PORTABLE COMPRESSOR KIT
OPERATION GUIDE
CKMP12V2
Part No. 2102MP12V2
Revision Date 8/05/2023
Copyright © 2023 by ARB Corporation Limited

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CKMP12V2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ARB CKMP12V2

  • Page 1 PORTABLE COMPRESSOR KIT OPERATION GUIDE CKMP12V2 Part No. 2102MP12V2 Revision Date 8/05/2023 Copyright © 2023 by ARB Corporation Limited...
  • Page 2 No liability is assumed for damages resulting in the use of the information contained herein. ARB Air Locker Air Operated Locking Differentials, ARB Air Locker Air Activation System and Air Locker are trademarks of ARB Corporation Limited. Other product names used herein are for identification purposes only and may be trademarks of their respective owners.
  • Page 3: Table Of Contents

    Table of Contents: 1 Introduction What Is Included Features of the CKMP12V2 Portable Compressor Specifications of the CKMP12V2 Portable Compressor 2 Safe Air Compressor Operation Connecting for Use Safety Precautions Tyre Filling Understanding the Built-In Protection Devices 3 Service & Maintenance...
  • Page 4: Introduction

    Introduction IMPORTANT: For the safest and most effective service from this portable air compressor, please read this guide in its entirety before attempting actual use. mark inside each of the  symbols as Place a HINT: you follow each step so that you don’t miss any. What Is Included Below is a detailed list of items included with this kit: ...
  • Page 5: Features Of The Ckmp12V2 Portable Compressor

    Introduction Features of the CKMP12V2 Portable Compressor The ARB CKMP series portable air compressor is a world class recreational product designed and built to commercial / industrial standards boasting the following features:  Ultra compact design makes this the highest flowing portable compressor in its class.
  • Page 6: Specifications Of The Ckmp12V2 Portable Compressor

    Norgren series 237 Gromelle series 600 WARRANTY This ARB Air Compressor is designed to provide many years of trouble free recreational use, and is warranted to be free from manufacturing defects for two (2) years from the date of purchase.
  • Page 7: Safe Air Compressor Operation

    Safe Air Compressor Operation Connecting for Use  Position the compressor on a sturdy flat surface before opening the box.  Unlock and open the box using the two toggle clamps.  Make sure that the switch is in the ‘OFF’ position by pressing down on the top of the switch rocker.
  • Page 8: Safety Precautions

     Never point the hose at anyone and always see that bystanders are out of the line of air flow.  If using extension or replacement hoses other than genuine ARB hoses, use only sound strong hose with secure couplings and connections having a high temperature rating and a burst pressure of over 1380 Kpa [200 PSI].
  • Page 9: Tyre Filling

     Press the bottom of the rocker switch down to start and pressurize the compressor. ARB’s tyre filler attachment is equipped with a NOTE: stop valve. Air will not pass through the tyre filler attachment until it is connected to a tyre valve.
  • Page 10: Understanding The Built-In Protection Devices

    Safe Air Compressor Operation Understanding the Built-In Protection Devices This compressor has been equipped with both THERMAL and OVER PRESSURE protection devices in the interests of personal safety and to protect the unit from unnecessary internal damage. Never disable or modify any of the compressor’s built-in NOTE: protection devices.
  • Page 11: Service & Maintenance

    Service & Maintenance Air Filter Service The CKMP12V2 Portable Air Compressor comes factory fitted with a high density, high flow, sintered bronze air filter to protect the compressor components, and any accessories that might be used with the compressor, from damage caused by the ingress of dirt and fine dust particles. The filter element is removable and cleanable and should provide for years of continuous service.
  • Page 12: Electrical Fuse Replacement

    (maxi blade type) and of the same amp rating or less. Safety Valve Service The CKMP12V2 Portable Air Compressor comes factory equipped with a safety valve to relieve any excessive pressure from inside the system safely and automatically. This pressure could occur as a result of a fault in the pressure switch circuit, pressure generated from prolonged exposure to direct sunlight, accidental connection to a higher source of pressure, etc.
  • Page 13: Parts List

    Portable Compressor Kit – Exploded Parts Diagram CKMP12V2 CKMP12V2...
  • Page 14: Itemized Parts List

    CKMP12V2 Portable Compressor Kit Specs: ITEM # DESCRIPTION PART # NOTES Voltage 12 Volts SAFETY VALVE FITTING 320204 Current Draw SAFETY VALVE SPRING 150115 No-Load 13A SAFETY VALVE POPPET 320205 Load 23A Air Flow COMPRESSOR HEAD BOLT (M6 x 60) 200703 75.1L/min @ 0kPa [2.65CFM @ 0psi]...
