- Page 1 SafeAir M-30 ASTM F3322-18 Compliant* USER MANUAL *Pending...
-
Page 2: Table Of Contents
8.3 Before Landing ....................20 8.4 After Landing ...................... 21 8.5 FTS Test (for RC equipped systems) ..............21 DEPLOYMENT ..................23 9.1 General ....................... 23 9.2 Repacking the parachute ................23 CE AND FCC COMPLIANCE INFORMATION ........26 SafeAir™ M-30 Installation Guide https://parazero.com/... - Page 3 ParaZero’s drone safety system is not intended to eliminate all damages to people or property and ParaZero cannot guarantee this or hold any liability of any type. ParaZero’s SafeAir M-30 Pro is a parachute system that uses a spring- based, ballistic deployment mechanism to instigate parachute deployment. Please note, you must read, comply with, and apply all written information in this manual.
-
Page 4: General Information
• The CSC function (Combination Stick Command) is not supported The ParaZero SafeAir M-30 Pro is a smart-parachute system that deploys autonomously after detecting a critical failure in your drone. When deployed, the parachute slows the descent rate of your drone and reduces the potential ground impact kinetic energy. The system... -
Page 5: Technical Specifications
The first periodic maintenance schedule is set for once a year from the manufacturing date and appears printed on the system itself and on its box. The maintenance should be performed by ParaZero, or a designated certified agent. For more information, please contact support@parazero.com. -
Page 6: Safety Instructions
Follow the instructions in this guide in the exact order in which they are presented, in order to ensure your own safety as well as the safety of others. The ParaZero SafeAir M-30 Pro is a safety system designed to deploy almost instantaneously by using a spring-based ballistic deployment mechanism which must be handled with caution. -
Page 7: Package Contents
Package Contents The SafeAir M-30 package includes the following parts: Table 1 – SafeAir M-30 Package Contents Description SafeAir M-30 unit Tools and cables bag USB-C cable 4 thumb screws for fast connection of the system 4 mounting screws and an Allen key... -
Page 8: Safeair System Ports & Switches
SafeAir System Ports & Switches SafeAir™ M-30 Installation Guide https://parazero.com/... -
Page 9: Installation
Warning Please do not connect the FTS cable to the drone to prevent inadvertent activation during the firmware update process Perform the self-test assessment found here SafeAir™ M-30 Installation Guide https://parazero.com/... -
Page 10: Connecting The Safeair System To The Drone
Operators who follow Max Takeoff Weight of 3,998g should attach four mounting screws, and tightly secure them using the Allen key. Otherwise, tightly secure the four thumb screws Connect the TerminateAir cable to the PSDK Port of the drone SafeAir™ M-30 Installation Guide https://parazero.com/... - Page 11 Verify that the rotors can rotate freely Caution Do not lift the drone from the SafeAir System as this may harm the system! Gently wiggle the drone to confirm that the system is securely in place. SafeAir™ M-30 Installation Guide https://parazero.com/...
-
Page 12: Remote Controller (Optional)
Remote Controller (optional) 6.1 RC 2.0 System Ports & Switches SafeAir™ M-30 Installation Guide https://parazero.com/... -
Page 13: Rc 2.0 Main Screen Messages
Battery is critically low 0-20% ② RC Signal strength Signal is at 75-100% Signal is at 50-75% 3 long beeps every 5 Signal exists and below 50% seconds 3 short beeps every 5 No signal seconds ③ GPS Signal SafeAir™ M-30 Installation Guide https://parazero.com/... - Page 14 System is connected to a power source ⑨ Current SafeAir 0000.0 m The current altitude relative to Altitude the takeoff point. The display only updates when the system is armed. Refresh interval may vary. Autopilot Drone Autopilot Connected SafeAir™ M-30 Installation Guide https://parazero.com/...
-
Page 15: Safeair M30 Drone Remote Screen Messages
RC monitor. This allows the user to directly stream all relevant data directly from the SafeAir M30 unit to the Drone’s RC monitor and have the data on one main screen. (See images below). SafeAir™ M-30 Installation Guide https://parazero.com/... -
Page 16: Rc 2.0 Idle Screen
Turn the power switch is off and plug the RC to a 5V power source via the USB C cable. The main screen shows the charging status. The following indication means low power. Charge the RC when this indication shows Note: the percentage updates every 60 seconds Charging Charging ● 079% ●●●●● SafeAir™ M-30 Installation Guide https://parazero.com/... -
Page 17: Rc 2.0 System Specifications
6.6 RC 2.0 System Specifications • Range – 1 km or line sight • Battery capacity – 1.5 hours • Frequency – 868 MHz or 915 MHz, depending on region SafeAir™ M-30 Installation Guide https://parazero.com/... -
Page 18: System Led Indications
3. Check RC is paired to device Flickering System is not leveled Check system is positioned on a Init Yellow x2 leveled surface Flickering System storage error Format storage with ParaZero Yellow x3 Desktop App Flickering Repeating IMU error 1. Restart system Mgta/yellow 3 beep 2. - Page 19 Contact Support 2x Yellow Solid Orange None General Hardware Contact Support Malfunction (*) ParaZero Remote Controller (RC) is an optional add-on and provides manual triggering capability. The LED indication is applicable for RC equipped systems. SafeAir™ M-30 Installation Guide https://parazero.com/...
-
Page 20: Operating Guidelines
Rough maneuvers in close proximity to the ground may result in inadvertent Caution parachute deployment. Exercise caution during the landing process. As a precaution, always turn the SafeAir off before moving it. Failure to do so could initiate system deployment. SafeAir™ M-30 Installation Guide https://parazero.com/... -
Page 21: After Landing
Test Motor-Cut Close menu Select “Test Motor-cut” using the middle button Approve motor-cut test Scroll down using downward facing arrow ->Long Press<- button to “OK” and long press the middle button to select Cancel SafeAir™ M-30 Installation Guide https://parazero.com/... - Page 22 SafeAir LED should be BLUE the RC 2.0 should display the Idle Screen Warning If the FTS test is not successful, do not use the SafeAir system and contact ParaZero support at support@parazero.com SafeAir™ M-30 Installation Guide https://parazero.com/...
-
Page 23: Deployment
9.1 General For professional operators that comply with ASTM F3322-22 and are intended for flight over people, parachutes must be packed and repacked by ParaZero (or by an entity that has been certified and designated by ParaZero). The SafeAir M-30 includes an Autonomous Triggering System (ATS) that identifies most of the known critical failures and triggers the system autonomously. - Page 24 Fold the 2/3 of the right gores under the folded parachute. Use weights to keep the parachute depressed and folded, as you move along the length of the parachute. SafeAir™ M-30 Installation Guide https://parazero.com/...
- Page 25 (the main strap should fold once into the figure 8 shape). For any doubts, contact support@parazero.com Place the folded parachute inside the inner stage with the strings facing downwards. Keep the parachute compressed tightly in the platform.
-
Page 26: Ce And Fcc Compliance Information
- Consult the dealer or an experienced radio/TV technician for help. The FCC Compliance Statement is available online at parazero.com/FCC-compliance EU Compliance Statement The EU Declaration of Conformity is available online at parazero.com/EU-compliance Fly Safely! Should you have questions, contact our support team at –... - Page 27 Operate Drones Everywhere, Safely Telephone: +972-36885252 Email: support@parazero.com Address: 30 Dov Hoz St. Kiryat Ono, Israel 5555626 https://parazero.com/...
