  • Page 1 RX-V550 AV Receiver OWNER'S MANUAL...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. • Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated “dangerous voltage”...
  • Page 3 This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. 2 IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables.
  • Page 4 Retain this Owner’s Manual in a safe place for future reference. Since hearing damage from loud sounds is often undetectable until it is too late, YAMAHA and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels.

  • Page 5: Table Of Contents

    INTRODUCTION FEATURES... 2 GETTING STARTED... 3 Supplied accessories ... 3 Installing batteries in the remote control ... 3 CONTROLS AND FUNCTIONS ... 4 Front panel ... 4 Remote control... 6 Using the remote control ... 7 Front panel display ... 8 Rear panel ...

  • Page 6: Features

    Center: 90 W Surround: 90 W + 90 W Surround back: 90 W Sound field features Proprietary YAMAHA technology for the creation of sound fields Dolby Digital/Dolby Digital EX decoder DTS/DTS ES Matrix 6.1, Discrete 6.1, DTS Neo:6, DTS 96/24 decoder...

  • Page 7: Getting Started

    Supplied accessories Please check that you received all of the following parts. Remote control CODE SET TRANSMIT Batteries (4) SYSTEM POWER POWER STANDBY POWER (AAA, R03, UM-4) MD/CD-R TUNER SLEEP DTV/CBL V-AUX MULTI CH IN TV VOL TV CH VOLUME TV MUTE TV INPUT MUTE...

  • Page 8: Controls And Functions

    CONTROLS AND FUNCTIONS CONTROLS AND FUNCTIONS Front panel PHONES SPEAKERS STANDBY SILENT CINEMA 1 STANDBY/ON Turns on this unit or sets it to the standby mode. When you turn on this unit, you will hear a click and there will be a 4 to 5-second delay before this unit can reproduce sound.
  • Page 9 PHONES (SILENT CINEMA) jack Outputs audio signals for private listening with headphones. When you connect headphones, no signals are output to the OUTPUT jacks or to the speakers. All Dolby Digital and DTS audio signals are mixed down to the left and right headphone channels. A SPEAKERS A/B Turns on or off the set of front speakers connected to the A and/or B terminals on the rear panel each time the...

  • Page 10: Remote Control

    CONTROLS AND FUNCTIONS Remote control This section describes the function of each control on the remote control used to control this unit. To operate other components, see “REMOTE CONTROL FEATURES” on page 51. CODE SET TRANSMIT POWER POWER STANDBY MD/CD-R TUNER DTV/CBL V-AUX...

  • Page 11: Using The Remote Control

    H STRAIGHT (EFFECT) Switches the sound fields off or on. When STRAIGHT is selected, input signals (2-channel or multi-channel) are output directly from their respective speakers without effect processing. I SET MENU (A/B/C/D/E) Activates the SET MENU function. Selects preset station groups when the unit is in tuner mode.

  • Page 12: Front Panel Display

    CONTROLS AND FUNCTIONS Front panel display SILENT CINEMA NIGHT ZONE2 MATRIX DISCRETE VIRTUAL DIGITAL PL x 1 Decoder indicators When any of this unit’s decoders function, the respective indicator lights up. 2 SILENT CINEMA indicator Lights up when headphones are connected and a sound field program is selected (see page 27).
  • Page 13 K LFE indicator Lights up when the input signal contains the LFE signal. L Input channel indicators/speaker indicators Indicate the channel components of the current digital input signal. Indicate the number of speakers connected in SPEAKERS (page 24), or indicate the channel being adjusted in SP LEVEL (page 48).

  • Page 14: Rear Panel

    CONTROLS AND FUNCTIONS Rear panel MULTI CH INPUT AUDIO VIDEO VIDEO FRONT DIGITAL INPUT COAXIAL SURROUND /CBL CENTER WOOFER OPTICAL DTV/CBL MD/CD-R (PLAY) ZONE 2 /CD-R VIDEO (REC) WOOFER MONITOR OUT AUDIO OUTPUT MD/CD-R OPTICAL DIGITAL OUTPUT 1 DIGITAL INPUT jacks See pages 15, 17 and 18 for details.

  • Page 15: Speaker Setup

    Place this speaker directly behind the listening position and at the same height as the surround speakers. Subwoofer The use of a subwoofer, such as the YAMAHA Active Servo Processing Subwoofer System, is effective not only for reinforcing bass frequencies from any or all channels,...

