Summary of Contents for ESKUTA 4 Series
-
Page 2: Your Model Information
YOUR SX-250 INFORMATION Your Name: Your Address: VIN No. Colour: Date of Purchase: Dealer: Dealer Address: Once you have completed the above details, then please scan and forward a copy to: contact@eskuta.com Owners Handbook... -
Page 3: Table Of Contents
SX-250. SX-250 Overview Technical Specification As you embark on this exciting adventure, we're delighted to welcome you to the Eskuta Family! Know Your SX-250 14 - 15 Maintenance & Service Checklist Adjustments and Cleaning... -
Page 4: How To Charge Your Sx-250
HOW TO CHARGE YOUR SX-250 METHOD ONE METHOD TWO 1. Insert the key into the 2. Turn to the right and 3. Turn the circuit breaker to Connect the charging unit to seat lock. the seat will pop open. off and then unplug the power this port on the rear of the cable from the battery SX-250. -
Page 5: Charging Advice
CHARGING ADVICE ABOUT CHARGING Read the user manual Before riding your SX-250 for the first time, you must carefully charge the battery for a minimum of 8 hours using the supplied charger. Do not expose the battery to a naked WARNING flame. -
Page 6: Important Battery Information
IMPORTANT BATTERY INFORMATION – PLEASE READ! To ensure that you maximise the performance of your battery, we would like to provide you with some instructions on how to use it properly. Following these guidelines will help you to extend the life of your battery and optimise its performance. WHEN YOU RECEIVE YOUR SX-250 Upon receiving your SX-250, you MUST charge the battery fully before using it. -
Page 7: How To Ride Your Sx-250
HOW TO RIDE YOUR SX-250 2. The display will light 1. Put the key in the 3. Press the right brake 4. The speedometer will up when your SX-250 is ignition and turn it to to go into ride mode appear on your dashboard successfully turned on the right... -
Page 8: Features
SX-250 FEATURES LIGHTS HORN Press the black horn button to sound the horn. KEY FOB 1. Flick the switch to the 2. Flick the switch up to DISARM left to turn on the headlight turn on your full beam Press once to disarm and tail light. -
Page 9: Fault Finding & Help
FAULT FINDING & HELP DESCRIPTION OF MALFUNCTION ANALYSIS OF MALFUNCTION WAY OF ELIMINATING Screen does not light up when ignition is (1) Low voltage of battery (1) Charge the battery (2) turn switched on with key (2) Circuit breaker not in ‘on’ position to ‘on’... -
Page 10: Be A Responsible Owner
Fitting a child seat or trailer is not recommended, as it will invalidate the warranty. The SX-250 should not be used with indoor trainers or rollers. This Eskuta SX-250 complies with EN 15194 and may only be used by competent riders aged 14 years and over. The motor assistance is limited to a maximum continuous power rating of 250 W and a maximum speed of 25km/h (15.5 mph). - Page 11 Your SX-250 has a maximum weight limit of 120kg, including the rider and any cargo. Use cargo accessories designed for your SX-250 and obtained from Eskuta or authorized distributors. Utilize storage compartments on your SX-250 when possible. Ensure even weight distribution on both sides to prevent imbalance and instability.
-
Page 12: Sx-250 Overview
SX-250 OVERVIEW Built in ‘Walk-mode’ mirrors allows the SX-250 48V 26Ah Lithium-ion Battery to be powered Up to 50 miles range*. Can be charged when without pedalling installed or when removed from the SX-250 up to 4 mph LED indicators LED brake &... -
Page 13: Technical Specification
TECHNICAL SPECIFICATION Waterproof Model No. SX-250 IP65 Level Shock Absorber Fr. Hydraulic Telescopic with Spring & Rr. Gas Classification/Category EPAC - Electrically power-assisted cycle Front/Rear spring - self adjusting Brakes High performance Disc Brakes Certification CE Mark - EN 15194:2017 Dimension (LxWxH) 1670 X 750 X 1080mm Tyres... -
Page 14: Know Your Sx-250
KNOW YOUR SX-250 Headlight Glove Box Front Fork Front Fender Front Disc Break Pedal Side Stand Rear Footrest Centre Stand Rear Disc Brake Brushless Hub Motor Rear Fender Rear Shock Absorber Charging Port Tail Light Saddle Mirror Ignition Owners Handbook... - Page 15 KNOW YOUR SX-250 Brake levers Distant/Dipped Headlight Switch Tail light/ Headlight Switch Horn Speedometer Owners Handbook...
-
Page 16: Maintenance & Service Checklist
Grease bottom brackets PARTS Tighten headset Tighten handle bars A full range of parts are available directly from Eskuta or one of our resellers. Please give us a call on 02476 350150 with Tighten rear brake any requirements. Replace chain... -
Page 17: Adjustments And Cleaning
ADJUSTMENTS & CLEANING ADJUSTMENT OF BRAKES Loosen the brake wire locking screw. Turn adjusting screw so that the wheel turns freely when the brake lever is not held. Tighten the brake wire locking screw. Ensure that the brake is fully applied when pulling the brake lever at least 20mm before it touches the handlebar. If not, re-adjust brake. ADJUSTMENT OF CHAIN TIGHTNESS Loose the nut of back shaft. -
Page 18: Warranty
Eskuta reseller subject to the following terms and limitations determines are affected by such disassembly. THE PERIOD OF WARRANTY for Eskuta e-bikes shall be one (1) year from the date of THE CUSTOMER’S RESPONSIBILITY under this warranty shall be to: - purchase, with an 8,000-kilometre limitation. -
Page 19: Declaration Of Conformity
The maximum continuous rated power is 250W The maximum permissible total weight is 120kg Signature: Name: Ian O’Connor ESKUTA LIMITED. UNIT 10 BERMUDA INNOVATION CENTRE, ST DAVID’S WAY BERMUDA PARK, NUNEATON, WARWICKSHIRE. CV10 7SD. ENGLAND. Position: Managing Director Dated: 15/10/2023... - Page 20 Eskuta Limited Email: contact@eskuta.com Phone: 02476 350150 Unit 5 Bermuda Innovation Centre, St David’s Way, Bermuda Park, Nuneaton, Warwickshire, CV10 7SD...
