Specialty Fiber Stripper
SS110
Thank you for purchasing Fujikura's
Specialty Fiber Stripper.
Please read this instruction manual carefully
before operating the equipment.
Adhere to all safety instructions and
warnings contained in this manual.
Keep this manual in a safe place.
There may be updates without notice.
rd
3
6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fujikura SS110
Summary of Contents for Fujikura SS110
- Page 1 Specialty Fiber Stripper SS110 Thank you for purchasing Fujikura’s Specialty Fiber Stripper. Please read this instruction manual carefully before operating the equipment. Adhere to all safety instructions and warnings contained in this manual. Keep this manual in a safe place.
- Page 2 Please consent beforehand. The software equipped in the specialty fiber stripper and its related documents are protected by copyright laws and international treaty provisions as well as other intellectual property laws. Copying some or all of instruction manual without notice is prohibited.
-
Page 3: Table Of Contents
Table of Contents Safety Information ............. 1 General Information ........... 6 Introduction ......................6 Components ......................6 Description of Product ..........7 Description of Stripper..................7 Functions and Names of Operation Keys ............8 Mode Settings ..................... 9 LED Display ...................... 12 Setting Up the Stripper .......... -
Page 4: Safety Information
Safety Information Thank you for purchasing Fujikura’s Specialty Fiber Stripper. In this instruction manual, the processes and procedures are documented which should be observed in order to use this product safely. The following symbols are used in this instruction manual to indicate warning and caution for safe use. - Page 5 SS110_Rev3...
- Page 6 Safety Information WARNING / CAUTION Disconnect the AC power cord from the AC adapter inlet or the wall socket (outlet) immediately if user observes the following or if the stripper receives the following faults: • Fumes, bad smell, noise, or over-heat occurs. •...
- Page 7 Safety Information WARNING / CAUTION Do not store the stripper in any place where temperature and/or humidity are extremely high. Such environments may cause damage to the stripper. Before turning on, make sure to confirm that there is no abnormality in this product after long-term storage.
- Page 8 Safety Information RECYCLING and DISPOSAL In European Union In accordance with the European Parliament Directive, electrical parts and materials that can be re-used and/or recycled have been identified in order that the use of new resources and the amount of waste going for landfill can be minimised. In the European Union, do not discard this product as unsorted municipal waste.
-
Page 9: General Information
Cleaning Brush BRS-03 Hexagonal Wrench HEX-01 USB Cable USB-01 The fiber stripping conditions can be edited by connecting the SS110 to a PC via a USB cable and using the “Data Connection” application. Additional Options List Name Item Remarks Blade for 80μm Cladding Diameter SB-SS110-80-160 160μm Coating Diameter... -
Page 10: Description Of Product
Description of Product Description of Stripper Heater Rubber Fiber Holder Clamp Fiber Holder Base Top Cover Blade Positioning Spacer LED Indicators Heater Main switch Scale Operation Keys Power Switch USB Port DC Power Port SS110_Rev3... -
Page 11: Functions And Names Of Operation Keys
Description of Product Functions and Names of Operation Keys The current stripper state can be checked using the operation keys and LED Indicators. Main switch F2 key F3 key F1 key LED Indicators LED 1 LED 2 LED 3 Operation Keys Name Description Starts the stripping operation and returns the fiber holder base to its... -
Page 12: Mode Settings
Description of Product Mode Settings This product is equipped with three LEDs to confirm heating temperature setting, fiber strip setting, and operation status. LED Indicators to confirm the heating temperature Press F1 key to enter the heat temperature setting mode for the fiber strip settings. When a fiber stripping mode is selected, the LED indicators will light up and/or blink RED for a few seconds to indicate the temperature for the selected mode. -
Page 13: Led Display
Description of Product Heating temperature LED display LED State setting LED 3 blinks once LED 3 blinks twice LED 3 blinks three times LED 3 blinks four times LED 3 is lit and remains steady How to change the heating temperature setting Press and hold F1 key to enter heat temperature setting mode. - Page 14 Description of Product LED Indicators to confirm the stripping mode Press the F2 key to enter the mode for confirming the strip setting, and when the F2 key is pressed, each LED will light up for a few seconds. As shipped from the factory, one of the three LEDs will illuminate GREEN to indicate the selected stripping mode as shown in the table below.
