heat-timer Mini-MIG Assembly, Installation And Operation Instructions

InstallatIon and operatIon InstructIons
Mini-MIG
wIth teMperature, swItch, and pulse/counter Inputs
for platInuM and Gold controls
The digital display shows each output reading
LEDs indicate the power
and communication status
INPUT RATINGS:
115VAC 60Hz, 12VA MAX
Use Copper Conductors Only.
C US
ENCLOSED
ENERGY
CAUTION:
MANAGEMENT
EQUIPMENT
LISTED
99RA
PWR
Network
Input 1 Input 2
L N N1
1 2 3 4 7 8 9
120VAC Power Connect to Platinum or Gold
control Network terminals
all heat-timer controls are strictly operating controls. they cannot be used as limit controls. all boilers
must have all safety and limit controls required by code. It is the responsibility of the installer to verify that all
the safety and limits are working properly before the Mini-Mod is installed.
MultIple Input Gateway
Multiple Input Gateway
Power
Comm
T1
125 72
Risk of Electric Shock.
DO NOT APPLY ANY VOLTAGE
TO INPUT TERMINALS
Input 3 Input 4 Input 5 Input 6 Input 7 Input 8 Input 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
View Button scrolls through
all inputs status
Mini-MIG
T2 T3 T4
73 75
VIEW
RESET
Pulse
Input 10 Input 11 Input 12 Input 13 Input 14 Input 15
Input 16
25 26 27 28 29 30 31 32 33 34 35 36 37 38
Wire to each Input
Temp, Switch or counter
warnInG
R

overvIew

The Mini-MIG is used with any Heat-Timer
Remote Communication network or Internet
control. The Mini-MIG simplifies the wiring
and reduces the cost of individual Network
sensors. The network can terminate in
any of the following controls which have
been equipped with the Internet or Remote
Communications packages: MPC, MPCQ,
HWR, HWRQ, SRC, or Multi-MOD.
The MIG can accept Temperature, Switch,
and pulse/counter (with Internet ready
Platinum controls only) inputs. Any of the
sensors types listed on the next page can be
connected to the Mini-MIG. However, The
pulse counters can only be utilized when
connected to an Internet ready Platinum
control.