  • Page 16: Speaker Connections

    SPEAKER SETUP Speaker connections Be sure to connect the left channel (L), right channel (R), “+” (red) and “–” (black) properly. If the connections are faulty, no sound will be heard from the speakers, and if the polarity of the speaker connections is incorrect, the sound will be unnatural and lack bass.
  • Page 17 SURROUND terminals Connect surround speakers to these terminals. SUB WOOFER jack Connect a subwoofer with built-in amplifier, such as the YAMAHA Active Servo Processing Subwoofer System, to this jack. SURROUND BACK terminals Connect a surround back speaker to these terminals.

  • Page 18: Connections

    CONNECTIONS Before connecting components CAUTION Do not connect this unit or other components to the mains power until all connections between components are complete. Cable indications For analog signals left analog cables right analog cables For digital signals optical cables coaxial cables For video signals video cables...

  • Page 19: Connecting Video Components

    CONNECTIONS Connecting video components Connections for DVD playback Optical out Video out DVD player Audio out COMPONENT VIDEO AUDIO VIDEO VIDEO S VIDEO MONITOR Video Video in monitor S VIDEO VIDEO MONITOR OUT (U.S.A. model)
  • Page 20 CONNECTIONS Connecting to the MULTI CH INPUT jacks This unit is equipped with 6 additional input jacks (left and right FRONT, CENTER, left and right SURROUND and WOOFER) for discrete multi-channel input from a multi-format player, external decoder, sound processor or pre- amplifier.
  • Page 21 Connections for other video components Optical out Cable TV or satellite tuner Audio out DIGITAL INPUT COAXIAL OPTICAL DTV/CBL Audio in Audio out VIDEO AUX jacks (on the front panel) Use these jacks to connect any video source, such as a game console or video camera, to this unit.

  • Page 22: Connecting Audio Components

    CONNECTIONS Connecting audio components Connections for audio components Coaxial out Audio out CD player DIGITAL INPUT COAXIAL MD/CD-R ( PLAY ) /CD-R ( REC ) AUDIO MD/CD-R OPTICAL DIGITAL OUTPUT (U.S.A. model) Audio out Audio in MD recorder or Optical in tape deck Optical out...

  • Page 23: Connecting The Antennas

    • A properly installed outdoor antenna provides clearer reception than an indoor one. If you experience poor reception quality, an outdoor antenna may improve the quality. Consult the nearest authorized YAMAHA dealer or service center about outdoor antennas. 75-ohm/300-ohm antenna adapter (U.K.

  • Page 24: Connecting The Power Supply Cord

    CONNECTIONS Connecting the power supply cord Connecting the AC power cord Plug the power cord into an AC wall outlet. AC OUTLET(S) (SWITCHED) U.K. and Australia models ... 1 OUTLET Korea model ...None Other models ...2 OUTLETS Use these outlets to connect the power cords from your other components to this unit.

  • Page 25: Impedance Selector Switch

    IMPEDANCE SELECTOR switch CAUTION Do not change the setting of the IMPEDANCE SELECTOR switch when the unit power is switched on, as doing so may damage the unit. If this unit fails to turn on when STANDBY/ON is pressed on either the front panel or remote control, the IMPEDANCE SELECTOR switch may not be fully slid to either position.

  • Page 26: Turning On The Power

    CONNECTIONS Turning on the power When all connections are complete, turn on the power of this unit. PRESET/TUNING FM/AM A/B/C/D/E l PRESET/TUNING h EDIT NEXT LEVEL PROGRAM PHONES SPEAKERS STRAIGHT TONE CONTROL INPUT MODE STANDBY EFFECT SILENT CINEMA CODE SET TRANSMIT SYSTEM POWER...

  • Page 27: Basic Setup

    The basic setup feature is a useful way to set up your system quickly and with minimal effort. • If you wish to configure the unit manually using more precise adjustments, use the detailed parameters in SOUND MENU (page 47) instead of using BASIC SETUP. •...
  • Page 28 BASIC SETUP Press d to display the SPEAKERS parameter. PRESET/CH SELECT Press j / i to select the number of speakers you connected. SPEAKERS 6spk Choices Display Front L/R 2spk SL SB SR SL SB SR Front L/R, Center L L C R 3spk SL SB SR Front L/R, Surround L/R...
  • Page 29 To balance the speaker levels Perform the following steps after step 13 (see page 24). V-AUX DTV/CBL MD/CD-R SILENT CINEMA NIGHT ZONE2 PTY HOLD AUTO MATRIX DISCRETE VIRTUAL HiFi DSP DIGITAL SLEEP FR-----||----- PL x The unit outputs the test tone from the selected speaker and the left front (or left surround) speaker in turn.

