Paccar BRADEN PD12C Parts And Service Manual

Paccar BRADEN PD12C Parts And Service Manual

Hydraulic planetary hoists
Hide thumbs Also See for BRADEN PD12C:
Table of Contents

Advertisement

Quick Links

Download this manual
PD12C and PD15B
Parts and Service Manual
PD12C AND PD15B
HYDRAULIC PLANETARY HOISTS
Record serial number below:
First 2 numbers indicate year of manufacture
(for serial number location, see page 3).
Visit www.paccarwinch.com for the most up-to-date product and service information.
Technical publications for most PACCAR Winch products are available for download.
800 East Dallas | Broken Arrow, OK 74012
www.paccarwinch.com | 918.251.8511
MADE IN THE
LIT2935_03-2024 (CPR) ©2024 PACCAR Inc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRADEN PD12C and is the answer not in the manual?

Questions and answers

Related Manuals for Paccar BRADEN PD12C

Summary of Contents for Paccar BRADEN PD12C

  • Page 1 First 2 numbers indicate year of manufacture (for serial number location, see page 3). Visit www.paccarwinch.com for the most up-to-date product and service information. Technical publications for most PACCAR Winch products are available for download. 800 East Dallas | Broken Arrow, OK 74012 www.paccarwinch.com | 918.251.8511 MADE IN THE LIT2935_03-2024 (CPR) ©2024 PACCAR Inc...

  • Page 2: Table Of Contents

    Table of Contents FOREWORD ........................... 3 PLANETARY HOIST MODEL NUMBER EXPLANATION ............3 GENERAL SAFETY RECOMMENDATIONS ................4 THEORY OF OPERATION ....................5-6 HOIST INSTALLATION ......................7-8 RECOMMENDED FASTENER TORQUE ................9 WIRE AND SYNTHETIC ROPE INSTALLATION ..............9-11 TWO-SPEED MOTOR CASE DRAIN PLUMBING ..............11 PREVENTIVE MAINTENANCE ..................

  • Page 3: Foreword

    FOREWORD Read this entire publication and retain it for future reference. For inquiries regarding your BRADEN Planetary Hoist or this publication, please contact BRADEN Service Department at 918-251-8511, Monday through Friday, 8:00 a.m. to 4:30 p.m. (CST). The minimum service intervals specified are for operating hours of the prime mover. The following service instructions have been prepared to provide assembly, disassembly and maintenance information for the BRADEN Model PD12C and PD15B series hoist.

  • Page 4: General Safety Recommendations

    GENERAL SAFETY RECOMMENDATIONS Safety and informational callouts used in this manual include: WARNING CAUTION WARNING – This emblem is used to warn against hazards CAUTION – This emblem is used to warn against potential and unsafe practice which COULD result in severe personal or unsafe practices which COULD result in personal injury injury or death if proper procedures are not followed.

  • Page 5: Theory Of Operation

    THEORY OF OPERATION DESCRIPTION OF HOIST open at 300-500 psi (20.7-34.5 bar) cracking pressure the pilot pressure becomes flow-dependent and modulates The hoist has four basic component parts: the spool valve opening which controls the lowering speed. Refer to figures 1, 2, and 3. 1.
  • Page 6 THEORY OF OPERATION of oil flowing through it and the speed at which the load will be lowered. Increasing the flow of oil to the motor will cause the pressure to rise and the opening in the brake valve to enlarge, speeding up the descent of the load. Decreasing this flow causes the pressure to lower and the opening in the brake valve to decrease thus slowing the descent of the load.

