- Page 1 RADIUM TUBE RADIANT HEATER USER MANUAL AND WARRANTY CERTIFICATE MANUFACTURER Daygas Heating Systems İnş. Tah. Ltd. Sti. Firuzköy Bulvarı No: 206, 34325 Avcilar / Istanbul 0 (850) 532 91 53 - 0 (212) 423 30 44 Avcilar VD. - 2710796836...
- Page 2 ....................Technical Maintenance ...................... Safety Precautions When Using Radium Series ............Considerations for Gas and Electricity Connection ..........First Run & Troubleshooting ..................... Maintenance and Warnings ..................... Warranty Certificate ......................Warranty Conditions ......................Matters Out of Warranty Coverage ................www.daygas.eu...
- Page 3 Introduction Daygas heat systems were put in place in 2014 by young entrepreneurs in Istanbul and started producing gas heaters in open and closed areas. Since the Daygas organization, it has established unconditional customer satisfaction. Daygas brings to final consumers efficient, economical, quality and functional products that enhance innovation and R&D work, saving energy in the heating...
- Page 4 When used outdoors, the device should be protected from precipitation and wind. Usage Areas of Radium Tubular Series Cafes and restaurants » » Factories » Warehouses Houses of Worship » Gyms » Garages » » Winter gardens and terraces » Military areas www.daygas.eu...
- Page 5 In the area where the device will be installed, the grounding line in the electrical connection suitability should be checked. Grounding line in areas where it is not suitable must be taken separately. The device should never be operated in areas where the grounding line is not properly connected to the device. www.daygas.eu...
- Page 6 Radium U Type Technical Information Radium U Type Radiant Dimensions Weight Installation Capacity Consump- (mm) (kg) Height tion Model m³/h m³/h Gross Radium 15 1,43 1,05 4200 250-450 Radium 20 1,90 1,41 4200 250-450 Radium 30 2,85 2,11 7200-10200 120-175 150-220...
- Page 7 Waiting time for the ignition system. Second Response time of the flame control system. Second Distance between spark plug electrodes. mm 4 ± 1 Precision of combustion control automation. µA Ambient temperature. °C -15...+60 Mounting position. At the bottom of the boiler. Weight. kg 0,15 www.daygas.eu...
- Page 8 Your Daygas Special Master Card Connection Diagram LIGHTERING GROUND IONIZERS VALVE HOUSE SNAIL PROCESTAT NEUTRAL PHASE Radium Tube Type Design and Working Principle Radium Tube consists of a burner with mixing tubes in its enclosures. The mixing tube is connected to the burner body with a connecting discharge tube.
- Page 9 Gas Inlet Gas Outlet Fig. 1 Gas Valve Connection Requirements Installation of valve block should be done by Daygas Authorized Service. » Before connecting the valve block to the gas pipeline, the gas pipeline must be » cleaned and degassed.
- Page 10 I radiant pipe clamp (coupling) 3/4 gasket Snail fan I side closure double Snail fan cable line U type reflector C-14 socket Glass fuse U side closure double U elbow Motherboard box U hanger Motherboard Tors screw Gas flex (internal) www.daygas.eu...
- Page 11 E2 fault warning code and warning light are given on the devices in case of prosestat faults.When the air processor malfunctions, this warning code or warning light appears on the screen of the devices. When the air temperature is broken, the devices do not work. www.daygas.eu...
- Page 12 It provides easy discharge of waste gas due to its ability to both suck and shoot. SNAIL FAN TECHNICAL SPECIFICATIONS Voltage (Nominal) 230 V Frequency 50 Hz Input power 0,08 kW Phase 1 Ph Flow 0,35 A Transfer 2450 d/d Flow 600 m³/h Engine speed 2450 d/d Protection class IP44 Insulation class www.daygas.eu...
- Page 13 Radium U Type Device Equipment TOP HANGER REFLECTOR REFLECTOR COVER BURNER BURNER FLUE OUTLET LOWER HANGER RADIANT PIPE U ELBOW www.daygas.eu...
- Page 14 Step 2 - Placing the Radiant Tubes Make sure the radiant tubes are fully seated on the floor of the lower hanger and make sure the radiant tubes are square and flush. www.daygas.eu...
- Page 15 Make sure that the burner pipe is in full contact with the radiant pipe and fix it with a stainless coupling. without fixing then make sure the burner is level and level. Check its health. If necessary, fix the burner with an additional fixing material as shown in the figure. www.daygas.eu...
- Page 16 Step 7 - Final Check of Device After all the assembly steps are completed, make the final durability test of the device. Never start using the device without making sure that the whole assembly is intact. www.daygas.eu...
