- Page 1 USER MANUAL OPERATOR MANUAL SVU-50...
-
Page 2: Table Of Contents
OPERATOR MANUAL CONTENTS Contact Info ......3 OPERATOR MANUAL Unit Operation ..... 4-5 This manual covers the how to use the Super Vac SVU. Control Panel ......4 Operation ......5 Securement ......6 For additional instruction, view installation videos at: Parts ........ -
Page 3: Contact Info
SVU-50 THANK YOU Please allow us to express a simple thank you for investing in a SUPER VAC product. As a company we are dedicated to producing the very best and most versatile fan package available. We take great pride in the quality of our work and hope that you will find many years of satisfaction from the use of this equipment. -
Page 4: Unit Operation
OPERATOR MANUAL SVU CONTROL PANEL: MONITOR RPMs LOW/HIGH IDLE ReGen ON/OFF POWER OFF EMERGENCY STOP MASTER POWER POWER ON TILT BACK AND FORWARD LIGHTING ROTATE LEFT TO RIGHT Revised 3-2024... -
Page 5: Operation
SVU-50 STEP 1: START STEP 2: MASTER POWER STEP 3: TURN KEY To start the unit, turn the key to on and the dash will When that is on, turn you master power on. That will Turn the key all the way to the right to start. -
Page 6: Securement
OPERATOR MANUAL TIE-DOWN HOOK & TIE-DOWN STRAP: Movement of SVU unit can be done with provided Bar, Hooks, and Straps. Refer to provided manual for proper procedure per application/ SPREADER BAR STRAPS HOOKS Revised 3-2024... -
Page 7: Unit Information
SVU-50 HYDRAULIC VALVES The hydraulic valves, located under the engine have been preset. If the tilt speed needs adjustment, tighten the valves to move slower, or loosen the valves to move faster. HYDRAULIC SYSTEM ACCESS To access the hydraulic system, remove the lid to the hydraulic system cover located under the fuel filter and priming button. -
Page 8: Fuel Filter & Primer Button
OPERATOR MANUAL FUEL FILTER & PRIMER BUTTON PRIMING THE FUEL FILTER PUMP When operating the SVU from a cold state, it is important to prime the fuel pump. Priming the fuel pump is achieved by turning on the master power and tuning the key to the “on” position. Then, press the Primer Button. -
Page 9: Fuel & Exhaust
SVU-50 FUEL & EXHAUST Use only Diesel gas to fill Fuel Tank. Diesel Exhaust fluid should be used and filled in the D.E.F. fuel container on the side of the unit. DIESEL EXHAUST FLUID USE ONLY DIESEL FUEL IN FUEL TANK... -
Page 10: Maintenance
OPERATOR MANUAL MAINTENANCE: ENGINE: Refer to Cummins supplement for engine maintenance. SVU UNIT: After each use: Clean and inspect unit after each use. Keep debris clean from shroud and blade area. Inspect covers and fasteners etc. for tightness on a regular basis. WARNING Never operate with any guards, covers or other components not properly in place and in good condition.