  • Page 7: Hoist Installation

    HOIST INSTALLATION 1. The hoist should be mounted with the centerline of the drum in a horizontal position. The mounting plane of the base may be rotated in any position around this centerline. 4. The vent plug must always be located above the horizontal centerline.
  • Page 8 HOIST INSTALLATION HOIST ASSEMBLY W/BRAKE VALVE WINCH ASSEMBLY & STATIC BRAKE W/BRAKE VALVE & STATIC BRAKE BRAKE VALVE HOIST BRAKE BRAKE VALVE WINCH BRAKE CONTROL VALVE 2-SPEED SELECTOR VALVE CONTROL VALVE PUMP PUMP periods. A high viscosity index will minimize changes in WARNING viscosity with corresponding changes in temperature.

  • Page 9: Recommended Fastener Torque

    RECOMMENDED FASTENER TORQUE Higher or lower torques for special applications will be specified such as the use of spanner nuts, nuts on shaft ends, jam nuts and where distortion of parts or gaskets is critical. Lubricated torque values based on use of SAE 30wt engine oil applied to threads and face of bolt or nut. Avoid using thread lubricants (such as anti-seize compound) as the applied torque may vary by 10-40%, depending upon the product used.
  • Page 10 WIRE AND SYNTHETIC ROPE INSTALLATION 4. Install the wedge as shown in Figure 1 then pull the slack from the cable. NOTE: An early style wedge was designed to accommodate multiple sizes of wire rope. It may need to be inserted large end first or small end first depending on the diameter of rope being anchored.

  • Page 11: Two-Speed Motor Case Drain Plumbing

    WIRE AND SYNTHETIC ROPE INSTALLATION 3. Splice an eye at the end of the rope to be inserted into the anchor pocket. It is recommended to wrap the eye with electrical tape to allow the rope to slide into the pocket easily. 4.

  • Page 12: Preventive Maintenance

    PREVENTIVE MAINTENANCE 2. OIL CHANGE PROCEDURE A regular program of preventive maintenance for your planetary hoist is strongly recommended to minimize the Gear oil should be changed after 100 hours of use for need for emergency servicing and promote safe, reliable new installation of the hoist to remove initial wear par- hoist operation.
  • Page 13 PREVENTIVE MAINTENANCE 8. INSPECTION WARNING A. Bearings Gears – Refer HOIST Failure to properly warm up the hoist, particularly under low DISASSEMBLY, pages 19 and 20; and PLANET ambient temperature conditions, may result in temporary brake CARRIER SERVICE, pages 30 and 31. slippage due to high back pressures attempting to release the B.

  • Page 14: Recommended Gear Oil

    Gear Compounds EP 150 or Meropa 150 Range C Mobilgear SHC 150 Omala S4 GX 150 PACCAR Winch winches/hoists are factory filled with Mobilgear 600 XP 150 or equivalent. Consult with your oil supplier for equivalent oil options as required. OIL CAPACITIES: (PD12C/PD15B) 01, 02 &...

  • Page 15: Troubleshooting

    TROUBLESHOOTING WARNING If a hoist ever exhibits any sign of erratic operation, or load control difficulties (i.e. load creeping or chattering) appropriate troubleshooting tests and repairs should be performed immediately. Continued operation in this manner may result in property damage, serious personal injury or death. PROBABLE CAUSE TROUBLE REMEDY...
  • Page 16 TROUBLE PROBABLE CAUSE REMEDY Oil leaks from vent plug 1. Same as PROBABLE CAUSE A2. 1. Same as REMEDY A2. 2. Motor seal may be defective as a 2. Hydraulic system back pressure result of high system back pressure or must not exceed 100 PSI (6.9 bar).
  • Page 17 TROUBLE PROBABLE CAUSE REMEDY Trouble “D” Continued From NOTE: If pressure does not increase Previous Page in proportion to adjustment, relief valve may be contaminated or worn out. In either case, the relief valve may require disassembly or replacement. 3. Be certain hydraulic system 3.
  • Page 18 PROBABLE CAUSE TROUBLE REMEDY Hoist “chatters” while raising rated 1. Same as REMEDY for D2. 1. Same PROBABLE CAUSE as D2. load. 2. Same as REMEDY for E2. 2. Hydraulic oil flow to motor may be too low. 3. Conduct operator training as 3.

