- Page 1 USER MANUAL OPERATOR MANUAL SVU-50...
- Page 2 OPERATOR MANUAL CONTENTS Contact Info ......3 OPERATOR MANUAL Unit Operation ..... 4-5 This manual covers the how to use the Super Vac SVU. Control Panel ......4 Operation ......5 Securement ......6-8 For additional instruction, view installation videos at: Parts ........
- Page 3 SVU-50 THANK YOU Please allow us to express a simple thank you for investing in a SUPER VAC product. As a company we are dedicated to producing the very best and most versatile fan package available. We take great pride in the quality of our work and hope that you will find many years of satisfaction from the use of this equipment.
- Page 4 OPERATOR MANUAL SVU CONTROL PANEL: MONITOR RAISE AND LOWER ReGen ON/OFF TILT BACK AND FORWARD RPMS ROTATE LEFT TO RIGHT LOW/HIGH IDLE POWER OFF LIGHTING POWER ON MASTER POWER START ENGINE Revised 6-2023...
- Page 5 SVU-50 STEP 1: START STEP 2: MASTER POWER STEP 3: TURN KEY To start the unit, turn the key to on and the dash will When that is on, turn you master power on. That will Turn the key all the way to the right to start.
- Page 6 OPERATOR MANUAL SVU SECUREMENT: How to tie down the SVU unit for transport. FIRST: Turn master power on, tilt forward. STREETSIDE UNIT TIE-DOWN CURBSIDE UNIT TIE-DOWN BACK FLOOR STRAP STREETSIDE FLOOR HOOK CURBSIDE FLOOR HOOK Revised 6-2023...
- Page 7 SVU-50 STEP 1: APPLY BACK STRAPS Connect rear strap to eyelet. Use Ratchet Strap to secure. Release rear strap. (Repeat Steps B,C, and D on the opposite side.) Utilize tilt motion to get the unit in place. Revised 6-2023...
- Page 8 OPERATOR MANUAL STEP 2: APPLY FRONT STRAPS With back straps tight and in place Hook opposite side of ratchet straps onto front unit tie downs. Tighten both front ratchet straps until (step 1), hook ratchet straps into tight and secure. both front floor loops.
- Page 9 SVU-50 MAINTENANCE: ENGINE: Refer to Kubota Supplement for Engine Maintenance. SCISSOR LIFT: Refer to Advance lift supplement for Scissor Lift Maintenance SVU UNIT: After each use: Clean and inspect unit after each use. Keep debris clean from shroud and blade area.
