ELLA PETITE WALK IN SPA BATH WITH MICROBUBBLES
OWNERS MANUAL
Representing Model Numbers:
03168M | 03167M | 03168MF | 03167MF
03168MH | 03167MH | 03168MFH | 03167MFH
IMPORTANT
Warranty Activation Form MUST be completed for both the Owner and Installer to
validate the warranty.
Failure to complete both pages will void the warranty on this bathtub.
Completed Ella Warranty Activation Forms can be emailed to warranty@ellasbubbles.com,
faxed to 312.666.3551, OR mailed to 2101 S. Carpenter St., Chicago, IL 60608
Advertisement
Table of Contents
Related Manuals for Ella's Bubbles ella 03168MF
Summary of Contents for Ella's Bubbles ella 03168MF
- Page 1 ELLA PETITE WALK IN SPA BATH WITH MICROBUBBLES OWNERS MANUAL Representing Model Numbers: 03168M | 03167M | 03168MF | 03167MF 03168MH | 03167MH | 03168MFH | 03167MFH IMPORTANT Warranty Activation Form MUST be completed for both the Owner and Installer to validate the warranty.
-
Page 3: Table Of Contents
Table of Contents Unpack and Inspect ............................1 Move your Ella Walk in Bath .......................... 2 Important Safety Instructions ........................3 - 4 Before Installation ............................5 Drain and Plumbing ............................6 Preparing the Sub-floor..........................7 Service Access and Ventilation ........................8 Door Seal ................................. -
Page 5: Unpack And Inspect
Unpack and Inspect NOTE: Returns are only accepted in original packaging used for shipping. Use caution so as not to damage cardboard crate or its wooden pallet. Do not dispose of shipping material until installation is complete. Please visit our website, www.ellasbubbles.com for complete details of return/exchange policy. -
Page 6: Move Your Ella Walk In Bath
Move your Ella Walk in Bath •Remove all four (4) access panels before moving the tub •Take off the screw caps •Unscrew the screws with a Philips head screwdriver Large Access Panel (1) •Remove the end access panel Small Access Panel (2) End Access Panel (4) White Screw Caps Screw... -
Page 7: Important Safety Instructions
Important Safety Instructions WARNING: ***Read through the entire manual completely before beginning installation.*** Contract a licensed plumber and electrician for installation. Be sure you and your contractor are aware and follow all local plumbing and electrical codes. Your Ella Walk in Bath is not intended for outdoor use. - Page 8 Important Safety Instructions (continued) WARNING: To prevent stripping the PVC threads, ONLY hand tighten the drain elbow. DO NOT tighten with tools. www.ellasbubbles.com Page 4 02/16...
-
Page 9: Before Installation
Before Installation Protecting the Bath Cover and protect the bath shell and fixtures from scratches or other damages during the installation and tests. Remove the access panels when moving the Walk in Bath and always lift the bathtub from the frame (Page #2). Water Test Fill tub for a minimum of 20 minutes to test that the pumps are functioning properly before final in-wall installation to avoid unnecessary repairs or removal. -
Page 10: Drain And Plumbing
Drain and Plumbing Make sure that the drain rough in has been placed at the proper location. The dual drain can be connected with a “T” or “Y” connection into existing house drain. Proper materials must be used based on local plumbing code requirements. NOTE: The customer and their contractor are responsible for using the appropriate solution to meet the current local construction and plumbing code requirements, proper drainage, and rodding access to the drain. -
Page 11: Preparing The Sub-Floor
Preparing the Sub-floor Prepare the sub-floor for the drain and ensure that the area is level. The supporting sub-floor must be able to support the total weight of the bathtub, bather and water. Use a level and make sure that the sub-floor below the tub is leveled. If the floor is not perfectly level, adjust the appropriate leveling legs to re-align the tub to perfect level. -
Page 12: Service Access And Ventilation
Service Access and Ventilation It is the responsibility of the installer or owner to provide access for service required, per code. Ella is not responsible for any costs related to obtaining access for repair. The owner shall assume responsibility for such costs, and if appropriate, must seek recovery from the installer. -
Page 13: Microbubble System Diagram
MicroBubble System Diagram (Front view) A. High Pressure, Low Flow 10.0 A Pump 1. Outlet Portion of Pump 2. Sucktion Portion of Pump B. Pressure Vessel 3. Patented Liquid Thin Film Device (Inside Vessel) www.ellasbubbles.com Page 9 02/16... - Page 14 MicroBubble System Diagram(Continued) (Side view) B. Pressure Vessel 3. Patented Liquid Thin Film (Front view) Device (Inside Vessel) C. Agitation Nozzle D. Outlet Port www.ellasbubbles.com Page 10 02/16...