  • Page 19: Service Kits

    SERVICE KITS 61567 - BRAKE VALVE O-RING KIT 61715 - SEAL KIT DESCRIPTION PART NO. QTY. DESCRIPTION PART NO. O-RING 24186 O-RING 13838 O-RING 23601 O-RING 12465 O-RING 24193 O-RING 25366 O-RING 24194 O-RING 78312 BACK-UP RING 24195 O-RING 22586 BACK-UP RING 24196 O-RING...

  • Page 20: Hoist Disassembly

    HOIST DISASSEMBLY SERVICE PRECAUTIONS connecting the brake valve and manifold to the brake cylinder. • Before any part is removed from the hoist, all service instructions should be read and understood. • Work in a clean, dust free area as cleanliness is of utmost importance when servicing hydraulic equipment.
  • Page 21 HOIST DISASSEMBLY 12. Remove the primary planet carrier from the drum. Refer 8. Remove the brake cylinder capscrews and install to “Planet Carrier Service” for additional information. two (2) capscrews and a short piece of chain into the motor support mounting bolt holes. Using the chain as a handle, lift the brake cylinder out of the drum and base, being careful to avoid damaging the sealing or bearing surfaces.

  • Page 22: Main Assembly Components

    MAIN ASSEMBLY COMPONENTS...
  • Page 23 MAIN ASSEMBLY COMPONENTS ITEM DESCRIPTION PD12C PD15B PART NO. PART NO. BASE CONFIGURATIONS (SEE PGS 8-9) CABLE DRUM (01 DRUM) 26757 CABLE DRUM (02 DRUM) 25518 CABLE DRUM (04 DRUM) FROM S/N 9102358 28831 28832 CABLE DRUM (05 DRUM) 25901 26464 PD12C CABLE DRUM CLOSURE (CONSULT FACTORY WITH HOIST 26763 or...

  • Page 24: Base Configurations

    BASE CONFIGURATIONS COMMON BASE PARTS ITEM DESCRIPTION PART NO. QTY. RETAINING RING 70575 PLUG HEX (STANDARD WINCHES) 31386 PLUG FLUSH 24420 SIGHT GLASS (-1 OPTION) 25958 O-RING FOR ITEM 44 PLUGS* 24186 RELIEF VALVE 18062 CAST BASE ITEM DESCRIPTION PART NO. BASE (RIGHT HAND) 25615 BASE (LEFT HAND)
  • Page 25 BASE CONFIGURATIONS 39 41 FABRICATED BASE DRUM OPTION CODE ITEM DESCRIPTION -02 / -05 -02 (LH) PART NO. BEARING SUPPORT 106459 106459 106459 106459 CAPSCREW, HEX HEAD (1/2-13 X 1-1/4 GD8 Z) 104174 104174 104174 104174 BASE 26344 26344 26344 26344 SIDE PLATE, BEARING SUPPORT END 26764...

  • Page 26: Special Drum Code 06 Components Pd15B Only

    SPECIAL DRUM CODE 06 COMPONENTS PD15B ONLY Sideplate - Bearing Winch Cable Sideplate - Bearing Drum Cable Winch Model Bearing Base Support Part No Drum Motor End Support Closure Wedge Support Shaft (Not ITEM # pictured) -06UG Underwound 05156 104057 102033 102032 102031...

  • Page 27: Drum Rotation To Hoist (04 & 05 Drum/Base Shown)

    DRUM ROTATION TO HOIST (04 & 05 DRUM/BASE SHOWN) UNDERWOUND MODELS DESIGNATED BY “–U” Underwound will have “U” in Underwound will have “U” in (EXAMPLE: PD12C-41051-04U) model number model number RH BASE (Standard) RH BASE (Standard) LH BASE (Optional) LH BASE (Optional) OVERRUNNING CLUTCH COMPONENTS PART NO.

