Summary of Contents for REI UHD-14VW
- Page 1 UHD-14VW Follow us on Youtube 1-In-4-Out USB-C & HDMI and Facebook Video Wall Controller USER MANUAL www.orei.com...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions IR Remote IR Cable Pin Assignment Video Wall RS-232 Control Command Application Example Thank you for purchasing this product Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. - Page 3 Registration Page Please Activate your warranty by registering our product through the link below - https://www.orei.com/register Technical Support Need Help? Our experienced Technical Support Team is here for you to answer your questions, give technical advice or help troubleshoot your project to get you installed on time and on budget.
-
Page 4: Introduction
Introduction The UHD-14VW 1-In-4-Out Video Wall Controller is designed to take a single input and distribute it across 4 displays. The device features an HDMI and a USB-C input to connect to your media source. It supports resolutions up to 4K@60Hz 4:4:4. The device can take a media source and spread it across 4 displays creating a 2x2 Video wall. -
Page 5: Features
5. 8 different Video wall modes 6. Features 180 degree image rotation 7. Bezel adjustment and EDID management 8. Control via included remote, RS-232 or front panel. 9. Plug & Play setup Package Contents UHD-14VW 1pcs 12V/1A Locking Power Supply 1pcs Power Adapter 1pcs... -
Page 6: Specifications
Specifications Technical HDMI Compliance HDMI 2.0 HDCP Compliance HDCP 2.2 Video Bandwidth 18Gbps Input: up to 4K@60Hz 4:4:4 Video Resolution Output: 720P60Hz, 1080P60Hz, 4K@30Hz, 1024x768P@60Hz Color Space RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0 Color Depth 8/10/12 bit IR Level 5Vp-p IR Frequency 38KHz HDMI IN/OUT: LPCM 2.0/5.1/7.1, Dolby Digital/Plus/EX, DTS, DTS-EX, DTS-96/24... - Page 7 Specifications Connection 1 × HDMI INPUT [Type A, 19-pin female] Input ports 1 × USB-C INPUT [Type C, 24-pin female] 4 × HDMI OUTPUT [Type A, 19-pin female] Output ports 1 × OPTICAL AUDIO OUT [S/PDIF] 1 × L/R AUDIO OUT [RCA] 1 ×...
-
Page 8: Operation Controls And Functions
Operation Controls and Functions Front Panel Name Function Description Press once to turn on the device. Press and hold for 3 Power button seconds to enter standby mode. The LED will light up green indicating stable power and light Power LED up red when on standby HDMI LED The LED will light up green when HDMI input is selected. - Page 9 Operation Controls and Functions Rear Panel INPUT AUDIO OUT VIDEO WALL OUT HDMI USB-C OPTICAL HDMI 1 HDMI 2 HDMI 3 HDMI 4 RS-232 IR EXT DC 12V Name Function Description Connect the source media device such as a DVD player, HDMI INPUT set-top box, etc.
-
Page 10: Ir Remote
IR Remote Power on the device or set it to standby mode. Mute INPUT Mute: HDMI USB-C AUTO Turn off/on the audio output, including HDMI, Optical and L/R audio. OUTPUT Rotation HDMI: 720P 1080P Press to select the HDMI input as the source VIDEO WALL USB-C: 1×1... -
Page 11: Ir Cable Pin Assignment
IR Cable Pin Assignment IR Receiver pin’s definition is as below: IR Receiver IR Signal IR RECEIVER Power Grounding Video Wall Video wall supports 8 modes as shown below: 1×1 2×2 1×2 2×1 3×1 4×1 1×4 1×3 Users can set the display mode via the front panel buttons, included remote, and RS-232 commands. -
Page 12: Rs-232 Control Command
RS-232 Control Command The product also supports RS-232 command control. Connect the RS-232 port of the product to a PC with a 3-pin phoenix connector cable and an RS-232 to USB cable. The connection method is as follows. Ground 3-pin Phoenix Connector RS-232 RS-232 to USB cable Then, open a Serial Command tool on PC to send ASCII command to... - Page 13 RS-232 Control Command Command Code Function Description Example Feedback Default Setting System Setting r fw mcu fw version : r fw version! Get firmware version version! x.xx.xx power on system Power on/off the initializing... device, z=0~1 s power z! s power 1! initialization (z=0 power off, z=1 finished!
- Page 14 RS-232 Control Command Command Code Function Description Example Feedback Default Setting Input Setting Set input x edid mode (x=0~2, z=1~6) x=0. all input x=1. input1 x=2. input2 s input 1 input 1 edid: s input x edid z! z=1. 4k60, 2.0ch 4k60,2.0ch edid 1! 4k60, 2.0ch...
- Page 15 RS-232 Control Command Command Code Function Description Example Feedback Default Setting Output Setting Get tv wall display r tw r tw mode! tv wall mode: 2x2 mode mode! tv wall Set tv wall horizontal s tw h tv wall horizontal s tw h bezel +! horizontal bezel...
- Page 16 RS-232 Control Command Command Code Function Description Example Feedback Default Setting Output Setting Set output y mirror output1: 0° (y=1~4, x=0,1) rotation y=1. output 1 output2: 0° s output y rotate y=2. output 2 s output 1 output1: 0° rotation y=3.
-
Page 17: Application Example
Application Example IR Receiver 2.0 Speakers Amplifier H - B E Z E L V - B E Z E L 1 × 2 1 × 3 1 × 4 2 × 2 1 × 1 2 × 1 3 × 1 4 ×... - Page 18 1-In-4-Out USB-C & HDMI Video Wall Controller UHD-14VW www.orei.com © 2023...