- Page 15 Description of Product LED Indicators You can check the status of the stripper by the lighting or flashing of the LED. Using the FH110 fiber holder When using the FH110 fiber holder, the user can register the coating removal conditions to each fiber holder.
-
Page 16: Setting Up The Stripper
Set Up the Stripper How to Replace the Blade The SS110 is available with several different sizes of stripper blades that can be purchased as optional accessories. Before starting operation, attach a stripper blade according to the size of the fiber to be stripped. - Page 17 Set Up the Stripper Attach the stripper blade 1. Confirm the blade size, and loosely attach both blades in the correct mounting position. Upper blade Lower blade screws screws Upper & lower blades 2. Tighten the lower blade screws with the hex wrench while pushing the stripper blade downward and backward.
-
Page 18: Heater Height Adjustment
Set Up the Stripper Heater height adjustment This product is able to accommodate different fiber coating diameters by adjusting the height of the heating element. Adjusting the heat element height allows the fiber to be better aligned with the stripping blades. How to adjust the heater height Turning the adjustment screw on the right side of the device body will adjust the height of the heater. -
Page 19: Applicable Fiber Holder
Set Up the Stripper Applicable fiber holder Several different types of fiber holders can be used with the SS110. When using fiber holders, the fiber holder base must be set up for each type of fiber holder. be set up f... - Page 20 Set Up the Stripper Fiber Holder Adapter Installation The FH-70 series fiber holders can be used if the corresponding fiber holder adapter FH-70 is installed. FH-70 AD-SS110-FH70 Requires optional Fiber holder adapter for FH-70 accessories (optional) Remove the screws with the...
-
Page 21: Stripping Operation
Turning Power ON/OFF 1. Remove any fiber before powering on the stripper. If a fiber is on the fiber holder base when the SS110 is turned on, the fiber will hit the device body and break. 2. Slide the switch located on the right side of the device body to power on. -
Page 22: Stripping
Stripping Operation Stripping Coating residue will remain in the stripping area after operation. Remove the coating residue before the next operation. 1. Load the fiber holder onto the fiber holder base. If the appropriate mode is not selected, press and hold the F2 key to switch modes. 2. - Page 23 Stripping Operation 4. Open the top cover and fiber holder clamp cover, then remove the fiber holder from the SS110. 5. Remove and clean the coating residue from the upper and lower blades with the included brush BRS-03. SS110_Rev3...
- Page 24 Stripping Operation 6. Remove the coating residue from the heater, rubber pad, and small gaps with the opposite side of the brush BRS-03. Never leave coating residue under the fiber holder base. Always sweep toward the outside Use caution – the heater is very hot! 7.
-
Page 25: Daily Maintenance
Daily Maintenance Daily Maintenance Clean the stripper blade, the surface of the heater, and the rubber pad with the brush BRS-03 after every stripping pass. for cleaning the blades for cleaning the heater Move the Fiber Holder Base Brush BRS-03 backward using maintenance mode Clean the stripper blades Remove any coating residue from the upper and lower blades with the brush BRS-03. - Page 26 Others FCC notices (U.S. only) and other regulation information The specialty fiber stripper SS110 uses RFID technology. Typical certification or regulations are below. United States FCC FCC ID: 2A9PZ-SS110 Contains FCC ID: QOQ-BGM220S2 This device complies with part 15 of the FCC Rules. Operation is subject to the following...
- Page 27 Others Canada ISED IC: 29835-SS110 Contains IC: 5123A-BGM220S2 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 28: Warranty And Contact Address
Warranty and Contact Address Warranty Warranty period and limits If the stripper becomes out of order within one year from the date of delivery, we will repair it free of charge. However, note that repairs will be charged for the following cases regardless of the warranty period: 1. -
Page 29: Contact Address
Warranty and Contact Address Contact Address Inquiries concerning products should be made to the nearest Fujikura authorized distributor or one of the following: Fujikura Europe Ltd. C51 Barwell Business Park Leatherhead Road, Chessington, Surrey KT9 2NY, UK General inquiries: +44-20-8240-2000 Service &...
