The TRBP-02 is a wireless device that receives target commands from
remote units and releases targets from the trap machine.
In a standalone trap setup (without a card reader,) the TRBP-02 is
designed to operate as the network base-station for the wireless, voice
release trap remotes and Puller's remote. The base-station has a trap
reload delay of 1.25 seconds after throwing a target.
When the TRBP-02 enters Pause mode it sends a Sleep message to the
remotes which shortly after enter low power mode. The remotes wake
up shortly after the TRBP-02 changes back to Run mode. The TRBP-02
pause/run mode is controlled as follows:
•
On power-up it is always in run mode
•
After 15 Minutes with no target activity, the TRBP-02 automatically
enters pause mode
•
When the Puller's remote is turned on, the TRBP-02 automatically
goes to run mode. When the Puller's remote is turned off, the TRBP-
02 automatically goes to pause mode.
•
Any trap remote can switch the TRBP-02 from run to pause and back.
This is typically done by using the Puller's remote keys with a
microphone icon to mute the system while changing positions.
When used with the TargetManager card reader (compatible only with
TargetManager Firmware version 4 or higher), the TargetManager
controls the pause/run modes and the power saving of the remotes. The
TRBP-02 is paired with the TargetManager and operates as a simple
receiver.
Setup and installation
Mounting the base station: use a 1-1/4" plastic pipe bracket to mount
the base station outside the trap house on the back wall. The cable
should point downwards. Drill a small hole in the back or side of the
house and run the black cable from the base station into the house.
Protect the base station from accidental shot using nonmetallic material.
For example a polycarbonate sheet ¼" or thicker.
E
Z
P
u
l
l
T
r
a
p
B
a
s
e
-
E
Z
P
u
l
l
T
r
a
p
B
a
s
e
-
(FW V2.5.0)
S
t
a
t
i
o
n
M
o
d
e
l
T
R
B
S
t
a
t
i
o
n
M
o
d
e
l
T
R
B
Wiring for trap powered from 120VAC, including DC traps powered via
inverter:
Connect the switch wires (White & Green) to the "pull cord" terminal of
the trap. Plug the 110VAC/12VDC adaptor to a wall outlet. Insert the
"barrel" type plug into the jack attached to the Red and black wires.
Wire Color
Connect to 120VAC operated trap
RED
AC/DC adaptor +12VDC
BLACK
AC/DC adaptor GROUND (-)
GREEN
Trap Switch
WHITE
Trap Switch
Wiring for 12VDC trap powered from a battery:
Check the trap manufacturer's wiring instructions and connect the cable
to a suitable plug according to table below:
Wire Color
Connect to 12VDC battery operated trap
RED
+12VDC
BLACK
GROUND (-)
GREEN
Trap Switch N/O (Trigger)
Trap Switch COM
WHITE
For Positive release, connect together with
For Negative release, connect together with BLACK
WARNING: Do not exceed the maximum ratings!
1. * Maximum supply voltage 15VDC
2. * Maximum Trap switch current < 2Amp
3. * Maximum DC Trap switch < 30VDC
4. * Maximum AC Trap switch < 250VAC
P
-
0
2
P
-
0
2