  • Page 30: Playback

    PLAYBACK Basic operations l PRESET/TUNING h PRESET/TUNING FM/AM A/B/C/D/E EDIT NEXT LEVEL PROGRAM INPUT PHONES SPEAKERS STRAIGHT TONE CONTROL INPUT MODE STANDBY EFFECT SILENT CINEMA CODE SET TRANSMIT SYSTEM POWER POWER STANDBY POWER TV VOL MD/CD-R TUNER SLEEP TV MUTE DTV/CBL V-AUX MULTI CH IN...
  • Page 31 Select a sound field program if desired. Rotate PROGRAM (or press AMP on the remote control to select the AMP mode, then press one of the sound field program buttons repeatedly) to select a sound field program. (See page 40 for details about sound field programs.) PROGRAM Front panel...

  • Page 32: Selecting Sound Field Programs

    PLAYBACK Selecting MULTI CH INPUT Press MULTI CH INPUT so that “MULTI CH INPUT” appears in the front panel display and video monitor. MULTI CH INPUT Front panel MULTI CH INPUT Note When “MULTI CH INPUT” is shown in the front panel display, no other source can be played.
  • Page 33 Remote control operation CODE SET TRANSMIT TV VOL TV CH SYSTEM POWER POWER STANDBY POWER TV MUTE TV INPUT MD/CD-R TUNER SLEEP STEREO HALL JAZZ DTV/CBL V-AUX MULTI CH IN MUSIC ENTERTAIN TV THTR q/DTS NIGHT EX/ES TV VOL TV CH VOLUME PRESET/CH LEVEL...
  • Page 34 PLAYBACK Notes • Some 6.1-channel compatible discs do not have a signal (flag) which this unit can automatically detect. When playing these kinds of discs with 6.1-channel, select a decoder manually (PLIIx Music, EX/ES or EX). • 6.1-channel playback is not possible even if EX/ES is pressed in the following cases: –...
  • Page 35 Listening to high fidelity stereo sound (Direct Stereo) Direct Stereo allows you to bypass this unit’s decoders and DSP processors to enjoy pure high fidelity sound from 2- channel PCM and analog sources. Rotate PROGRAM (or press AMP to select the AMP mode, then press STEREO repeatedly) to select “Direct Stereo”.

  • Page 36: Selecting Input Modes

    PLAYBACK Downmixing to 2 channels You can enjoy 2-channel stereo playback even from multi- channel sources. Rotate PROGRAM (or press STEREO on the remote control) to select 2ch Stereo. PROGRAM STEREO MUSIC q/DTS Front panel 2ch Stereo You can use a subwoofer with this program when SWFR or BOTH is selected in “BASS OUT”.
  • Page 37 Notes • When you play DTS-encoded CD/LDs with the input mode set to AUTO: – This unit automatically switches to the DTS decoding mode. The unit remains in DTS mode (and the t indicator may flash) for up to 30 seconds after playback of the DTS source is complete.

  • Page 38: Tuning

    TUNING Automatic and manual tuning There are 2 tuning methods; automatic and manual. Automatic tuning is effective when station signals are strong and there is no interference. Automatic tuning l PRESET/TUNING h PRESET/TUNING FM/AM A/B/C/D/E EDIT NEXT LEVEL PROGRAM INPUT PHONES SPEAKERS STRAIGHT...

  • Page 39: Presetting Stations

    Manual tuning If the signal from the station you want to select is weak, tune into it manually. Manually tuning into an FM station will automatically switch the tuner to monaural reception to increase the signal quality. Select TUNER and the reception band following steps 1 and 2 as described in “Automatic tuning”.
  • Page 40 TUNING Press and hold MEMORY (MAN’L/AUTO FM) for more than 3 seconds. The preset number, the MEMORY and AUTO indicators flash. After about 5 seconds, automatic presetting starts from the frequency currently displayed and proceeds toward the higher frequencies. MEMORY MAN'L/AUTO FM V-AUX DTV/CBL...

