Summary of Contents for Totem HAMMER
-
Page 4: Section 1. General Information
Section 1. General Information 1.1 What's In the Box? 1 xBike frame with the rear wheel 1xWheel 1xSaddle 2xPedal 1 xDisc brake 1 xQuick release 2xReflector 1 xRear derailleur protecting rack 1 xCharger 1 xBattery 1 x Bike frame with the rear wheel 1x Wheel 1x Saddle 6xScrewM5*8.5... - Page 11 Step 7. Install the battery • Insert the battery into the middle frame. Turn the key to the locked position • To unlock the battery, insert the key, and turn it to the unlock position to pull the battery out &check whether the battery switch is turned on every time you ride - 11-...
- Page 12 Step 8. Install Front Reflector and Headlight • Take out the white reflector and 1 x screw M6*20 • Install the reflector on the headlight brackets • Tighten the screws with suitable tools and complete front reflector installation • Pre-installed wire for headlight can be found between the fork, plug the wire into the back slot of the headlight to connect headlight with battery. (Keep the wire in between two fork legs) Pass the bolt through headlight bracket and fender mounting point, lighten the bolt to install the headlight.
- Page 13 Check that it is securely connected to the wall and to the bike. • Use only the charger provided with your TOTEM E-Bike. If you have lost or misplaced your charger, contact customer support to obtain a replacement.
- Page 14 ® NOTE: • Fully charge the battery before your first use, this may take up to 3 hours. • Perform periodic visual inspections on the battery ports and charging cables. • Keep your charging environment clean and dry at all times. •...
-
Page 17: Buttons Information
4.3 Buttons Information TOTEM E-Bike's display features several different elements. : Quick-press to switch modes from high to low speed. Battery level Press and hold to activate walk-assist. � : Press and hold for -2 seconds to turn the E-Bike on/off. - Page 23 TOTEM USA Customer service 119S Tennessee Str eet, Mckinney,TX 75069 Tel: +1-812-807-1570 Website: www.totemusa.com January 2024 By TOTEM USA version 3 RoHS REACH()�...
