A350M-SV
A350M-SVF
Revision : A
Date
: May 04, 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A350M-SV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POWERCOLOR A350M-SV

Summary of Contents for POWERCOLOR A350M-SV

  • Page 1 A350M-SV A350M-SVF Revision : A Date : May 04, 2004...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Overview Package Checklist ................1-2 The A350M-SV/ SVF/ SVGF Mainboard ........1-3 Main Features ................1-4 Chapter 2 Installation Procedures 1). Set System Jumpers ..............2-2 Clear CMOS ..............2-2 2). Install Memory Modules ............2-3 3).
  • Page 3 A350M-SV/ SVF/ SVGF Mainboard Manual Chapter 3 BIOS Setup Main Setup ..................3-2 Advanced Setup ................3-2 CPU Configuraion ............. 3-5 IDE Configuraion .............. 3-7 Floppy Configuraion ............3-9 Super IO Configuraion ............3-10 Hardware Health Configuraion .......... 3-12 ACPI Configuraion ............3-13 USB Configuraion .............

  • Page 4: Chapter 1 Overview

    Chapter 1 Overview RC350 1 - 1...

  • Page 5: Package Checklist

    Package Checklist If you discover an y i t em below was d amaged or lost, pleas e c o n t ac t y o u r vendor. NOTE: The driver CD, which contains patch files, onboard video/ audio chip drivers, related online help and other useful information, can be found in your mainboard package.

  • Page 6: The A350M-Sv/ Svf/ Svgf Mainboard

    The A350M-SV/ SVF/ SVGF Mainboard 1 - 3...

  • Page 7: Main Features

    Main Features I n t e l Pentium 4 ( P r es c o t t an d Northwood) processor up to 3.2GHz ® ® - I n t e l H y p e r-Thread i n g Technology - FSB: 533MHz and 800MHz I n t e l Celeron...
  • Page 8 I/O Ports 2 IDE connectors - U l t r a D M A 6 6 / 1 0 0 u p t o 4 d e v i c es COM1 and COM2 (pinhead e r ) 1 VG A p o r t 1 P a r a l l e l p o r t 1 PS/2 mouse and PS/2 keyboard 6 USB ports...

  • Page 9: Chapter 2 Installation Procedures

    Chapter 2 Installation Procedures This mainboard has several user-adjustable jumpers that allow you to configure the system to suit your requirements. This chapter contains information on the various jumper settings on your mainboard. To set up your computer, you must complete the following steps: Step 1 - Set system jumpers.

  • Page 10: Set System Jumpers

    1.) Set System Jumpers Jumpers are used to select the operation modes for your system. Some jump- ers on the board have three metal pins with each pin representing a different function. A 1 is written besides pin 1 on jumpers with three pins. To set a jumper, a black cap containing metal contacts is placed over the jumper pin(s) according to the required configuration.

  • Page 11: Install Memory Modules

    2.) Install Memory Modules 1. Locate DDR DIMM sockets on the mainboard. 2. Install DDR DIMM straight down into socket 1, using both hands, then socket 2, and so forth. 3. The clip on both ends of the socket will close to hold the DDR DIMM in place when the DDR DIMM reaches the bottom of the socket.

  • Page 12: Install The Cpu

    3.) Install the CPU The mainboard has a built-in Switching Voltage Regulator to support CPU Vcore autodetection. That is, it has the ability to detect and recognize the CPU’s condition from the BIOS Setup Screen. The procedure below shows you how to install your CPU, its fan and heatsink.

  • Page 13: Connect Atx Power

    Affix the CPU by pressing the lever downward and locking it beside the socket. 3. Place the fan with heatsink on top of the CPU and press down on the two plastic clips,, them of swith the holes on two sides the retention module.

  • Page 14: Install Expansion Cards

    NOTE: The CPU installing proce- dures should be: 1. Insert the CPU (with its fansink and retention module) on the socket. 2. Connect the 4-pin plug of the power supply 3. Connect the 20-pin plug of the power supply. To remove the processor, please do it in reverse order.

  • Page 15: Connect Devices

    2. Remove the corresponding slot cover from the computer chassis. Un- screw the mounting screw that secures the slot cover and pull the slot cover out from the computer chassis. Keep the slot cover mounting screw nearby. 3. Push the card firmly into the slot. Push down on one end of the expan- sion card, then the other.

  • Page 16: Ide Device Connectors

    IDE Device Connectors The two connectors, IDE1 (PRIMARY) and IDE2 (SECONDARY), are used for your IDE hard disk drives, CD drives, LS-120|drives, or IDE ZIP drives. Insert the floppy ribbon cable (below) onto the floppy connector. The colored stripe (indicated by the arrow, right) of the ribbon cable must be on the same side as Pin 1.

  • Page 17: Power Connectors

    Power Connectors The 20-pin male block connector is connected to the ATX power supply. The 4-pin male block connector is for the ATX_12V power supply. Both connec- tors are linked with your ATX power supply. The plug from the power supply can only be inserted in one orientation because of the different hole sizes.

  • Page 18: Front Panel Block Connector

    Front Panel Block Connector This block connector includes the connectors for linking with the Power LED (2-pin), HDD LED, power button, power/sleep/mes- sage waiting button, and the reset button on the front panel of the system case. Please identify polari- ties of plug wires for the case speaker and LEDs.

  • Page 19: Cd Audio-In Connectors

    CD Audio-In Connectors The connectors, CD_IN and AUX_IN, are for CD-ROM drive audio analog input use. Pin definitions: Pin1 is Left, Pin2 and 3 are GND, P4 is RIGHT. 1394 Connectors (A350M-SVF/SVGF model only) The mainboard has two 1394 Connectors; one 1394 Connector integrated on the edge of the board, and the others use 1394 pinheader on the board.

