- Page 1 OPERATING MANUAL Incubator VSI-120 / VIS-180 / VIS-260...
- Page 2 Congratulations! You have made an excellent choice. VACC-SAFE thanks you for the trust you have placed in us. This operating manual has been designed to help you gain an understanding of the operation and possible applications of our instruments. For optimal utilization of all functions, we recommend that you thoroughly study this manual prior to beginning operation.
-
Page 3: Table Of Contents
VACC-SAFE CO Incubator Important: keep operating manual for future use CONTENTS 1. Safety and general precaution ..................5 1.1. General information on precaution ..............5 1.2. Precaution for using the power cable ..............6 1.3. Precaution for ground connection ..............6 1.4. - Page 4 8.2. RS-485 interface....................24 9. Optional function ......................26 9.1. Printer ......................26 10. Service and Check Point....................26 11. Troubleshooting ......................26...
-
Page 5: Safety And General Precaution
VACC-SAFE CO Incubator 1. Safety and general precaution 1.1. General information on precaution Precaution is to prevent the possible accident or danger during operation. So, you must keep Precaution is divided into caution and warning. And, each of them has following meanings. -
Page 6: Precaution For Using The Power Cable
1.2. Precaution for using the power cable Do not make the power plug be pressed by back of the product. (A space between the product and the plug must be 30cm at least.) The power outlet must be only for this product. (Using various products simultaneously can cause a fire) Clean the power plug with a dry towel and connect it properly. -
Page 7: Precaution For Use
VACC-SAFE CO Incubator 1.4. Precaution for use You must not disassemble, fix and remodel the product by yourself. (You can damage the product throughout a fire and malfunction or get a property loss as well as experimental loss. Do not use the product for different purpose. -
Page 8: Transportation, Storage And Location Of Installation
2. Transportation, storage and location of installation 2.1. Transportation DO NOT try to slide or tilt the unit Lift the unit at its four lower corners with the aid of 2 people. Permissible ambient temperature range for transport: -10℃ to 60℃. 2.2. -
Page 9: Location Of Installation And Ambient Conditions
VACC-SAFE CO Incubator 2.3. Location of installation and ambient conditions Do not put inflammable substances near the product. (It can cause a fire) When you install the product, you have to put the distance of at least 30cm from the wall. To completely separate the unit from the power supply, power plug must be disconnected. -
Page 10: Prerequisite And Configuration
When you have received the instrument which is packed on pallet, inspect the box carefully for any damages that may have caused any damages to product during shipping. Please report any damage to the carrier or to your local VACC-SAFE distributor. LOCATION The incubator is designed to operate at temperature 5℃... -
Page 11: Configuration
VACC-SAFE CO Incubator 3.2. Configuration Exterior Configuration of CO incubator Air jacket-6 side direct heating Outer door Ventilation fan Magnetic door seal Glass door heater-Prevent condensation Power switch Stainless steel shelve- Perforated to improve Control panel Inner door seal- Airtight to prevent CO... -
Page 12: Features And Specifications Of The Unit
4. Features and specifications of the unit 4.1. Features 1. Excellent Uniformity of Temperature, CO 2. 6 Sides Direct Heat for Temperature Uniformity and Fast Recovery. 3. IR CO Sensor detects precise density of CO 4. Outer Heated Door ensures no condensation on glass door. 5. -
Page 13: Specification
VACC-SAFE CO Incubator 4.2. Specification Items VIS-120 VIS-180 VIS-180E VIS-260 Temperature Range Ambient +5 C to 60 Accuracy ±0.1 C at 37 Uniformity at 37 C / RT 25 C ±0.3 ±0.3 ±0.3 ±0.4 Inlet pressure range 0.3~0.5bar 0.3~0.5bar 0.3~0.5bar 0.3~0.5bar... -
Page 14: Control Panel
