supports RAID 0 and RAID 1. RAID 0 (Striped Disk Array without Fault Tolerance) RAID 0 uses two new identical hard disk drives to read and write data in parallel, interleaved stacks.
  • Page 99 Motherboard Manual RAID Array List - existing and newly created RAID arrays are shown in this section of the utility. 4. Install the ATI Chipset Driver. If you are in the process of installing Windows ® XP or ® Windows 2000 on RAID configured Serial ATA drives, you will need to prepare a floppy diskette that contains the RAID ®...

  • Page 100: Chapter 5 - Troubleshooting

    Troubleshooting Chapter 5 Troubleshooting...
  • Page 101 Motherboard Manual This section details things you can do to evaluate problems that could possibly occur in the course of using this motherboard. The topics covered include possible hardware problems and problems with the CMOS Setup Utility’s system configuration record. Hardware Problems A hardware problem may occur either after you installed additional hardware or because some existing hardware failed...
  • Page 102 Troubleshooting • Third, check the internal components. Turn off and unplug the system before you remove the system’s chassis cover. Make sure all DIMMs are properly installed in the memory sockets. Make sure you used the correct cables to connect the internal peripherals and that the peripherals are properly connected to the motherboard.
  • Page 103 Motherboard Manual Plug and Play Problems motherboard supports automatic recognition configuration of add-in cards that support the Plug and Play (PnP) specification. Most currently available add-in cards support PnP. PnP simplifies card installation by allowing the system to handle system resource allocation. If you installed an add-in card that is not PnP compliant, you need to configure the card manually.
