Automotive Integrated Electronics USBCDPLAY1 Installation Instructions

INSTALLATION INSTRUCTIONS
(USB CD PLAYER-PROPER POSITIONING)
THIS SECTION WILL COVER THE PROPER MOUNTING ORIENTATION/POSITION
AND ANGLE OF YOUR NEW CD PLAYER. THE UNIT MUST BE AFFIXED TO A SOLID
SURFACE VIA THE PROVIDED ADHESIVE PAD . PLEASE FOLLOW THESE
PRECISELY TO ENSURE PROPER FUNCTIONALITY AND FITMENT.
**FAILURE TO COMPLY VOID WARRANTY, CAUSE DAMAGE TO THE[
UNIT AND CREATE IMPROPER PERFORMANCE AND SOUNDS**
WHEN CHOOSING A PROPER LOCATION FOR YOUR CD PLAYER, YOU MUST ENSURE THAT THE UNIT WILL BE
STEP 1
FREE FROM DUST, EXCESSIVE VIBRATIONS OR ERRATIC ENVIRONMENTS SUCH AS EXTREME HEAT FROM IN-VEHICLE
COMPONENTS (HEATER VENTS ETC.)
STEP 2
ONCE CHOSEN, MAKE SURE THE MOUNTING POSITION IS WITHIN COMPLIANCE AS REQUIRED BY THE
MANUFACTURER. THIS IS AS FOLLOWS:
HORIZONTAL POSITION
(CORRECT)
VERTICAL POSITION
(CORRECT)
MOUNTED UPSIDE
DOWN
[
INSTALL POSITIONING ***CORRECT***
HORIZONTAL POSITION IS DEFINED AS CD SLOT BEING ON THE
TOP SIDE OF THE UNIT WITH THE ARROW PORTION OF THE EJECT
BUTTON POINTING UP
() ®
GOOD
VERTIC AL POSITION IS DEFINED AS CD
SLOT FACING UP UNIT ANGLED
NO GREATER THAN ZERO DEGREES
(PERFECTLY STRAIGHT & UPRIGHT)
THE MOUNTED ANGLE MUST **NOT**
EXCEED PAST ZERO DEGREES TO
AVOID DAMAGE/ABUSE TO THE UNIT AND
CAUSE UNIT TO POSSIBLY
MAKE IMPROPER FUNCTIONING SOUNDS.
INSTALL POSITIONING ***NOT CORRECT***
MOUNTED ON
EITHER SIDE
0
©9
BAD
ANGLE LESS THAN ZERO
(SIGNIFIED BY DISC LABEL UPSIDE DOWN)
CD
e
@ - � ---------1)
t---
LABEL SIDE
ANY ANGLE
ZERO TO 90 DEGREES
(CORRECT)
DEGREE
CD
&