  • Page 20: Ps/2 Keyboard And Mouse Connector

    PS/2 Keyboard and Mouse Connector These two 6-pin female connectors (keyboard is purple and mouse is green) are used for your PS/2 keyboard and PS/2 mouse. RJ45 LAN Connector The RJ45 jack of the LAN port is used for the LAN cable plug. 2 - 12...

  • Page 21: Serial Port Connectors

    Serial Port Connectors COM1 is teal colored 9-pin D-sub male connector and COM2 is a 9-pin male connector, allowing you to connect with devices that use serial ports, such as a serial mouse or an external modem. VGA Connector This connector is linked to your monitor. The pinheaders pin assignments are shown at right side.

  • Page 22: Printer Connector

    Printer Connector This burgundy-colored 25-pin D-Sub female connector is attached to your printer. Audio I/O Jacks LINE_OUT (lime) can be connected to headphones or preferably powered speakers. LINE_IN (light blue) allows tape players or other audio sources to be recorded by your computer or played through the LINE_OUT. MIC_IN (pink) allows microphones to be connected for audio input.

  • Page 23: Front Audio Connector

    NOTE: The LINE_IN, LINE_OUT, MICROPHONE jacks can be used the 5.1-channel audio output with its software tool. For details, please read the FAQ on the web site www.fic.com.tw. Front Audio Connector The mainboard has a front panel audio, F_AUDIO, connector (Intel spec.).

  • Page 24: Tv_Out Connector (Optional)

    The figure below show the pin assignments of the USB pinheaders. TV_OUT Connector (optional) The connector is used to link your computer system with your TV set through an optional small card. 2 - 16...

  • Page 25: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup 3 - 1...

  • Page 26: Main Setup

    A350M-SV/ SVF/ SVGF Mainboard Manual 3.1 Main Setup 1 . U s e [ E n t e r ] , [ Ta b ] o r [ S h i f t - Ta b ] t o s e l e c t a f i e l d . U s e [ + ] o r [ - ] t o c o n f i g u r e S y s t e m T i m e .
  • Page 27 3 - 3...

  • Page 28: Advanced Setup

    A350M-SV/ SVF/ SVGF Mainboard Manual 3.2 Advanced Setup 3 - 4...

  • Page 29: Cpu Configuraion

    3.2.1 CPU CONFIGURATION 3 - 5...
  • Page 30 A350M-SV/ SVF/ SVGF Mainboard Manual 3 - 6...

  • Page 31: Ide Configuraion

    3.2.2 IDE CONFIGURATION PRIMARY/ SECONDARY IDE MASTER/ SLAVE & THIRD/ FOUTH IDE MASTER 3 - 7...
  • Page 32 A350M-SV/ SVF/ SVGF Mainboard Manual 3 - 8...

  • Page 33: Floppy Configuraion

    3.2.3 FLOPPY CONFIGURATION 3 - 9...

  • Page 34: Super Io Configuraion

    A350M-SV/ SVF/ SVGF Mainboard Manual 3.2.4 SUPER IO CONFIGURATION 3 - 10...
  • Page 35 3 - 11...

  • Page 36: Hardware Health Configuraion

    A350M-SV/ SVF/ SVGF Mainboard Manual 3.2.5 HARDWARE HEALTH CONFIGURATION 3 - 12...

  • Page 37: Acpi Configuraion

    3.2.6 ACPI CONFIGURATION 3 - 13...

  • Page 38: Usb Configuraion

    A350M-SV/ SVF/ SVGF Mainboard Manual 3.2.7 USB CONFIGURATION 3 - 14...

  • Page 39: Pci/Pnp Setup

    3.4 PCI/PnP Setup 3 - 15...
  • Page 40 A350M-SV/ SVF/ SVGF Mainboard Manual 3 - 16...

  • Page 41: Boot Setup

    3.5 Boot Setup 3.5.1 BOOT SETTINGS CONFIGURATION 3 - 17...
  • Page 42 A350M-SV/ SVF/ SVGF Mainboard Manual 3 - 18...

  • Page 43: Boot Device Priority

    3.5.2 BOOT DEVICE PRIORITY 3 - 19...

  • Page 44: Security Setup

    A350M-SV/ SVF/ SVGF Mainboard Manual 3.6 Security Setup 3 - 20...
  • Page 45 3 - 21...

  • Page 46: Chipset Setup

    A350M-SV/ SVF/ SVGF Mainboard Manual 3.7 Chipset Setup 3 - 22...
  • Page 47 3 - 23...
  • Page 48 A350M-SV/ SVF/ SVGF Mainboard Manual 3 - 24...
  • Page 49 3 - 25...

  • Page 50: Power Setup

    A350M-SV/ SVF/ SVGF Mainboard Manual 3.8 Power Setup 3 - 26...

  • Page 51: Exit Setup

    3.9 Exit Setup 3 - 27...

  • Page 52: Chapter 4 Utilities And Software Installation

    Chapter 4 Utilities and Software Installation 4 - 1...
  • Page 53 1-2. In case user's system does not open the Support CD automatically, p l e as e c l i c k t o t h e fo l l o w i n g p a t h t o e n t e r t h e Ma i n I n s t a l l a t i o n M e n u : D : \ a u t o r u n .
  • Page 54 How To update USB 2.0 drivers fo r W indows 2000 5 - 1 . A f t e r u s e r i n s t a l l W indows 2000 SP4, open Device Ma n a g e r. To d o s o , c l i c k S t a r t , p o i n t t o S e t t i n g s , c l i c k C o n t r o l P an e l , d o u b l e - c l i c k S y s t em , c l i c k the Hardware tab , an d t h e n c l i c k Device Ma n a g e r.