  • Page 28: Brake Clutch Rotation

    BRAKE CLUTCH ROTATION Note: Designation of cable drum rotation is determined by viewing winch from hydraulic motor end while hoisting. The inner race of the brake clutch sprag assembly, when viewed from the motor side, must freewheel in the direction opposite as the cable drum during hoisting PART #81716 &...

  • Page 29: Brake Cylinder Assembly

    BRAKE CYLINDER ASSEMBLY ITEM DESCRIPTION PART NO. QTY. BRAKE CYLINDER (LOBED DISC) 100035 BRAKE PISTON SEAL 25642 PRESSURE PLATE 25635 PISTON BACKUP RING 25636 DIE SPRING 25644 FRICTION DISC 21036 BRAKE DISC, STEEL, LOBED 100027 BRAKE DISC, STEEL, SPLINED 21029 MOTOR ADAPTER (4 BOLT C) 051, 064, 049/024, 064/032 100028 MOTOR ADAPTER (2 BOLT C) VARIOUS...

  • Page 30: Planet Carrier Assemblies Pd12C Only

    PLANET CARRIER ASSEMBLIES PD12C ONLY PRIMARY PLANET CARRIER ASSEMBLY 21:1 29:1 41:1 59:1 ITEM DESCRIPTION PART NO. QTY. PRIMARY PLANET CARRIER ASSEMBLY 81805 81806 81807 81801 PRIMARY PLANET CARRIER 25715 25730 25606 25604 PRIMARY PLANET GEAR 26280 2278 26278 26276 PRIMARY PLANET GEAR SHAFT 25614 25614...

  • Page 31: Planet Carrier Assemblies Pd15B Only

    PLANET CARRIER ASSEMBLIES PD15B ONLY PRIMARY PLANET CARRIER ASSEMBLY Part Number 82342 (serial number 9702222 and higher) 34:1 41:1 RATIO 41:1 RATIO RATIO SERIAL # SERIAL # 970221 & 970222 & LOWER HIGHER ITEM DESCRIPTION PART NO. QTY. PRIMARY PLANET CARRIER 82343 81844 82342...

  • Page 32: Motor Groups (Standard)

    MOTOR GROUPS (STANDARD) V-33/20 TWO-SPEED, BRAKE VALVE 81719 V-33/20 83 58 TWO-SPEED, BRAKE VALVE 29576 66 65 40 41 049/024 & 064/032 MOTOR TWO-SPEED...
  • Page 33 MOTOR GROUPS (STANDARD) 051 & 064 MOTOR SINGLE-SPEED 40 41 071 & 062 MOTOR SINGLE-SPEED 40 41 080 MOTOR SINGLE-SPEED...
  • Page 34 MOTOR GROUPS (STANDARD) 68 61 029, 034, & 039 MOTOR SINGLE-SPEED ITEM DESCRIPTION PART NO. PILOT O-RING 029 (2 BOLT B) 25385 21063 034 (2 BOLT B) 25912 21063 034 (2 BOLT B) UNDERWOUND 103887 21063 039 (2 BOLT B) 25515 21063 039 (4 BOLTC) CT WINCHES...
  • Page 35 MOTOR GROUPS (STANDARD) 049/024 039, 051, 064 029, 034, 039 071/062 V33/20 064/032 4 BOLT-C 4 BOLT-C 2 BOLT-B 2 BOLT-A 2 BOLT-B 4 BOLT-C ITEM DESCRIPTION PART NO. CAPSCREW 1/2-13 X 1-1/2 GD8 Z HX HD 104322 104322 104322 104322 104322 CAPSCREW 1/2-13 X 1-1/2 ASTM A574 SKT HD...

