- Page 1 SpaceLift Attic Lift Extender Package (Part No. SLAS-032)
-
Page 2: What Comes In The Box
WHAT COMES IN THE BOX Electrical Box Extender Plate 10-foot Package of extension wire 2 screws... - Page 3 Disconnect the Key Remote Plate Turn off power and unscrew the Key Remote from the housing box. Gently pull it SLIGHTLY away from housing. Do not pull cable far away from motor. New photo...
- Page 4 Disconnect the Key Remote Plate (cont.) Disconnect the cable from back of button attachment. NOTE: BE CAREFUL TO USE THE RELEASE CLIP. Make sure to keep the cable out of housing box so it can be re-clipped into the extender connector plate.
- Page 5 Put disconnected Key Remote to the side to attach to the electrical box. Keep screws to attach to extension plate.
- Page 6 Replace Key Remote Plate with supplied Extender Plate Connect cable on back of the Extender Plate NOTE: CABLE WILL BE FULLY INSERTED WHEN YOU FEEL/HEAR SNAP.
- Page 7 Replace Key Remote Plate with supplied Extender Plate (cont.) Place Extender Plate back on housing box and screw down.
- Page 8 Attaching extension wire Feed wire through the back of the electrical box and plug into the back of Key Remote. NOTE: CABLE WILL BE FULLY INSERTED WHEN YOU FEEL/HEAR SNAP.
- Page 9 Attaching Extension wire (cont.) Mount electrical box and Key remote where desired. Attach Key Remote to electrical box with supplied screws. NOTE: MAKE SURE DIRECTION BUTTONS ARE POSITIONED CORRECTLY IN PLATE. (See key remote instructions for further info) Secure the wire safely away from the lift to the box.
- Page 10 THANK YOU 203-446-4699 spaceliftproducts.com...
