- Page 1 SafeAir M-350 Pro (ASTM F3322-22 Compliant*) INSTALLATION GUIDE * Pending...
-
Page 2: Table Of Contents
OPERATING GUIDELINES ....................24 Preflight ............................. 24 Takeoff .............................. 24 Before Landing ..........................24 After Landing ........................... 25 FTS Test (for RC equipped systems) ....................25 DEPLOYMENT ........................27 General ............................27 Repacking the parachute ......................27 SafeAir™ M-350 Pro Installation Guide https://parazero.com/... - Page 3 Important Notice ParaZero’s SafeAir M-350 Pro (ASTM F3322-22 compliant) is a drone safety system that mitigates operational risk and aims to lower potential ground impact kinetic energy during proper use. ParaZero’s drone safety system is not intended to eliminate all damages to people or property and ParaZero cannot guarantee this. ParaZero’s drone safety system is a ballistic parachute system that uses a pyrotechnic component to instigate parachute deployment.
-
Page 4: General Information
• Not to connect the TerminateAir to the SmartAir The ParaZero SafeAir M-350 Pro is smart-parachute system that deploys autonomously after detecting a critical failure in your drone. When deployed, the parachute slows the descent rate of your drone and reduces the potential ground impact kinetic energy. The system... -
Page 5: Technical Specifications
The first periodic maintenance schedule is set for two years from the manufacturing date and appears printed on the system itself and on its box. The maintenance should be performed by ParaZero or a designated, certified agent. For more information, please contact support@parazero.com. -
Page 6: Safety Instructions
Do not remove the safety pin until specifically instructed to do so in this guide. This manual explains how the SafeAir M-350 Pro works and how to properly operate the system on the ground and in the air. Be sure to take the time to read this manual carefully in order to increase your safety and the safety of those around you. -
Page 7: Package Contents
Package Contents The SafeAir M-350 Pro package includes the following parts: Table 1 – SafeAir M-350 Pro Package Contents Description The main bracket, including the canister plus rubber band, the SmartAir Pro (SAP) with a safety pin and pyro dummy... -
Page 8: Smartair Connectors Overview
(optional Vin & PWM) C – USB-C connector D – Parachute cable connector E – RGB LED F – Inner buzzer G – External antenna connector (some models) H – System button (advanced users) SafeAir™ M-350 Pro Installation Guide https://parazero.com/... -
Page 9: Installation
Optional – connect external antenna to the SAP and secure it to the drone’s leg, in such a way that it won’t interfere with the drone or its sensors SafeAir™ M-350 Pro Installation Guide https://parazero.com/... -
Page 10: Connecting The Electronic Terminateair
Use the provided large Allen key to unscrew and remove the battery locker. Keep the battery locker and its parts in a safe location Screw the TerminateAir locker, do not use any washers until secured, remove adhesive tape SafeAir™ M-350 Pro Installation Guide https://parazero.com/... - Page 11 For storage purposes, bend the TerminateAir locker downwards while in the locked position, be aware that it could only be bent to one position, rotate it by 180 degrees if necessary SafeAir™ M-350 Pro Installation Guide https://parazero.com/...
-
Page 12: Flight Preparations
Use the pyro-dummy connected instead of the parachute cable for the SAP during initialization process. Warning Please disconnect FTS and parachute cables from the SmartAir to prevent inadvertent activation during the firmware update process Perform the self-test assessment found here SafeAir™ M-350 Pro Installation Guide https://parazero.com/... -
Page 13: Inserting The Pyro Actuator
Insert the pyro-actuator into the socket in the bottom of the container, ensuring that you insert completely to the end of the connection point. SafeAir™ M-350 Pro Installation Guide https://parazero.com/... -
Page 14: Inserting The Parachute
DJI M350 RTK arms by wrapping the string around each arm and inserting one end into the string’s loop and tightening it as shown in photo SafeAir™ M-350 Pro Installation Guide https://parazero.com/... - Page 15 TerminateAir. The strings should not obstruct the DJI M350 RTK sensors nor propellers. strings should climb in a straight line from the conduit and upwards, as indicated in image circled in red SafeAir™ M-350 Pro Installation Guide https://parazero.com/...