-
Page 15: Water Supply Lines
Water Supply Lines The Ella Petite comes standard with a 5-Piece Fast Fill Roman Faucet Set. Please note: The 5-Piece Fast Fill Roman Faucet does not include the I.P.S. connection flexible water supply lines. MicroBubble On/Off Control NOTE: It is recommended that shut off valves are installed behind the opening and in reach from the small access panel. -
Page 16: Installation Of Spout
Installation of Spout ALWAYS INSTALL SPOUT BEFORE THE WALK IN BATH IS IN PLACE. Parts List: Rubber gasket x (1) Rubber washer x (1) Brass mounting nut x (1) To Install the supplied spout, first place the rubber gasket on the bottom of the spout and make sure it is properly seated in its groove. -
Page 17: Installation Of Deck Mount Grab Bar
Installation of Deck Mount Grab Bar Parts List: Chrome grab bar x (1) Escutcheon x (2) Rubber washers x (4) Metal washers x (2) Bolts x (2) Grab Bar Escutcheon Tub Shell Rubber Washer Rubber Washer Metal Washer* Bolt To install the supplied grab bar first locate all the parts needed for installation. See drawing shown above. -
Page 18: Finishing Installation
Finishing Installation After all of the water and electrical testing is completed and all fixtures are checked, the tub can be installed to the surrounding wall or walls. The Ella Petite Walk In Bathtub comes with a low rise tile flange which allows for two or one wall installations. Stud Stud Stud... -
Page 19: Operating Instructions
Operating Instructions MicroBubble On/Off Control 1. Using the Door: Entering the walk in bath, the door can be closed and locked with the handle from a seated or standing position. Do not apply any body weight on the door when entering or exiting the walk in bath. -
Page 20: Cleaning And Maintenance
Cleaning and Maintenance Recommended Acrylic Cleaners DO NOT USE the following on your ACRYLIC Bath System. The use of the Use only cleaning products whose labels state that they are SAFE for ACRYLIC. following chemicals will cause a dull Always test products on a small are of skirt surface or chemical cracks. -
Page 22: Warranty Information
Ella MicroBubble Walk In Bath Warranty Information This limited lifetime warranty is extended to the first purchaser to be free from defects in workmanship and material under normal use and conditions from the date of the original purchase. This warranty is nontransferable and applies only to the original owner and to the original installation place –... -
Page 24: Warranty Activation Form
Warranty Activation Form 1 of 2 INSTALLER'S INFORMATION _______________________________________________________________________________________ Name _______________________________________________________________________________________ Address City State _________________________________ _________________________________________________ Telephone Email _________________________________ _________________________________________________ Date Signature Upon completing the installation of an Ella Walk In Bath, the following Warranty Activation Form must be completed, signed by both the customer and installer, and returned to Ella’s Bubbles, LLC. - Page 25 Copy of sales receipt must be included with warranty activation forms. To activate manufacturer's warranty, please complete both pages and use one of the options below to submit. Via mail: Ella's Bubbles, LLC. Warranty Department 2101 S. Carpenter St., Chicago, IL 60608 Via fax: 1-312-666-3551 Via email: warranty@ellasbubbles.com...
