- Page 1 User’s Manual INCU-LT series Premium Low Temperature Incubator This Manual applies to: INCU-LT Series Models: INCU-160LT, INCU-270LT and INCU-430LT.
- Page 2 SciQuip INCU-LT Series V2016.1.1 Thanks ! Thank you very much for purchasing one of our INCU-LT Series premium low temperature incubator, especially designed for you-the lab professional. Your choice indicates that you have very high requirements on style and performance of this type of incubators.
- Page 3 SciQuip INCU-LT Series V2016.1.1 Safety instruction! Please be sure to follow the instructions, they are really important for your safety. Danger! Warning against damage and injury. 1. The electrical supply circuit to the incubator must confirm to all national and local electric codes.
- Page 4 SciQuip INCU-LT Series V2016.1.1 Attention! Instructions for optimal performance 1. The unit must be placed vertically on a solid, flat floor or table. 2. The incubator needs even heat lost on all surfaces in order to maintain small internal temperature variations. As a result, a minimum of 20 cm must be allowed between the rear and sides of the incubator and any walls, partitions or obstructions to facilitate adequate convection of air around the unit.
-
Page 5: Table Of Contents
SciQuip INCU-LT Series V2016.1.1 Table of contents Performance Parameters Technical Specifications Preparation and Start-up Home Page Operation Set Page Settings Control Mode—Control Mode Settings Fixed Value Parameter—Fixed Value Mode Settings Programmable Parameters—Programmable Mode Settings P.I.D—P.I.D. Control Settings (Factory Default) Alarm—Alarm Settings Temperature Corrections (Factory Default) Clock—Clock Settings... -
Page 6: Performance Parameters
A magnetic gasket on the outer door helps to insure a tight seal against the cabinet. A double-layered observation window comes as standard on every INCU-LT Series Incubator. 2 grid shelves, 50mm test port and built-in printer on the side wall as standard, UV light as... -
Page 7: Technical Specifications
SciQuip INCU-LT Series V2016.1.1 2. Technical Specification Model INCU-160LT INCU-270LT INCU-430LT Volume (L) 4.3’’ LCD Touch Screen Control Panel Door type Highly-Insulated Single Door Grids no. Temperature Range (°C) -10-65 Temperature ±0.1 Accuracy (°C) Temperature ±0.5@37 Uniformity (°C) Working Temperature(°C) -
Page 8: Preparation And Start-Up
SciQuip INCU-LT Series V2016.1.1 3. Preparation and Start-up n and Clean the incubator before you put it into use and on a regular base. The interior should be wiped down with an appropriate disinfectant, such as 70 % ISOPROPYL ALCOHOL or equivalent. - Page 9 SciQuip INCU-LT Series V2016.1.1 “Timer Set Value”: It displays the current set timer value; “Set” Button: (See Chapter 5) Press this button to enter the “Set” Page; “Actual Running Time”: It displays the current running time. “Alarm” Status: Once the conditions of alarms are fulfilled, the alarm is declared, and indicator will be lighted.
-
Page 10: Set
SciQuip INCU-LT Series V2016.1.1 5. Set Page Settings Control Mode-- Control Mode Settings (See Chapter 6) Press it to enter the page and set control mode, and other functions, such as, temperature holding (programmable mode use only), cooling control, power recovery, door switch and print. -
Page 11: Control Mode-Control Mode Settings
SciQuip INCU-LT Series V2016.1.1 Defrost Setting—Auto Defrosting Cycle Settings (See Chapter 14) Press it to enter the page of setting defrosting cycle parameters. Quit—“Quit” Button Press it to exit the current page after all settings are finished. 6. Control Mode-- Control Mode Settings MODE—Control Mode Set... -
Page 12: Fixed Value Parameter-Fixed Value Mode Settings
SciQuip INCU-LT Series V2016.1.1 NRUN—Power Recovery Switch This function will enable or disable the non-volatile running to retain all set points when power interruption occurs. DOOR—Door Switch This function will enable or disable the door switch. Enable this function to automatically switch off the main heater when door is opened. -
Page 13: Programmable Parameters-Programmable Mode Settings
SciQuip INCU-LT Series V2016.1.1 8. Programmable Parameters—Programmable Mode Settings This new incubator can operate according to stored program to meet various requirements of professional experiments. Under programmable control mode, it is possible to program up to9 different segments, each with their own Ramp Time, Ramp End Temperature, Hold Time and Speed. - Page 14 SciQuip INCU-LT Series V2016.1.1 Hold Deviation—Hold Deviation Temperature This function indicates the temperature deviation that the incubator may have at the end of each” Ramp Time” before starting the “Hold Time”. In another word, the difference between actual temperature and desired “Ramp End Temperature”, this activates the “Hold Time”.
-
Page 15: P.i.d-P.i.d. Control Settings (Factory Default)
SciQuip INCU-LT Series V2016.1.1 9. P.I.D—P.I.D. Control Settings (Factory Default) P.I.D Control Settings Press the parameter button and use the keyboard to set the value, and then press “OK” to confirm and save. BACK—“Back” Button Press it to exit the current page after all settings are finished. -
Page 16: Alarm-Alarm Settings
SciQuip INCU-LT Series V2016.1.1 Alarm—Alarm Settings Deviation Alarm—Alarm Deviation Temperature This value determines the maximum deviation, measured in temperature (℃), which the chamber is permitted above/below once the incubator reaches the specified set point before an alarm condition is declared. Use the keyboard to enter and press “OK” to confirm and save. -
Page 17: Temperature Corrections (Factory Default)
SciQuip INCU-LT Series V2016.1.1 Temperature Corrections (Factory Default) Attention: 1. The unit is delivered with calibration done in the factory, so please perform the corrections only if necessary. 2. This may only be performed by an authorized engineer with certified equipment. -
Page 18: Clock-Clock Settings
SciQuip INCU-LT Series V2016.1.1 Clock—Clock Settings Clock Settings Press the display box and use the keyboard to set date and clock, and then press “OK” to confirm and save. BACK—“Back” Button Press it to exit the current page after all settings are finished. -
Page 19: Defrost Setting-Auto Defrosting Cycle Settings
SciQuip INCU-LT Series V2016.1.1 Defrost Setting—Auto Defrosting Cycle Settings This unit is equipped with automatic and manual defrosting functions. For automatic defrost, it is effective only when setting temperature value is lower than 10℃.The unit will run auto defrosting cycle according to the following two parameters settings, Defrost Timer—Auto Defrost Cycle... -
Page 20: Temperature Calibrations (Factory Default)
SciQuip INCU-LT Series V2016.1.1 Attention: The cooling system keeps running during defrosting cycle, while the motor fan stops. The temperature will silently overshoot during defrosting, and then be stabilized when defrosting terminates. For better temperature control during continuous low temperature operations, for example, below 10.0°C, the following operations are... -
Page 21: Electronic Control System
SciQuip INCU-LT Series V2016.1.1 Electronic Control System .Operat Trouble Shootings If there is a need to access the (top) control panel, use an Allen wrench of 6mm (Included). Push the Allen screw in and turn at the same time. The cover will be raised a little – enough to lift it and take it out. - Page 22 SciQuip INCU-LT Series V2016.1.1 broken specification 4. Malfunction of power Notify distributor to repair the unit. box circuit occurs 1.Unit Keep waiting and observe for a reached required while Incubator temperature (constant) temperature alarm 2. Setting of the alarm Refer to the operating procedure parameter is wrong.
