- Page 1 Control Panel Model Blackfire CCF-T INSTALLATION MANUAL Pagina 1 de 36...
-
Page 2: Table Of Contents
Index Presentation ............................3 Introduction to the system ........................ 3 Technical specifications ........................4 Security of system use ........................5 Product Description ........................... 5 Version ............................... 5 System installation ..........................5 7.1. Fixing the chassis ..........................6 7.2. Wiring Installation (Connection)......................7 7.3. -
Page 3: Presentation
Upon receiving a fire alarm signal or in case of general failure, the control panel will send an order to drop the curtains, closing the gap to be sectorized or compartmented CCF-T are autonomous systems by means of an integrated UPS module that guarantees an autonomy of 4-6 hours of operation in case of main power supply failure. -
Page 4: Technical Specifications
AC/DC power source to charge the batteries with an output of 27.6 Vdc 5A 160W. Controller card (9): COLDRV controller card for the management and activation of Blackfire MSB & MFB systems. Main’s terminal block (10): Isolated terminal block. Optional: Scape Buttons: For automatic opening and closing in case of emergency. -
Page 5: Security Of System Use
4. Security of system use The CCF-T control switchboards must be installed in visible areas due the signals and indicators located on the front of the panel and in accessible places to be able to perform maintenance tasks such as battery replacement, operation tests, etc. -
Page 6: Fixing The Chassis
7.1. Fixing the chassis The control panel shall be fixed considering its dimensions and, by means of the attachment points described in the following figure, shall be installed in an accessible place for subsequent maintenance: Special care must be taken not to damage electronic components or wiring when introducing mechanical tools (drills, screwdrivers, etc.). -
Page 7: Wiring Installation (Connection)
7.2. Wiring Installation (Connection). The installation of the wiring or connection shall be carried out at the main connecting terminal. The terminal is divided into 3 sections according to the element to be related: • Input 220 Vac: Conductors with minimum gauge AWG 15 (1.5 mm2) Neutral, Phase and Ground shall be used according to the description of the terminal. - Page 8 Warnings: ➢ Blackfire Fire Systems is not responsible for damages caused by a bad connection derived from the non-reading or misunderstanding of this manual, in case of doubt please contact our technical department. ➢ All the connection of the system must be made without power, the main power will not on until all the connections, including the alarm signal, have been made.
-
Page 9: Installing Coldrv Motor Controller Cards
7.3. Installing COLDRV motor controller cards The COLDRV motor modules are programmable elements that regulate and manage, the speed of descent, the uptime, and the control at rest of the motors. The main features are as follows: • Stop by overcurrent detection: When the counterweight bar touches against the bottom of the container box in MSB &... - Page 10 The control card COLDRV has a series of led status indicators. LED 18 (RED) ACTIVE: Over-temperature in SMK 2A & 5A motors. The 24 Vdc output is disconnected to the motor. LED 18 (RED) BLINKING: Fallo de comunicaciones. Se desconecta la salida 24 Vdc a motor. LED 19 (GREEN) FAST BLINKING: COLDRV in RUN mode (UP manoeuvre).
-
Page 11: Commissioning Of The System
Before rearming the system, it must be verified that there are no obstacles that prevent the maneuver of raising the barrier. You must have visual presence of the barrier to verify the correct direction of rotation of the engine. After rearming the barrier, the condition of switchboard CCF-T shall be as follows: ➢... - Page 12 This page is the initial one of the system that shows the generic information of the curtain and the icons of user interaction. 1 QR Code. The code allows us access to the Blackfire website. 2 Name and reference. Shows the name of the project and reference of the curtain according to the client's indications.
- Page 13 Contact Area The screen will show the company data for its location or contact information.. 1 Data area. 2 Interaction buttons. On this page the user will not have any more navigation possibilities, they will only be able to return to the initial page.
- Page 14 Help Area It will display the help pages for the user. In these pages you will find information on how to navigate through the different menus, access the curtain control, status information, access to the project documentation. It will give us the option to choose the language before accessing. 1 Language selector.
- Page 15 1 General documentation. The user has the option of accessing the general documentation of the system. This section contains the documentation for the system manuals and the control panel manual. 2 Specific documentation. The user has the option of accessing the specific documentation of the project. This section contains the installation documentation and maintenance manual.
- Page 16 5 Status indicators. Represented the different status icons of each of the alarms that are displayed on the screen and show the detail of their condition. 6 Help Pages. In this menu the user can scroll through the different help sections with the numeric buttons. 7 Interaction buttons.
- Page 17 General Documentation Section 1 QR Code. By reading the QR code, the user accesses the general documentation folder for his project located on the Blackfire servers. The files that are saved in this file can only be modified by Blackfire.
- Page 18 1 QR Code. By reading the QR code, the user accesses the specific documentation folder of his project, which will only have exclusive access if accessed with password permissions, located on Blackfire servers. The files that are saved in this file can only be modified by Blackfire.