  • Page 41: Selecting Preset Stations

    Press PRESET/TUNING l / h to select a preset station number (1 through 8) while the MEMORY indicator is flashing. Press h to select a higher preset station number. Press l to select a lower preset station number. l PRESET/TUNING h LEVEL V-AUX DTV/CBL...

  • Page 42: Exchanging Preset Stations

    TUNING Exchanging preset stations You can exchange the assignment of two preset stations with each other. The example below describes the procedure for exchanging preset station “E1” with “A5”. l PRESET/TUNING h PRESET/TUNING FM/AM A/B/C/D/E EDIT NEXT LEVEL PROGRAM INPUT PHONES SPEAKERS STRAIGHT...

  • Page 43: Recording

    Recording adjustments and other operations are performed from the recording components. Refer to the operating instructions for those components. PRESET/TUNING FM/AM A/B/C/D/E l PRESET/TUNING h MEMORY EDIT NEXT LEVEL MAN'L/AUTO FM PROGRAM INPUT PHONES SPEAKERS STRAIGHT TONE CONTROL INPUT MODE STANDBY EFFECT SILENT CINEMA...

  • Page 44: Sound Field Programs

    The YAMAHA CINEMA DSP modes are compatible with all Dolby Digital, DTS, and Dolby Surround sources. Set the input mode to AUTO (see page 32) to enable this unit to automatically switch to the appropriate digital decoder according to the input signal.

  • Page 45: Dolby Digital

    Program DOLBY DIGITAL Standard 5.1-channel processing for Dolby Digital sources. SUR. STANDARD DOLBY DIGITAL CINEMA DSP enhanced processing for Dolby Digital sources. SUR. ENHANCED DOLBY D EX Standard 6.1-channel processing for Dolby Digital sources. SUR. STANDARD DOLBY D EX CINEMA DSP enhanced 6.1-channel processing (Dolby Digital EX) for Dolby Digital sources.

  • Page 46: For Music Sources

    SOUND FIELD PROGRAM DESCRIPTIONS For music sources You can select from the following sound fields when playing music sources, like CD, FM/AM broadcasting, tapes, etc. Program CONCERT HALL HiFi DSP processing. A classic shoe-box type concert hall with approximately 1700 seats. Pillars and ornate carvings create extremely complex reflections which produce a very full, rich sound.

  • Page 47: Advanced Operation

    Using the sleep timer Use this feature to automatically set this unit in the standby mode after a certain amount of time. The sleep timer is useful when you are going to sleep while this unit is playing or recording a source. The sleep timer also automatically turns off any external components connected to the AC OUTLET(S).

  • Page 48: Manually Adjusting Speaker Levels

    ADVANCED OPERATIONS Manually adjusting speaker levels You can adjust the output level of each speaker while listening to a music source. This is also possible when playing sources through the MULTI CH INPUT jacks. Please note that this operation will override the level adjustments made in “BASIC SETUP”...

  • Page 49: Set Menu

    You can use the following parameters in SET MENU to adjust a variety of system settings and customize the way this unit operates. Change the initial settings (indicated in bold under each parameter) to reflect the needs of your listening environment.

  • Page 50: Using Set Menu

    SET MENU Using SET MENU Use the remote control to access and adjust each parameter. TV VOL TV CH VOLUME TV MUTE TV INPUT MUTE STEREO HALL JAZZ ROCK MUSIC ENTERTAIN TV THTR MOVIE q/DTS NIGHT EX/ES STRAIGHT ENTER EFFECT PRESET/CH LEVEL SET MENU...

  • Page 51: Sound Menu

    1 SOUND MENU Use to manually adjust any speaker setting or compensate for video signal processing delays when using LCD monitors or projectors. Most of the SOUND MENU parameters are set automatically when you perform “BASIC SETUP” (see page 23). Speaker set A)SPEAKER SET Use to manually adjust any speaker setting.
  • Page 52 SET MENU Speaker level B)SP LEVEL Use these settings to manually balance the speaker levels between the front left or surround left speakers and each speaker selected in SPEAKER SET (page 47). Choices: –10.0 dB to +10.0 dB • FR adjusts the balance of the front left and front right speakers.

