QUICK GUIDE etzMAX
The etzMAX is an ON-DEMAND Espresso Grinder for commercial or
domestic use, available in 4 versoins (LT/LM/P/X).
Models vary in design and scope of delivery
Fig.1
Fig.3
ATTENTION (W version only): Portafilter holder resp. the boom is connected to the weighing
cell. Improper use/assembly or excessive force (bending) can damage the weighing cell or
have a negative impact on its function.
GRIND ADJUSTMENT
The adjustment (5) consists of a stepped macro (upper ring, distance 0.1mm) and a stepless micro adjustment (lower ring, distance 0.01mm).
ROUGH
FEIN
BEAN HOPPER
1.
Turn both locking levers backwards (1)
2.
Place the bean hopper on the holder (2) with
the bean-stop-lever on the right
3.
Close both locking levers and turn the bean-
stop-lever 180° backwards to the OPEN
position
4.
The bean feeder is now open.
Fig.2
PORTAFILTER HOLDER
1.
To adjust, press the back of the holder with
your index finger while moving the holder
arm up/down with your thumb (3)
2.
Once adjusted, slide the holder onto the
boom until it engages (4)
Fig. 4
Recommended settings
Fig.5
(dependent on roast/roast level)
Ristretto: Macro 4-8, Micro 1
Espresso: Macro 6-10, Micro 1
LonghI: macro 8-12, micro 1
NOTE: Adjustment of more than 1 step on the macro ring
or more than 5 steps on the micro ring should only be
executed while grinding
Etzinger AG
Wirtschaftspark 44
FL-9492 ESCHEN
Phone +423 375 8383
PROGRAMMING
The
3
exclusively to set the grinding time in seconds
(GbT models) or the weight setting in grams (GbW
models).
Factory setting
T models: 1=4.3 sec / 2=5.6 sec / 3=7.0 sec
W models: 1=14g / 2=18g / 3=22g
Adjust the doses:
1.
Select a button (1, 2, 3)
2.
Press + / - to adjust time (sec) or weight (g).
3.
Once the desired grinding time or weight has been reached, press and
hold the corresponding button for 3 seconds. When the display
flashes and an alert sounds (GbW only), the setting is confirmed.
4.
To program the other buttons, repeat points 1-3
W models: If the grinder is in time mode when starting up, press STOP
and 1 simultaneously (for 5 seconds) to enter weighing mode.
With the grinder running, turn the macro ring to the right for
finer settings (FINE direction) or to the left for coarser
settings (COARSE direction).
The pointer marks the selected setting
The stepless micro ring ranges from coarse (11) to fine (1)
and may be used for fine tuning
Notch 1 on the macro ring serves as the zero point for the
micro adjustment.
programmable
buttons
are
used