- Page 19 It can only be accessed using the correct password. In the event that the password is incorrect, the user will see a page in which they will be informed that the password is incorrect and the contact details of Blackfire for the contact..
- Page 20 Home Section In this area the user can view the following information: 1 Name and reference. Shows the name of the project and reference of the curtain according to the client's indications. 2 Curtain status. Shows depending on the movement that the curtain is making, in which state it is, Raising, Lowering, Stop or Maintenance 3 Status of alarm sensors.
- Page 21 It can only be accessed using the correct password. In the event that the password is incorrect, the user will see a page in which they will be informed that the password is incorrect and the contact details of Blackfire for the contact.
- Page 22 EDIT Section 1 Name and reference. Shows the name of the project and reference of the curtain according to the client's indications. 2 Emergency rising time (ms). Parameter that assigns the time for the emergency button to raise the curtain and for it to remain stopped.
- Page 23 RTC Section In this area the user can view the following information: 1 Date. RTC date setting with dd/mm/yy format. You can increase or decrease the digits with the “+” or “-“ buttons respectively. 2 Hour. RTC time setting in hh:mm:ss format. You can increase or decrease the digits with the “+” or “-“ buttons respectively. 3 Save.
- Page 24 WIFI Section In this area the user can configure the Wi-Fi network connection of the control panel: 1 Data. Name and password of the Wifi network to which the user connects the control panel. 2 Information icons. The user can send the LOG and INI configuration files via previously configured email. 3 Save.
- Page 25 DRVs Section 1 NumDRVs. Parameter that corresponds to the total number of drivers that the curtain has. You can increase or decrease the value with the “+” or “-“ buttons respectively. 2 rs485 BAUD. Communications bus speed. 3 maxTimeUP(s). Parameter that assigns the maximum time that the curtain can carry out in the raising manoeuvre. Value displayed in seconds.
- Page 26 Log Section On this page the user will be able to view the last 15 events that the curtain has had and will be able to send them via email to have their registration. 1 Name and reference. Shows the name of the project and reference of the curtain according to the client's indications. 2 Table of Events.
-
Page 27: Troubleshooting
8. Troubleshooting During system installation or maintenance, various problems may occur. The resolution of these must be executed by the installation company, in most cases they can be resolved according to the following table: PROBLEM CAUSE SOLUTION - Connection. - Check input connection 220 Vac. Control Panel does not turn on - Check main power line. -
Page 28: Maintenance And Cleaning
9. Maintenance and Cleaning Since fire curtains and smoke control curtains are a product of high importance in terms of fire safety, the owner of the building has the obligation to keep the curtains in good working order, being inspected and tested regularly. To ensure the reliability and integrity of textile roller fire curtains, the system must be inspected, evaluated, and repaired by trained and qualified personnel for product maintenance. -
Page 29: Annexes
Annexes: ELEMENTO / ITEM MATERIAL DESCRIPCION / DESCRIIPTION PANTALLA TÁCTIL / TOUCH SCREEN LLAVE DE APERTURA PUERTA / DOOR PLASTICO / PLASTIC OPENING KEY LLAVE DE TEST / TEST KEY METAL / METAL Pagina 29 de 36... - Page 30 ELEMENTO / ITEM MATERIAL DESCRIPCION / DESCRIIPTION BATERIAS / BATTERIES 2 PCS 12V 1.3 Ah (STANDAR) FUENTE DE ALIMENTACION CARGA BATERIAS 27 Vdc potencia según modelo BATTERY CHARGING POWER SUPPLY 27 Vdc power acording model TARJETA CONTROLADORA COLDRV TARJETA CONTROLADORA COLDRV BOARD BOARD BORNERO PRINCIPAL PARA EL CONEXIONADO DE ALIMENTACION, ALARMA Y SALIDA BORNERA PRINCIPAL DE CONEXION MAIN...
- Page 31 DETALLE / DETAIL BORNE EN PLACA DE ENTRADA 24 Vdc TERMINAL IN BOARD FOR 24 Vdc INPUT BORNE DE CONEXION PARA EL MOTOR / MOTOR TERMINAL BORNE LLAVE DE TEST / KEY TEST TERMINAL ENTRADA SEÑAL FALLO BATERÍAS / BATTERY FAILURE SIGNAL IN ENTRADA SEÑAL FALLO DE RED / MAINS POWER FAILURE SIGNAL IN BORNE ALARMA FUEGO / FIRE ALARM TERMINAL BORNE DE CONEXION PROTOCOLO DE COMUNICACIONES RS485...
- Page 32 Pagina 32 de 36...
- Page 33 Pagina 33 de 36...
- Page 34 Pagina 34 de 36...
- Page 35 Pagina 35 de 36...
- Page 36 Pagina 36 de 36...