  • Page 53: Input Menu

    Audio set G)AUDIO SET Use to customize this units overall audio settings. Audio mute A.MUTE Use to adjust how much the mute function reduces the output volume. Choices: MUTE, –20 dB • Select MUTE to completely halt all output of sound. •...

  • Page 54: Option Menu

    SET MENU 3 OPTION MENU Use to adjust the optional system parameters. Display set A)DISPLAY SET Dimmer DIMMER Use to adjust the brightness of the front panel display. Choices: –4 to 0 Video conversion V CONV. Use this feature to turn on/off conversion of composite (VIDEO) signals to S-Video signals.

  • Page 55: Remote Control Features

    REMOTE CONTROL FEATURES In addition to controlling this unit, the remote control can also operate other A/V components made by YAMAHA and other manufacturers. To control other components, you must set up remote control with the appropriate manufacturer codes. Control area...

  • Page 56: Setting Manufacturer Codes

    U.K. and Europe models Other models Note You may not be able to operate your YAMAHA component even if a YAMAHA manufacturer code is initially set as listed above. In this case, try to set other YAMAHA manufacturer code(s). Press an input selector button or select the component you want to set up.

  • Page 57: Controlling Other Components

    Controlling other components Once you set the appropriate manufacturer codes, you can use this remote to control your other components. Note that some buttons may not correctly operate the selected component. Use the input selector buttons to select the component you want to operate. The remote control automatically switches to the appropriate control mode for that component.

  • Page 58: Clearing Setup Manufacturer Codes

    REMOTE CONTROL FEATURES Clearing setup manufacturer codes Clearing a setup manufacturer code for component control Press an input selector button or select the component control for which you want to clear the manufacturer code. MD/CD-R TUNER DTV/CBL V-AUX Press CODE SET using a ballpoint pen or similar object.

  • Page 59: (U.s.a., Canada And Australia Models Only)

    YAMAHA dealer or service center for the Zone 2 connections which will best meet your requirements. • Some YAMAHA models are able to connect directly to the REMOTE CONTROL OUT jack of this unit. If you own these products, you may not need to use an infrared emitter.

  • Page 60: Remote Controlling Zone 2

    ZONE 2 (U.S.A., CANADA AND AUSTRALIA MODELS ONLY) Remote controlling Zone 2 The supplied remote control can be used to control Zone 2. You can even select the input source and control components located in the main room directly from the second room regardless of the listening condition in the main room.
  • Page 61 When you have finished using the unit To set both the main unit and Zone 2 to standby mode While holding down AMP, press STANDBY. • You can turn on both the main unit and Zone 2 simultaneously by holding down AMP and pressing SYSTEM POWER. •...

  • Page 62: Editing Sound Field Parameters

    The acoustics in your room could be changed to those of a concert hall, a dance floor, or virtually any size room at all. This ability to create sound fields at will is exactly what YAMAHA has done with the digital sound field processor. Changing parameter settings You can enjoy good quality sound with the factory preset parameters.
  • Page 63 Repeat steps 2 through 4 as necessary to change other program parameters. Note You cannot change parameter values when “MEMORY GUARD” is set to ON. If you want to change the parameter values, set “MEMORY GUARD” to OFF (see page 50). Memory back-up The memory back-up circuit prevents the stored data from being lost even if this unit is set in the standby...

  • Page 64: Sound Field Parameter Descriptions

    SOUND FIELD PARAMETER DESCRIPTIONS SOUND FIELD PARAMETER DESCRIPTIONS You can adjust the values of certain digital sound field parameters so the sound fields are recreated accurately in your listening room. Not all of the following parameters are found in every program. DSP LEVEL Function: This parameter adjusts the level of all the DSP effect sounds within a narrow range.
  • Page 65 For PRO LOGIC IIx Music and PRO LOGIC II Music PANORAMA Function: Extends the front stereo image to include the surround speakers for wraparound effect. Choices: OFF/ON, initial setting is OFF. DIMENSION Function: Gradually adjusts the sound field either towards the front or towards the rear. Control range: –3 (towards the rear) to +3 (towards the front), initial setting is STD (standard).