-
Page 16: Remote Controller (Optional)
Remote Controller (optional) Follow the correct model of your RC. 6.1 RC 1.0 System Ports & Switches Lanyard hole Trigger switch Power switch Charging port Belt clip SafeAir™ M-350 Pro Installation Guide https://parazero.com/... -
Page 17: Rc 1.0 System Status And Troubleshooting
6.3 RC 1.0 System Specifications • Range – 1 km or line sight • Battery capacity – 1.5 hours • Frequency – 868 MHz or 915 MHz, depending on region • Video deployment example SafeAir™ M-350 Pro Installation Guide https://parazero.com/... -
Page 18: Rc 2.0 System Ports & Switches
6.4 RC 2.0 System Ports & Switches SafeAir™ M-350 Pro Installation Guide https://parazero.com/... -
Page 19: Rc 2.0 Main Screen Messages
Indicates which system is paired to SafeAir Mavic EU SafeAir the RC. It’s possible to assign the tail SafeAir Phantom EU number for the SafeAir system via system SafeAir System the desktop application. Tail number SafeAir™ M-350 Pro Installation Guide https://parazero.com/... - Page 20 System is connected to a power source ⑧ Current 0000.0 m The current altitude relative to the SafeAir takeoff point. The display only Altitude updates when the system is armed. Refresh interval may vary. SafeAir™ M-350 Pro Installation Guide https://parazero.com/...
-
Page 21: Rc 2.0 Idle Screen
6.8 RC 2.0 System Specifications • Range – 1 km or line sight • Battery capacity – 1.5 hours • Frequency – 868 MHz or 9125 MHz, depending on region • Video deployment example SafeAir™ M-350 Pro Installation Guide https://parazero.com/... -
Page 22: System Led Indications
System LED indications Stage Buzzer Indication Required action Alternating System didn’t sync Connect system to ParaZero Purple/Teal with app for a long Desktop App to sync logs and time check for updates System battery is not Charging the system is... - Page 23 (*) ParaZero Remote Controller (RC) is an optional add-on and provides manual triggering capability. The LED indication is applicable for RC equipped systems. SafeAir™ M-350 Pro Installation Guide...
-
Page 24: Operating Guidelines
Operating Guidelines 8.1 Preflight Initial Conditions: The safety pin is in. Finalize all preflight procedures to your drone and payload. The following tasks are included in addition to the regular preflight tasks – • Ensure that the thumb screws and the mounting legs screws are firmly closed. •... -
Page 25: After Landing
Test Motor-Cut Close menu Select “Test Motor-cut” using the middle button Approve motor-cut test Scroll down using downward facing arrow button to “OK” and long press ->Long Press<- the middle button to select Cancel SafeAir™ M-350 Pro Installation Guide https://parazero.com/... - Page 26 SmartAir LED should be BLUE and the RC 2.0 should display the Idle Screen Warning If the FTS test is not satisfactory, do not use the SafeAir system and contact ParaZero support at support@parazero.com SafeAir™ M-350 Pro Installation Guide https://parazero.com/...
-
Page 27: Deployment
9.1 General For professional operators that comply with ASTM F3322-22 and are intended for flight over people, parachutes must be packed and repacked by ParaZero (or by an entity that has been certified and designated by ParaZero). The SafeAir M-350 Pro includes an Autonomous Triggering System (ATS) that identifies most of the known critical failures and triggers the system autonomously. - Page 28 Start the folding process from one end and use weights to keep the parachute depressed and folded, as you move along the length of the parachute. SafeAir™ M-350 Pro Installation Guide https://parazero.com/...
- Page 29 Do not fold the rubber band, it is supposed to be rather loose. For any doubts, contact support@parazero.com Placing the parachute inside the canister necessitates the folded parachute, the yellow cap, the red base, and a new pyro actuator: Remove the used pyro-actuator from the socket in the bottom of canister.
- Page 30 Operate Drones Everywhere, Safely Telephone: +972-36885252 Email: support@parazero.com Address: 30 Dov Hoz St. Kiryat Ono, Israel 5555626 https://parazero.com/...
