Nordtronic 98424072 Quick Start Manual

Rotary Dimmer Zigbee
46,8 mm
Function introduction
Rotary knob, short press to turn on/off,
rotate clockwise to increase brightness,
rotate counterclockwise to decrease brightness
K1 / Min. set: for minimum brightness and
K1
Startup Brightness Setting
Min. set.
K2 / Reset: for zigbee network pairing, touchlink
Reset
K2
Item no. 98424072 or factory reset the device
Max. 150W LED
1ch dim output
Main input 230VAC
L
tc=75°C
Ratings: 100-240V~ 50Hz
Max. 150W LED