  • Page 66: Troubleshooting

    Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, set this unit to the standby mode, disconnect the power cord, and contact the nearest authorized YAMAHA dealer or service center. General...
  • Page 67 Problem The sound suddenly The protection circuitry has been activated goes off. because of a short circuit, etc. The sleep timer has turned the unit off. The sound is muted. Only the speaker on Incorrect cable connections. one side can be heard.
  • Page 68 TROUBLESHOOTING Problem Dolby Digital or DTS The connected component is not set to sources cannot be output Dolby Digital or DTS digital played. (Dolby Digital signals. or DTS indicator in The input mode is set to ANALOG. the front panel display does not light up.) A “humming”...
  • Page 69 Tuner Problem FM stereo reception is The characteristics of FM stereo noisy. broadcasts may cause this problem when the transmitter is too far away or the antenna input is poor. There is distortion, and There is multipath interference. clear reception cannot be obtained even with a good FM antenna.

  • Page 70: Resetting The Factory Presets

    RESETTING THE FACTORY PRESETS RESETTING THE FACTORY PRESETS If you want to reset all of your unit’s parameters for any reason, do the following. This procedure completely resets ALL parameters, including the SET MENU, level, assign and tuner presets. Be sure this unit is in standby mode. PRESET/TUNING FM/AM A/B/C/D/E...

  • Page 71: Glossary

    Audio formats Dolby Digital Dolby Digital is a digital surround sound system that gives you completely independent multi-channel audio. With 3 front channels (left, center, and right), and 2 surround stereo channels, Dolby Digital provides 5 full-range audio channels. With an additional channel especially for bass effects, called LFE (low frequency effect), the system has a total of 5.1-channels (LFE is counted as 0.1 channel).

  • Page 72: Sound Field Programs

    SILENT CINEMA YAMAHA has developed a natural, realistic sound effect DSP algorithm for headphones. Parameters for headphones have been set for each sound field so that accurate representations of all the sound field programs can be enjoyed on headphones.

  • Page 73: Video Signal Information

    Video signal information Component video signal With the component video signal system, the video signal is separated into the Y signal for the luminance and the P and P signals for the chrominance. Color can be reproduced more faithfully with this system because each of these signals is independent.

  • Page 74: Specifications

    SPECIFICATIONS AUDIO SECTION • Minimum RMS Output Power for Front, Center, Surround, Surround back 20 Hz to 20 kHz, 0.06% THD, 8 ... 90 W • Maximum Power (EIAJ) [China, Korea and General models] 1 kHz, 10% THD, 8 ... 130 W •...
  • Page 75 LIST OF MANUFACTURER CODES DAYTRON DECCA A TANDY 0941 DIXI ABEX 1151 DUMONT ADMIRA 1141 DYNATECH ADVENTURA 1131 ELECTROBAND AIKO 1121 ELECTROHOME AIWA 1481 ELECTRON AKAI 0331, 1101, 1111 ELIN ALBA 0431 ELTA ALLERON 1091 EMERSON AMBASSADOR 1081 AMSTRAD 0481, 1081 ANAM 0251, 1041, 1051, 1061, 1071...
  • Page 76 SEARS 0101, 0161, 0171, 0351, 0481, 0521, 0621, 0761, 0801, 0861, 0971, 0981, WATSON 1091 XOGEGO SHANGHAI 1561, 1681 SHARP 0461, 0471, 0541, YAMAHA 0661, 0911, 0941, YOKO 1141 ZENITH SHOGUN 1031 SIGNATURE 0991, 1771 ZONDA SIMPSON 0581, 0961 SOLAVOX...

  • Page 77: Dvd Player

    VIDEO CONCEPTS PHILCO 0002, 0932 PHILIPS 0002, 0282, 0402, 0492, 0932 WARDS PILOT 0912 PIONEER 0442, 0542 1002, 1012, 1022, YAMAHA 0202, 0632 1032, 1042, 1052, ZENITH 0042, 0362, 0512, 1062 0672 0512 0612 DVD PLAYER 0272, 0612 0382, 0392, 0932...
  • Page 78 0345 SHARP SHARP 0235, 0665, 0895, SHERWOOD 1065, 1075 SONY SHERWOOD 0115, 0235, 0395, TEAC 0475 TECHNICS SIEMENTS GARRARD WARDS 1245 YAMAHA SIGNATURE 0175 SONTEC 1165 SONY 0065, 0565, 0865, 1145 STARON 1235 0025 SYLVANIA 0215 SYMPHONIC 0335 TANDY 0305...
  • Page 79 YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD18 7GQ, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA...
