Model/Modelo/Modèle
B2596LFp
Series/Series/Seria
®
Windemere
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
p Specify Finish/Especifíque el Acabado/Précisez le Fini
Register Online
Regístrese en línea
S'enregistrer en ligne
www.deltafaucet.com/registerme
To reference replacement parts and access additional
technical documents and product info,
visit www.deltafaucet.com
Para referencia sobre las piezas de repuesto y acceder
a documentos técnicos adicionales e información del
producto, visite www.deltafaucet.com
Pour obtenir la référence des pièces de rechange ainsi
que pour avoir accès à d'autres documents techniques et
renseignements sur le produit, allez à www.deltafaucet.com
?
1-800-345-DELTA (3358)
customerservice@deltafaucet.com
Read all instructions prior to installation.
CAUTION
!
Failure to read these instructions prior to installation may result in personal
injury, property damage, or product failure. Manufacturer assumes no
responsibility for product failure due to improper installation.
Lea todas las instrucciones antes de hacer la instalación.
ADVERTENCIA
!
El no leer estas instrucciones de instalación puede resultar en lesiones
personales, daños a la propiedad, o falla en el funcionamiento del producto.
El fabricante no asume ninguna responsabilidad por la falla del producto
debido a una instalación incorrecta.
Veuillez lire toutes les instructions avant l'installation.
AVERTISSEMENT
!
L'omission de lire les présentes instructions avant l'installation peut
entraîner des blessures, des dommages matériels ou le bris du produit. Le
fabricant se dégage de toute responsabilité à l'égard d'un bris du produit
causé par une mauvaise installation.
You may need:
Usted puede necesitar:
Articles dont vous pouvez avoir besoin :
12/06/2023
TWO HANDLE BATHROOM
86601
CENTERSET FAUCETS
LLAVES DE DOS MANIJAS DE
MONTURA DE CENTRO PARA
LAVAMANOS
ROBINETS À ENTRAXE COURT
À DEUX POIGNÉES
1
86601 Rev. G
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Delta Windemere B2596LF Series
Summary of Contents for Delta Windemere B2596LF Series
- Page 1 Pour obtenir la référence des pièces de rechange ainsi que pour avoir accès à d’autres documents techniques et renseignements sur le produit, allez à www.deltafaucet.com 1-800-345-DELTA (3358) customerservice@deltafaucet.com Read all instructions prior to installation. CAUTION Failure to read these instructions prior to installation may result in personal injury, property damage, or product failure.
- Page 2 Cleaning and Care Care should be given to the cleaning of this product. Although its finish is extremely durable, it can be damaged by harsh abrasives or polish. To clean, simply wipe gently with a damp cloth and blot dry with a soft towel. Limpieza y Cuidado de su Llave Tenga cuidado al limpiar este producto.
- Page 3 SHUT OFF WATER SUPPLIES. Install Pop-Up Assembly Apply silicone to underside of flange (1). Remove stopper (1) and flange (2). Screw nut (3) Remove old faucet. Place gasket (1) on Insert body (2) into sink. Screw flange onto all the way down. Push black gasket (4) down. bottom of new faucet.
- Page 4 CONNECT TO WATER SUPPLIES. FLUSH SYSTEM/CHECK FOR LEAKS. (HOOK-UPS NOT PROVIDED). Remove aerator (1) and turn faucet handles (2) all the way on. Turn on Determine which type of connection you will be making. hot and cold water supplies (3) and flush water lines for one minute. (1) Ball nose risers (3/8"...
- Page 5 Maintenance If faucet exhibits very low flow: A. Remove and clean Aerator (3) (page 5), or SHUT OFFWATER SUPPLIES B. Clean Seats and Springs (2) of any debris. If faucet leaks from spout: *Install stems (1) correctly for proper handle rotation: Replace Stem Unit Assembly (1) and Seats and Springs (2), Note: The stops (4) must point to the center of the faucet for proper handle rotation.
- Page 6 Any labor charges incurred by the purchaser to repair, replace, install or remove this product are not covered by this warranty. Delta Faucet Company shall not be liable for any damage to the faucet resulting from reasonable wear and tear, outdoor use, misuse (including use of the product for an unintended application), freezing water, abuse, neglect or improper or incorrectly performed installation, maintenance or repair, including failure to follow the applicable care and cleaning instructions.
- Page 7 Delta por parte de un comprador que es propietario pero no vive en la vivienda residencial en la que se instaló...
- Page 8 La preuve d’achat (original du reçu du premier acheteur montrant la date d’achat) et la documentation attestant la date de réception du produit par le premier acheteur ou son représentant autorisé (installateur, etc.) doivent être présentées à Delta Faucet Company pour toutes les demandes en vertu de la garantie, sauf si le produit a été enregistré auprès de Delta Faucet Company ou si le produit est un produit recertifié Delta®...
Need help?
Do you have a question about the Windemere B2596LF Series and is the answer not in the manual?
Questions and answers
Cleaner aerator on Model/Modelo/Modèle B2596LFp Series/Series/Seria Windemere® Now leaks under sink when hot water turned on
To fix a leak under the sink when hot water is turned on for the Delta Windemere B2596LF Series, follow these steps:
1. Shut Off Water Supply – Turn off the hot water supply valve under the sink.
2. Inspect Connections – Check the supply line connections to ensure they are tight. If loose, tighten them with a wrench.
3. Check for Damaged Parts – Inspect the supply lines and connections for any visible cracks or wear. Replace any damaged parts.
4. Examine the Cartridge and Seals – If the leak persists, the internal seals or cartridge may be faulty. Turn off both water supplies, remove the faucet handle, and check the seals and springs.
5. Replace Necessary Parts – If the seals, springs, or cartridge are worn out, replace them using the RP54801 or RP41701 repair kit.
6. Reassemble and Test – Reassemble the faucet, turn on the water supply, and check for leaks.
If the issue continues, further inspection of the installation or additional replacement parts may be needed.
