- Page 1 Technical Pack (SV) Model No. WB12DC001 Updated by Waveblade Ltd on 29/10/13 Waveblade Limited Polaroid Building Vale Of Leven I.E. Dumbarton Scotland UK G82 3PW Tel: +44 (0) 1389 714192 Registered in Scotland No SC425281, UK VAT No 139 8487 59...
- Page 2 CONTENTS Waveblade Unit Description Waveblade Tool Labels Waveblade Operating Instructions Waveblade Standards and Certification Waveblade Packaging Model Numbers & Accessories Certificate of Conformity Waveblade Limited Polaroid Building Vale Of Leven I.E. Dumbarton Scotland UK G82 3PW Tel: +44 (0) 1389 714192...
- Page 3 1.0 WAVEBLADE Unit Description The product known as “Waveblade” is a product designed to remove barnacles and other marine fouling from the bottom of fibreglass hulls, steel hulls, underwater / above water marine steel structures, underwater / above water marine concrete structures, boat shafts, propellers, anodes, power train components.
- Page 4 2.0 WAVEBLADE Tool Labels Waveblade Limited Polaroid Building Vale Of Leven I.E. Dumbarton Scotland UK G82 3PW Tel: +44 (0) 1389 714192 Registered in Scotland No SC425281, UK VAT No 139 8487 59...
- Page 5 WARNING - To reduce the risk of injury, users must read the instructional manual before use. 3.2A n o 4000 - 4600 min Model No. WB12DC001 IP68 Manufactured in China for: Wavecraft Limited P.O. Box 1961, Dubai, U.A.E www. waveblade.com 3.2A...
- Page 6 3.0 WAVEBLADE Operating Instructions The operating instructions and quick start guide are listed below in English. They are also available in French and Spanish Waveblade Limited Polaroid Building Vale Of Leven I.E. Dumbarton Scotland UK G82 3PW Tel: +44 (0) 1389 714192...
-
Page 7: Operating Instructions
Power Barnacle Remover OPERATING INSTRUCTIONS WB12DC001 p.1-20 p.21-40 p.41-60 WBACC014-26 November 2012 Waveblade Instruction Book 20121126.indb 1 27/11/2012 11:20:48... -
Page 8: Table Of Contents
Replacing the Front Seal Protective Foam Boot Connecting to the 12VDC Power Operation Using the tool Do Not! Maintenance Trouble Shooting Disposal Technical Data Declaration of Conformity / Producer Guarantee Patented Wave Technology www.waveblade.com Waveblade Instruction Book 20121126.indb 2 27/11/2012 11:20:48... - Page 9 Figure 1: Main Tool Parts www.waveblade.com Waveblade Instruction Book 20121126.indb 3 27/11/2012 11:20:48...
-
Page 10: General Safety Rules
SAVE THESE INSTRUCTIONS Introduction Please make sure you familiarize yourself with the way the Waveblade works before you use it for the first time and that you understand how to handle electric power tools correctly. Further details can be found in this user manual. -
Page 11: Functional Description
When used according to manufacturer’s guidelines it does not remove your anti-foul. Any other use of, and modification to, the Waveblade is deemed to be improper usage and may result in serious physical injury and invalidate your warranty. Waveblade Limited declines to accept responsibility for damage(s) arising out of usage contrary to the instructions specified below. -
Page 12: Safety Instructions
Safety Instructions Waveblade is a sealed unit with no internal serviceable parts other than the replacement of blades, protective foam boot, 10A fuse and locking collar. Take care when using the Waveblade tool; never use damaged tools or tools you suspect may be damaged or not functioning correctly. -
Page 13: Mechanical Safety
2. Keep blade away from your hands, other body parts and other people. 3. Do not use unless blade is correctly and securely fitted. 4. Do not use the Waveblade in combination with other tools or processes. 5. If the tool is dropped the power should be disconnected and the tool thoroughly inspected before further use. -
Page 14: Tool Use And Care
8. Blade tightness should be periodically checked, as operating the tool with a loose blade will damage the Waveblade. Always check before every use and re-tighten a loose blade immediately. 9. Do not use damaged blades as they could cause personnel injury or damage to the working surface. -
Page 15: Blade Attachment
Take the replacement blade and slide the blade shaft into the locking collar. Firmly push the blade and collar against the nose of the tool and retighten the set screw. www.waveblade.com Waveblade Instruction Book 20121126.indb 9 27/11/2012 11:20:49... -
Page 16: Replacing The Front Seal Protective Foam Boot
Take a new Waveblade approved replacement foam boot and slide it over the front diaphragm seal ensuring that it is pushed fully home into the recess in the front of the knuckle guard. -
Page 17: Connecting To The 12Vdc Power
12 Vdc Fused Powe r S ource (C igar L ighter or S imilar) Push 12 Vdc F used Plug C onnector to S top P os ition Figure 7: Power Supply Connection www.waveblade.com Waveblade Instruction Book 20121126.indb 11 27/11/2012 11:20:50... -
Page 18: Operation
Continuously stalling the tool causes damage to the motor and reduces the life of the tool. Waveblade is most effective with very little pressure. Let the vibrations do the work not you. The motor is protected from overheating by an internal thermal switch. Should the motor become too hot the switch will operate and stop the motor until the internal temperature has dropped to a safe value. -
Page 19: Do Not
6. Use 1” chisel blade provided when working on propeller shafts or unpainted metal surfaces. 7. Waveblade should not be used continuously for periods exceeding 30 minutes. Ideally it should have an intermittent duty cycle of 1 minute on 10 seconds off. -
Page 20: Maintenance
& damage. To assist in cleaning this area it may be beneficial to remove the blade and blade retention collar prior to cleaning. Figure 10: After Use Flush Debris from the Blade Retention Collar www.waveblade.com Waveblade Instruction Book 20121126.indb 14 27/11/2012 11:20:50... -
Page 21: Trouble Shooting
Unauthorised repairs may result in considerable danger to the user. Trouble Shooting If the Waveblade should fail to operate it could be caused by several possibilities. Before assuming that the tool is faulty, check the following: 1. Has the fuse blown in the supply? Check the 12VDC plug connector by plugging in another known working device such as a spotlight or cell phone charger. -
Page 22: Disposal
Supply voltage rating 12 VDC Nominal To be supplied via the supplied 45 feet (13 meter) specially designed Waveblade cable. Shorter cables are not to be used. Supply to be fused at a current of 10 Amps or less. - Page 23 For recommended exposure limitations refer to BS EN ISO 5349-1:2001. Note: The Waveblade is not intended for use for prolonged periods of time. Depending on usage, users should carry out a risk analysis to ensure they are not exposed to significant levels of vibration or noise.
