- Page 1 Lilitab Counter Basic Fixed Mount Assembly Instructions v1.0...
- Page 2 Kensington Desk Mount Anchor 4 x 1/4-28 x 0.375 Compact Loradar Anchor Plate Base Screws GOT QUESTIONS? WE’RE HERE TO HELP! Scan to watch assembly video on EMAIL PHONE support@lilitab.com 888.705.0190 our YouTube Channel! Lilitab Counter Basic Fixed Mount Assembly Instructions v1.0...
- Page 3 NOTE: You will need to hold the foot cover up and out of your way while bolting. If not using the compact base, attach to surface using template on page 5, and thread the cable through your substrate. Lilitab Counter Basic Fixed Mount Assembly Instructions v1.0...
- Page 4 L key. NOTE: The security cover screws should be oriented such that they are parallel to the long edge of the Head Unit, as shown. If they’re not, simply rotate the security cover. Lilitab Counter Basic Fixed Mount Assembly Instructions v1.0...
- Page 5 Loradar Anchor Plate with a Kensington Lockhead to secure your kiosk on a counter/surface. PURCHASE OPTIONS FROM AMAZON Kensington Slim Lockhead: https://amzn.to/3lWAAod Kensington Desk Mount Anchor: https://amzn.to/3njssNU Loradar Anchor Plate: https://amzn.to/3Ga1wcc Lilitab Counter Basic Fixed Mount Assembly Instructions v1.0...
- Page 6 Use two (2) bolts, wood screws or other fastener suitable for your surface’s substrate (m6, no.14 or 1/4” diameter). Use the mounting 4X M6 OR pattern to the right for proper alignment. 1.50 1/4-20 38.10 Mounting pattern 1:1 scale Lilitab Counter Basic Fixed Mount Assembly Instructions v1.0...