  • Page 36: Motor Groups (-1 Option, Personnel Handling)

    MOTOR GROUPS (–1 OPTION, PERSONNEL HANDLING) 68 63 049/024 & 064/032 MOTOR TWO-SPEED PERSONNEL HANDLING 59 61 73 74 051 & 064 MOTOR TWO-SPEED PERSONNEL HANLDING 60 83 66 63 029, 034 & 039 MOTOR SINGLE-SPEED PERSONNEL HANDLING...
  • Page 37 MOTOR GROUPS (–1 OPTION, PERSONNEL HANDLING) 064/032 029/034/039 & 64 049/024 ITEM DESCRIPTION PART NO. CAPSCREW 1/2-13 X 1-1/2 GD8 Z HX HD 104322 104322 104322 LOCKWASHER 1/2 Z 11026 11026 11026 MANIFOLD 24779 25539 O-RING 13838 13838 25366 CAPSCREW 7/16-14 X 2 GD5 SKT HD ASTM A574 Z 21144 CAPSCREW 3/8-16 x 1-1/2 ASTM A574 SKT HD (EARLY) 13544...

  • Page 38: Brake Valve Assembly

    BRAKE VALVE ASSEMBLY ITEM DESCRIPTION PART NO. BRAKE VALVES BRAKE VALVE HOUSING FLANGE PART NO. VALVE SPRING RETAINER 24424 1-1/4 IN. CODE 61 81712 RELIEF RETAINER (81719 VALVE) 29609 1 IN. CODE 61 81715 SPRING RETAINER 24183 3/4 IN. CODE 62 81719 PLUG 22450...

  • Page 39: Fasteners, Adapter, And Hose Assemblies

    FASTENERS, ADAPTER, AND HOSE ASSEMBLIES CAPSCREWS AND LOCKWASHERS SPLIT FLANGE ADAPTER PART NO. DESCRIPTION PART NO. DESCRIPTION 29631 5/16 NC X 3 G8, SOCKET HEAD 25539 SPLIT FLANGE ADAPTER 21654 3/8 NC X 3 1/2 G8, SOCKET HEAD 25622 3/8 NC X 2 3/4 G8, SOCKET HEAD 29630 3/8 NC X 4 G8, SOCKET HEAD 13587...

  • Page 40: Fittings

    FITTINGS PART NO. DESCRIPTION 25302 ELBOW -4 JIC TO -4 ORB 25131 ELBOW -4 JIC TO -6 ORB 22934 TEE, 1/8-27 NPT-F RUN TO 1/8-27 NPT-M BRANCH 24236 STREET ELBOW, REDUCER, 1/4-18 M TO 1/8-27F 13708 STREET ELBOW, 1/8-27 24784 ADAPTER, -4 ORB TO -2 NPT-F 25748 SWIVEL TEE, -4 JIC M RUN X -4 JIC F SWIVEL BRANCH...

  • Page 41: Planet Carrier Service

    PLANET CARRIER SERVICE OUTPUT PLANET CARRIER 3. Use a punch to drive the roll pins from the planet shafts. Do not reuse the roll pins. DISASSEMBLY ASSEMBLY 1. Remove the planet gears by driving the roll pins into the center of the planet shafts. 1.

  • Page 42: Motor Support - Brake Cylinder Service

    PLANET CARRIER SERVICE 4. The roll pin is recessed approximately 1/16 in. (.06 mm) in the carrier when properly installed. With a center 3. Carefully align the pin hole in the carrier with the hole punch, stake the carrier next to the pin hole as shown. in the planet gear shaft and drive the roll pin into place.
  • Page 43 MOTOR SUPPORT — BRAKE CYLINDER SERVICE 4. Place steel brake disc on flat surface and check for CLEAN AND INSPECT distortion with a straight edge. Check surface for signs 1. Thoroughly clean and inspect all parts at this time. of material transfer or heat. Replace steel disc if splines Check brake piston sealing surfaces on brake cylinder are worn to a point, disc is distorted or heat discolored.
  • Page 44 MOTOR SUPPORT — BRAKE CYLINDER SERVICE 3. Insert first, a steel brake disc against the spacer followed by a friction brake disc then alternate steel and friction discs until seven (7) friction and eight (8) steel discs have been installed. Finish with a steel brake disc on top.
  • Page 45 MOTOR SUPPORT — BRAKE CYLINDER SERVICE BRAKE CYLINDER PRESSURE TEST 1. Install the –4 JIC fitting into the brake release port. 8. Install pressure plate into brake cylinder followed by Connect a hand pump with accurate 0-2000 PSI the piston backup ring. The close-fitting piston backup (0-13,800 kPa) gauge and shut-off valve to this fitting.