-
Page 24: Declaration Of Conformity / Producer
Declaration of Conformity / Producer Waveblade Limited, Vale of Leven Industrial Estate, Dumbarton, G82 3PW, UK, hereby declare that this product complies with the following EU directives and international standards: EU Machinery Directive 2006/42/EC EU Low Voltage Directive 2006/95/EC EU WEEE Directive 2002/96/EC... -
Page 25: Guarantee
GUARANTEE Waveblade Limited tools carry a guarantee for 12 months from the date of purchase. Your Waveblade has been carefully manufactured and meticulously checked before delivery. Please keep your receipt as proof of purchase. Contact your authorised service center, details of which can be found at www. - Page 26 For distribution information please visit: www.waveblade.com or email: info@waveblade.com Subject to change without notice. Please check our website www.waveblade.com for updates to these instructions. www.waveblade.com Waveblade Instruction Book 20121126.indb 20 27/11/2012 11:20:51...
- Page 27 QUICK START WB12DC001 The Waveblade is designed to remove marine fouling from a variety of surfaces such as hulls, propellers, propeller shafts and stern gear. The Waveblade uses a rapidly vibrating blade which when slid across the surface dislodges the marine fouling without pressure or effort.
- Page 28 2. Tighten your collar with the allen / hex key before and during each use, especially if using Waveblade for an extended period of time. A loose blade could drop off. 3. Let the vibration do the work. Do not apply force to the leading edge of the blade.
- Page 29 4.0 WAVEBLADE Standards and Certification The various aspects of the Waveblade / PowerShark have been tested to the following standards by the following testing authorities: Waveblade Applicable standards and Certification Index of test results: Item Standards Test House NRTL & GS / Octagon...
- Page 31 MTR No.: TE0901342 EMI Report 08Y3020 Project No. 1# (customer sample) Sample Number EUT Information HC785LG-08Y3020/50/0002-08Y3020/05/0005-1252-1070094 Test Condition DC 13.2V, Free load; CCW ,without ferrite core& make ground cap good grounding Comment Blue line: 1#-L Violet line: 1#-N CISPR 14 / EN55014 Terminal Voltage Disturbance (DCAGI-TP-ETET005) Test Specification Test Equipment Test Receiver ESHS 10, 9kHz~30MHz,Rohde &...
- Page 32 MTR No.: TE0901342 EMI Report 08Y3020 Project No. 1#~2#(customer sample) Sample Number EUT Information HC785LG-08Y3020/50/0002-08Y3020/05/0005-1252-1070094 Test Condition DC 13.2V, Free load; CCW , without ferrite core& make ground cap good grounding Comment Blue line: 1# Green line: 2# CISPR 14 / EN55014 Disturbance Power Emission (DCAGI-TP-ETET005) Test Specification Test Equipment Test Receiver ESHS 10, 20MHz~1000MHz,Rohde &...
- Page 33 MTR No.: TE0901342 Frequenc Measure QP Limit Margin Measure AV Limit Margin Pass/Fai y (MHz) d QP (dBpW) (dbuV) d AV (dBpW) (dbuV) (dBpW) (dBpW) 73.875 34.5 46.6 -12.1 12.7 36.6 -23.9 Pass 117.5 41.2 48.2 -7.0 14.9 38.2 -23.3 Pass 144.375 41.5...
- Page 38 5.0 Waveblade Packaging Waveblade Limited Polaroid Building Vale Of Leven I.E. Dumbarton Scotland UK G82 3PW Tel: +44 (0) 1389 714192 Registered in Scotland No SC425281, UK VAT No 139 8487 59...
- Page 39 Power Barnacle Remover Patented Wave Technology Patent & Copyright Notice – Waveblade is covered by a number of international patent rights, intellectual property rights and trade secrets. These rights take the form of both granted and pending patents, copyright, trade secrets and registered designs. All rights are reserved. This product may not be copied, disassembled, reproduced or tampered with.
- Page 40 6.0 Model Numbers & Accessories Model No. Description Comments Main Products Corded WB12DC001 Waveblade 12V DC Corded V1 Battery PS 3000 Waveblade PowerShark Accessories WBACC001-01 3" Black Sprung Steel blade WBACC002-01 3" Stainless Steel Blade WBACC003-01 Black Half round blade...
- Page 41 7.0 Certificate of Conformity Waveblade Limited Polaroid Building Vale Of Leven I.E. Dumbarton Scotland UK G82 3PW Tel: +44 (0) 1389 714192 Registered in Scotland No SC425281, UK VAT No 139 8487 59...
- Page 42 Waveblade Limited Polaroid Building Vale Of Leven I.E. Dumbarton Scotland UK G82 3PW Tel: +44 (0) 1389 714192 Registered in Scotland No SC425281, UK VAT No 139 8487 59...
