- Page 1 USER MANUAL Drain Auger PMDA7 WHAT'S IN THE BOX 1 x Hex Drive Bar 1 x Groves Please carefully read this user manual before operating the drain auger.
-
Page 2: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 this symbol to avoid possible injury or death. in death or serious injury. in death or serious injury. in minor or moderate injury. Addresses practices not related to personal injury. Double Insulated Amperes WARNING marking concerning Risk of Eye Injury. Wear ANSI-approved safety goggles with side shieds.
-
Page 5: Know Your Product
KNOW YOUR PRODUCT 5. Handle Stand Flexible Cable Case Switch Drum 6.Folding Handle SPECIFICATIONS Cable Length: 22.9 ft. (7mm x 7m) Drum Diameter: 6.2 inch (158mm) Max Rotary Speed: 500 rpm Dredging Capacity: 0.75 inch -2 inch. (19-50mm) Weight: 4.9 lbs (2.22kg) -
Page 6: Check Before Operation
OPERATION Check before operation 1. Check the drain auger’s parts for damage that may pose a threat to your safety. 2. Lubricate the flexible cable in according to the operation manual. 3. Selection of appropriate accessories for pipe dredge can improve the efficiency and quality of dredging. - Page 7 OPERATION(Cont.) Extend the cable to the clogged pipe Method 1 Hold the switch on the front handle tightly to allow the front bearing to clamp the cable, align the clogged pipe, then turn the folding handle straight, rotate in a clockwise direction, making the cable protrude forward until it reaches the blocked position.
- Page 8 OPERATION(Cont.) Clean the blockage Make sure the cable has reached the blocked position, release the switch on the handle to let the front bearing release the cable and the cable is automatically locked at this time, then rotate the handle in a clockwise direction, the cable will not forward or retract and only rotate to clean the pipe blockage.
- Page 9 OPERATION(Cont.) Retract the cable to clean the blockage Hold the switch firmily to press the front bearing against the flexible cable, rotate it counterclockwise to retract the cable into the drum. In this case you can not catch the garbage, please turn it forward first, then pull out the cable manually.
- Page 10 OPERATION(Cont.) Use with power drill ■ NEVER start in the high speed gear, in case the machine will be in an excessive inertia and out of control to cause injury, you are supposed to set the power drill to the minimum speed before starting it.
-
Page 11: Storage And Maintenance
STORAGE AND MAINTENANCE After each use, erect tools with the head down so that the liquid inside the drum will drain out. Please clean the flexible cable and drum carefully. If not used for a long time, apply butter to the surface of the flexible cable to prevent rust. - Page 12 www.populotools.com Instagram: populousa info@populotools.com Made in China...