  • Page 46: Brake Clutch Service

    BRAKE CLUTCH SERVICE DISASSEMBLY 4. Next, slide the sprag clutch out, inspect the sprag clutch closely for abnormal wear, cracks, pitting or corrosion. 1. Remove the snap ring and sprag bushing retainer from Check small clips for breakage or bright spots; the signs one end only.
  • Page 47 BRAKE CLUTCH SERVICE 2. Turn the assembly over and install the sprag clutch in 6. Turn the assembly over with the snap ring down. Install the bore of the outer race. the second retainer and snap ring. Make certain the 3.

  • Page 48: Hoist Assembly

    HOIST ASSEMBLY NOTE: PD15B HOISTS ONLY The drum closure will not fit through the opening in the base. For hoists with a three piece base, first assemble the bearing support side plate (91) to the base plate (90). Go to step 1 and follow the assembly procedure. Install the motor end side plate and tie bar(s) after installing the drum closure in step 10.
  • Page 49 HOIST ASSEMBLY 5. Stand hoist on bearing support end. Install the output sun gear and thrust washer into output planet carrier. 6. Install the output planet carrier into the drum while meshing the planet gears with the ring gear and the planet housing with the bearing support.
  • Page 50 HOIST ASSEMBLY 13. If the brake discs are misaligned, preventing the Measure the distance from the motor mounting surface installation of the clutch, then with a hand pump, apply to the inner brake race. With all components properly 750-1000 PSI (51.7-68.9 bar) to the brake release installed, this distance should be 11/16 in.

  • Page 51: Brake Valve Service

    BRAKE VALVE SERVICE SEC. A-A DRAIN PORT 2. Remove the elbow fitting, motor drain check ball and spring. ITEM DESCRIPTION BRAKE VALVE HOUSING “BR” PORT VALVE SPRING RETAINER SPRING RETAINER PLUG SPOOL The BRADEN brake valve is a reliable hydraulic valve with internal components manufactured to close tolerances.
  • Page 52 BRAKE VALVE SERVICE 4. Remove spool plug and carefully remove spool 2. Install new O-rings and backup rings on the spool and assembly. damper piston as shown. Ensure each backup ring is on the correct side of its O-ring. Take care not to cut 5.

  • Page 53: Reversing Direction Of Drum Rotation

    REVERSING DIRECTION OF DRUM ROTATION Motor Case Drain Motor Case Drain Brake Lowering Brake Lowering Motor Motor Valve Valve Port Port Hoisting Hoisting Port Port Brake Release Brake Release Circuit Circuit M = Manifold Block “B” “A” In order to change the direction of rotation and brake operation, 2 components must be changed on the hoist. First, the motor must be made to rotate in the opposite direction.
  • Page 54 REVERSING DIRECTION OF DRUM ROTATION 5. Pull the inner race out. Examine the race for scoring, 9. Install new O-rings in the brake valve and manifold wear or indentations caused by the sprag cams. If the block. Attach the brake valve and manifold block to inner race is not completely smooth, the assembly the motor using the original capscrews and tighten to should be replaced.
  • Page 56 800 East Dallas | Broken Arrow, OK 74012 www.paccarwinch.com | 918.251.8511 MADE IN THE LIT2935_03-2024 (CPR) ©2024 PACCAR Inc...
