  • Page 1 DS1000 Installation Guide DS1000 Installation Guide...

  • Page 2: Table Of Contents

    T T able of Contents able of Contents DS1000 Installation Guide DS1000 Installation Guide ....................................1 1 Pr Preface eface ....................................................2 2 DS1000 Pr DS1000 Product Ov oduct Over erview view ....................................4 4 P P ower Supply Unit (PSU) ower Supply Unit (PSU) ....................
  • Page 3 Installation Guide Disclaimer Copyright © 2024 by Celestica. All Rights Reserved. The term “Celestica” refers to Celestica Inc. and/or its subsidiaries. For more information, go to www.Celestica.com. All trademarks, trade names, service marks, and logos referenced herein belong to their respective companies.

  • Page 4: Pr Preface Eface

    Pr Preface eface This guide covers the installation and basic setup of the DS1000 Ethernet switch. Every effort has been made to ensure the accuracy and validity of this guide. Any updates of this guide are subject to change without notice.
  • Page 5 T T ype Gener Generaliz alized Definition ed Definition Indicates a hazardous situation that if not D D ANGER: ANGER:   avoided, will result in death or serious injury.

  • Page 6: Ds1000 Pr Ds1000 Product Ov Oduct Over Erview View

    This document describes the general hardware design of the DS1000 Ethernet switch. An Open Compute Project (OCP) accepted design, the DS1000 Ethernet switch offers 48 x 10/ 100/1000Mbps RJ45 ports and 8 SFP+ ports within a 1U form factor.
  • Page 7 Users can specify different bandwidths for voice/data/video to customize different qualities of service. MPLS Ready MPLS Ready DS1000 supports LDP and MPLS VPN which can be used in metropolitan area networks and wide area networks. Features ▪ 1U Form factor ▪...
  • Page 8 T T able 1. able 1.Network Standar Network Standards, Pr ds, Prot otocols, and Inter ocols, and Interfaces faces DS1000 DS1000 Suppor Supported T ted Technologies echnologies Standards 802.1d/w/s, 802.1Q, 802.1p, 802.3ad, 802.3x, GVRP, DHCP and SNTP Protocols IGMP, DVMRP and PIMRIPv1/2, OSPF and...

  • Page 9: P P Ower Supply Unit (Psu) Ower Supply Unit (Psu)

    P P ower Supply Unit (PSU) ower Supply Unit (PSU) There are two PSUs in the DS1000 Ethernet switch supporting two airflow options: Front-to-Back (F2B) and Back-to-Front (B2F). Each PSU's maximum output power is 550W with an output voltage of 12VDC +/- 5%. Each PSU includes a fan and a handle at the back of the power supply to support hot plug pull-out and insertion.

  • Page 10: Saf Safety Pr Ety Precautions Ecautions

    The laser may hurt and/or damage your eyes. ▪ Do not install, move or open the DS1000 or its modules when the device is connected to power. Doing so may damage equipment and cause serious burns to skin.

  • Page 11: P P Ower Ower

    P P ower ower Depending on the type of power system your device has, the following symbols may be used. On - On - Connects power to the system. This can be AC or DC power depending on product and model. Off - Off - Disconnects power to the system.
  • Page 12 NOTE:   This symbol is used when multiple power supplies are installed in a system. This warning label is typically found on the back of the device near the PSU. Power Connection Installation of this equipment must comply with local and regional electrical regulations governing the installation of information technology equipment by licensed electricians.

  • Page 13: Envir Environmental Requir Onmental Requirements Ements

    Dust and Par articles ticles Dust is harmful to the operation of the DS1000. Dust may lead to electrostatic adherence, especially under low relative humidity, resulting in poor contact of metal connectors or contacts. Electrostatic adherence may result in reduced product lifespan and increased chance of communication failures.
  • Page 14 Humidity e and Humidity Although DS1000 is designed to use multiple internal fans, the site should still maintain appropriate temperature and humidity. High-humidity conditions may cause increased electrical resistance and degradation of mechanical properties and corrosion of internal components.

  • Page 15: Envir Environmental Requir Onmental Requirements T Ements Tables Ables

    T T emper emperatur ature (airflow back t e (airflow back to fr o front): ont): Relativ Relative Humidity e Humidity Long-term Long-term Shor Short-term t-term Long-term Long-term Shor Short-term t-term condition condition condition condition condition condition condition condition 5 ~ 40°C 0 ~ 45°C 40 ~ 60% 5 ~ 90%...

  • Page 16: Regulat Regulator Ory Information Y Information

    Any modifications made to this device that are not approved by Celestica may void NOTE:  ...
  • Page 17 In accordance with European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), the presence of the above symbol on the product or on its packaging indicates that this item must not be disposed of in the normal unsorted municipal waste stream. Instead, it is the user's responsibility to dispose of this product by returning it to a collection point designated for the recycling of electrical and electronic equipment waste.

  • Page 18: Chassis Installation

    Chassis Installation Chassis Installation DS1000 is designed to be installed in a standard 19'' square hole, four post rack. The bracket kit is only for 19 inch (483mm) wide, standard square hole racks, with a depth ranging from 22 inches ~ 33.5 inches (558mm ~ 850mm) as measured from rack post to rack post. This chapter covers the tools and procedures necessary to correctly and safely install the DS1000 Ethernet switch.

  • Page 19: Installing The Chassis

      on the rack must be deployed. If a standard 19'' rack is not available, DS1000 can be placed on a clean, stable, and level surface. Leave a clearance of 100mm (~4 inches) around the chassis for ventilation. Do not place anything on top of the chassis.
  • Page 20 NOTE: The following illustrations may display a different product. However, the installation   process is universal to all Celestica rack-mountable products. Pr Procedur ocedure e 1 1 Attach the two outer brackets with M4 screws provided in the accessory kit.
  • Page 21 Figur Figure 4. e 4. Secur Secure Br e Brack acket t et to Chassis o Chassis Figur Figure 5. e 5. Inner Rail Br Inner Rail Brack acket Installed t et Installed to Chassis o Chassis 4 4 Push the chassis with the outer bracket locked in step 1 above from the front side by one person, and push the inner bracket into the outer brackets (sleeve) slot on the chassis...
  • Page 22 from the rear side by another person at the same time, until guide pin (detail 1) and inner bracket guide pin (detail 3) fit in rack square holes. Then, lock them with M6 screws (PH#3 slotted screwdriver). 5 5 Press chassis and inner bracket until M6 screws fully lock. 6 6 Save enough space around the switch for good air circulation.

  • Page 23: Contact Information

    Customers can register and request support (as well as search information in the knowledge base) at:https://customersupport.celestica.com/csm In case there are any questions or issues using the customer portal visit: https://www.celestica.com/contact-us. For immediate questions, please feel free to call your responsible account manager.