- Page 17 Radium I Type Technical Data Radium I Type Radiant Installation Dimensions Weight Capacity Consumption Height (mm) (kg) Model m³/h m³/h Gross Radium 15 1,43 1,05 3900 250-450 Radium 20 1,90 1,41 3900-6900 35-60 45-80 250-450 Radium 30 2,85 2,11 6900-9922...
- Page 18 The gap from the floor to the device is at least 2.5 m. The space from the floor to the device may vary according to the rates approved by the regional gas distribution companies. CEILING DEVICE DEVICE FLOOR 280 cm Reflector Pressure Spring (Supplied with the device) www.daygas.eu...
- Page 19 Make sure that the burner pipe is in full contact with the radiant pipe and fix it with a stainless coupling. After fixing, make sure that the burner is level and level. Check its health. If necessary, fix the burner with an additional fixing material as shown in the figure. www.daygas.eu...
- Page 20 Step 5 - Final Check of Device After all the assembly steps are completed, make the final durability test of the device. Never start using the device without making sure that the whole assembly is intact. www.daygas.eu...
- Page 21 Radium Tube Type Gas and Electric Connections of Devices 1- Electrical Connection Socket: 190-260 V / 50-60 Hz 2- - Gas Connection: 3/4’’ Gas Pressure: 20-50 mbar www.daygas.eu...
- Page 22 Make sure that the assembly of the device and its parts (top cap, mounting foot) » are complete. » Operate the heater by taking into account the requirements specified in the “CONDITIONS FOR SAFE CONNECTION AND OPERATION OF RADIUM TUBE HEATER” of this manual. www.daygas.eu...
- Page 23 Check the operation of the boiler and the ignition electrode of the heater and whether there is a spark. Attention! If the emitter does not start within 30 seconds, the gas supply to the emitter is cut off. To restart the transmitter, you must turn off the transmitter’s power supply. www.daygas.eu...
- Page 24 Attention! In seasonal usage conditions of the heater, the device is not inactive for a long time.R emains, it is recommended to cover the hole in the mixing tube with cloths or take various measures to prevent insects and other organic matter from getting in. www.daygas.eu...
- Page 25 Before giving electrical energy to the device, make sure to measure your electrical line. Our device works with 220/230 V 50 Hz. In case these values change and there is interference, make sure to stabilize your line with regulatory devices. www.daygas.eu...
- Page 26 For malfunctions of your device other than the ones described above, please contact the manufacturer of the device and the service without intervening. Interfering with malfunctions other than the ones above may have dangerous consequences. www.daygas.eu...
- Page 27 Do not leave flammable or combustible materials near the combustion area and do not squeeze them during the operation of your device. Never let your device come into contact with water. When cleaning the paint, use a slightly damp cloth and make sure that your device is absolutely cold. www.daygas.eu...
- Page 28 GUARANTEE CERTIFICATE...
- Page 29 The consumer may apply to the consumer arbitration committee or the consumer court in the place of residence or the consumer transaction, in case of disputes that may arise regarding the use of his rights arising from the guarantee. www.daygas.eu...
- Page 30 (for example, for the purpose of providing process heat instead of space heating), In case the device(s) are first started up outside of Daygas Heating Systems or Daygas authorized service, In case of malfunctions and damages arising from electrical voltage fluctuations...
- Page 31 ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 32 E-Mail: Authorized Stamp: Authorized Stamp: Authorized Signature: Yetkili Signature: MANUFACTURER Daygas Heating Systems İnş. Tah. Ltd. Sti. Firuzköy Bulvarı No: 206, 34325 Avcilar / Istanbul +90 (850) 532 91 53 - +90 (212) 423 30 44 Avcilar VD. - 2710796836...
- Page 33 Authorized Stamp: Authorized Stamp: Authorized Signature: Authorized Signature: Authorized Signature: MANUFACTURER Daygas Heating Systems İnş. Tah. Ltd. Sti. Firuzköy Bulvarı No: 206, 34325 Avcilar / Istanbul +90 (850) 532 91 53 - +90 (212) 423 30 44 Avcilar VD. - 2710796836...
- Page 34 MANUFACTURER Daygas Heating Systems İnş. Tah. Ltd. Sti. Firuzköy Bulvarı No: 206, 34325 Avcilar / Istanbul 0 (850) 532 91 53 - 0 (212) 423 30 44 Avcilar VD. - 2710796836 FACTORY Firuzköy Bulvarı No: 206, 34325 Avcilar / Istanbul...
