Toast Flex Easy Install Manual

Toast Flex 22" Stand Kit
Easy Install Guide
Tools Needed
4x Thumbscrews
found in the general toolkit
Pro tip: Clear your install area of any obstructions before you get started.
Step 1
Connect to power and ethernet
terminal.
1
3
Remove back panels. Open and remove the
back panel from the top cut outs to expose
the back pockets
Follow the step-by-step instructions on the reverse page.
according to the labels on the back of your Toast Flex 22"
2 5
Plug in your cables.
and the (optional) ethernet cable in the left
pocket as shown
4
6
Plug in the USB-C power
What's in the box
1x Stand
1. Power & ethernet cables
2. Grommet to seal the pocket
3. Pocket for cable management
4. Accessory pocket
5. Grommet to set the cable
6. Pocket for cable management
1