5. Control Panel Heating Signal: To show status of heating activation at 3 parts where is controlled by 3 each sensor. Glass door means the heater around glass door. Temperature Display LED window. Temperature set button. Set temperature display. Gas Setting Button. Gas percentage in Chamber。... -
Page 15: Operation
VACC-SAFE CO Incubator 6. Operation Before Switch ON, insert water tray filling with distilled water (If necessary). Make sure connection of gas supply. And Open CO gas cylinder or supply with the pressure of regulator set to 4.5~7.25Psi or 0.3~0.5 bar. -
Page 16: Calibration Of Temperature & Co
6.4. Calibration of temperature & CO Please follow up the procedure for calibration below in case of discrepancy between actual value (measured by reliable thermometer or device) in chamber and displayed value. Conduct the analysis of CO density and Temperature when incubator has been stabilized for more than 2 hours. -
Page 17: Alarm
Push UP ( ▲ ) and DOWN ( ▼ ) to adjust CO % display. Before release of CO incubator from VACC-SAFE factory, CO density is calibrated optimizing at 5%. When using different density ofCO rather than 5%, this calibration is highly recommendable. -
Page 18: Water Tray
than 3 minutes. If CO₂ deviation is more than ±1% from set point for about 3 minutes, alarm starts ringing. So, CO₂ alarm tolerance delay is about 3 minutes. Door Open The outer door is open for longer than one minute. *When pressing the alarm mute button on the control panel will stop the alarm from activating. - Page 19 VACC-SAFE CO Incubator 2. Seal access port with full silicon stopper (Use complete stopper without drilling hole.) 3. Empty the chamber except shelves and rack. Water trays can be left in, but without water. 4. Clean the inside of the chamber and dry thoroughly. Before starting this program, set the desired end temperature and CO2% values.
-
Page 20: Uv Decontamination
(& CAL/SET) which directed as CLEAN MODE. At the same time long press two buttons to enter the dry heat sterilization process The display should indicate the following: Figure 2: Display of the incubator indicating sterilization cycle “CLEAN” is shown in temperature display and 600 is shown in CO₂ LED Window. CLEAN means the HOT AIR Decontamination program is now activated. - Page 21 VACC-SAFE CO Incubator Circulation Fan UV Light If UV needed to be exposed to entire chamber, follow the procedure below. Find the bolt which holding the ceiling. That is in circle in below photo. Unscrew this bolt with supporting the ceiling by another hand so the ceiling will not fall down.
- Page 22 edge of ceiling up and put two holes into its hook. Then, lift the front of ceiling up and screw up the Nut. When inserting the ceiling, it should be going under the part bended (marked with red squire#1) until that part end.
-
Page 23: Safety Switch
VACC-SAFE CO Incubator 7. Safety Switch It is the safety device to prevent the heater from overheating, when the temperature controller is malfunctioning. Set the Safety S/W higher than setting point. The Safety S/W has wide deviation. Safety S/W is the safety device for preventing the heater to overheat when TEMPCONTROL is malfunctioning. -
Page 24: Rs-232 Interface
8.1. RS-232 interface The RS-232 interface uses automatic identification. Parameter settings are as follows: Baud: 4800~19200 bits/second Data bits: 8 Stop bits:1 Handshake: None Parity: None List of commands Item Input / output Content of "#" Remarks Set the equipment parameters out_sp_00 #### Decimal number Unit:0.01℃... - Page 25 VACC-SAFE CO Incubator write Read and 40004 Set CO density CO Unit:0.1% write 0: Null Read and 40005 Audible alarm 1: activate write Input register Register address Explanation Data type Remark Read or write (DEC.) Current chamber 30001 Unit:0.01℃ Read...
- Page 26 CO Config the printer Please contact Vacc-Safe or authorized service provider 10. Service and Check Point WARNING: Technical service should only be performed by qualified service personnel.
- Page 27 Solenoid valve defective. Replace solenoid valve value. Humidity Condensations inside Fan defective Replace the fan. (contact VACC-SAFE service) chamber Improper temperature Condensation Increase value door heating distribution b/w the door and on the door temperature.
