Veracity LONGSPAN MAX XT VLS-LSM-CXT Quick Start Manual

Exterior long range ethernet & high power poe
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VLS-LSM-CXT
QUICKSTART GUIDE
EXTERIOR LONG RANGE ETHERNET & HIGH POWER POE
LONG
SPAN
®
MAX XT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LONGSPAN MAX XT VLS-LSM-CXT and is the answer not in the manual?

Questions and answers

Related Manuals for Veracity LONGSPAN MAX XT VLS-LSM-CXT

Summary of Contents for Veracity LONGSPAN MAX XT VLS-LSM-CXT

  • Page 1 VLS-LSM-CXT QUICKSTART GUIDE EXTERIOR LONG RANGE ETHERNET & HIGH POWER POE LONG SPAN ® MAX XT...

  • Page 2: What's In The Box

    WHAT’S IN THE BOX x 4 (1 spare) 02 | LONGSPAN MAX XT Quickstart Guide...
  • Page 3 LIST OF CONTENTS LONGSPAN Max XT Device Cable Gland Grommet - Red Enclosure: powder coated aluminium For 7.0 - 9.0mm cables Cable Gland Body Mounting Plate UV Stabilised Nylon Anodised aluminium Cable Gland Nut (with Conduit Adaptor) Screws - Mounting & Grounding UV Stabilised Nylon M4 x 8mm - DIN 933SZ - Aluminium Cable Gland O-ring - Red...
  • Page 4 Pass the POE cable through the FITTING CONNECTORS cable gland components and plug into the RJ45 socket, ensuring that it ‘clicks’ to confirm a connection. GASKET CABLE EXAMPLE CABLE Black To ensure an IP69K seal, the O-ring and correctly sized Grommet must Black 4.7 - 6.5mm Cat 5e UTP, Cat 6 UTP...
  • Page 5 Tighten the Cable Gland Body onto the threaded RJ45 port. This seals the O-ring. Tighten the gland firmly, by hand. Do not use tools for tightening. Tighten the Gland Nut onto the Body. This seals the Grommet around the cable. www.veracityglobal.com | 05...

  • Page 6: Mounting Plate

    MOUNTING PLATE Use nylon washers provided for max. corrosion resistance Mounting to flat surfaces: Mounting to poles: Maximum screw size 3.5mm (#6) Maximum band width 12.5mm (1/2”) 06 | LONGSPAN MAX XT Quickstart Guide...

  • Page 7: Mounting The Device

    MOUNTING THE DEVICE Manually adjust the mounting screws to Mount the device to the bracket to assess allow for the mounting bracket thickness. the fit. Repeat until a tight fit is achieved. In applications subject to vibration, use a light to medium threadlocker on the mounting screws.
  • Page 8 CONDUIT ADAPTOR The Conduit Adaptor section of the Cable With the POE cable connected to the device, Gland Nut is designed for use with 20mm firmly push the conduit into the Conduit Adaptor until it’s fully inserted and held securely in place. (ISO) or 1/2-inch (US) flexible conduit.

  • Page 9: Grounding The Device

    GROUNDING THE DEVICE Grounding the LONGSPAN Max XT case is generally NOT required.  Therefore the following steps can be bypassed unless grounding is specifically required due to local conditions or specifications. If grounding IS required, carry out the following steps: The grounding point is designed for use with M4 ring terminals and lugs.

  • Page 10: Dimensional Drawings

    DIMENSIONAL DRAWINGS 69 mm 113 mm 10 | LONGSPAN MAX XT Quickstart Guide...
  • Page 11 VLS-LSM-CXT POE RANGE POE REFERENCE TABLE IEEE POE POWER POE POWER POE DEVICE POWER Cat6 Cat5e CLASS STANDARD AT PSE AT PD 71 WATTS 200m (656ft) 150m (492ft) 802.3af 15.4W 12.95W 62 WATTS 235m (770ft) 180m (590ft) 802.3af 3.84W 51 WATTS 290m (950ft) 230m (754ft) 802.3af...
  • Page 12 CONNECTIONS & LEDS COMPATIBILITY LONGSPAN Max XT devices are compatible Ethernet and POE to Camera/Device with all standard LONGSPAN Base 8, 10Base-T/100Base-TX, auto speed, crossover, LONGSPAN Base and LONGSPAN Max full duplex. IEEE 802.3af/at/bt compliant. Base devices. Details of distances, and available POE FUNCTION are shown in the tables on Page 11.
  • Page 13 CONNECTIONS & LEDS LONGSPAN Link and 802.3bt POE Input FUNCTION RJ45 Green On = 100Mbps Flash = 10Mbps Off = no link RJ45 Yellow On = link Blink = activity www.veracityglobal.com | 13...
  • Page 14 POWER & ERROR LED INDICATOR The 7 Segment Power and Error LED indicators are shown here. The LED indicator for Power shows a green ‘P’ and the Error Codes show a red ‘E’ for 2 seconds before displaying the relevant number for 2 seconds and then the code repeats.
  • Page 15 See LONGSPAN Max XT Tables on Page 11 or the powered either by a POE network switch datasheet tables for distance vs power levels. or for maximum power, by a separate Veracity LONGSPAN Max XT will only deliver >25W POE to 56-57V DC power supply.

  • Page 16: Surge Protection

    This equipment generates, uses, and can radiate radio frequency energy All Veracity products have been independently tested to verify their and, if not installed and used in accordance with the instruction manual, resilience to the stringent immunity levels of international standards.
