Etzinger etzMAN Quick Start Manual

QUICK START GUIDE etzMAN
etzMAN is a Standalone Manual Coffee Grinder that
may be used to grind whole, roasted beans.
Carefully unpack grinder and verify delivery contents according
to attached list. Clean all loose parts with a soft damp cloth
and allow to dry completely before use.
Fig. 1
Fig. 2
Fig. 3
Fig. 4

INSTALLING BEAN HOPPER

Push both locking levers rearwards
(arrow direction OPEN, Fig. 1).
Position cap / hopper (bean-blocker handle to the right)
at intended opening.
Rotate bean-blocker by 180° into OPEN-position (Hopper)
and close locking levers (Fig. 2). Fill in the beans and close
lid (Hopper).
PORTAFILTER-HOLDER
Use your index finger to press against the rear part
part of the upper holding arm (Fig. 3) while sliding the
arm in position with your thumb – up/down.
Once adjusted, insert it onto the center hook (Fig. 4)
and slide it rearwards as far as it will go.

ADJUSTMENT

The Adjustment (Fig. 5) consists of a stepped macro adjust and a stepless micro adjust.
Recommended settings (final setting depends on roast&brand; coarser settings for lighter roasts)
Ristretto / Espresso / Longhi Macro 4-8 / 6-10 / 8-12
Fig. 5

INSTALLING CRANK

Position and insert crank at intended outlet until clicked into place.

USING / OPERATE your etzMAN

Before using your etzMAN, make sure for the Bean-Blocker-Handle to be in OPEN position (if
operated with Hopper). Turn the crank counter-clockwise while holding on to the upper backside
of the grinder for stability. Use the enclosed cloth/glove (Delivery Content) to protect the grinders´
surface while grinding. Beware of edges when stabilizing the grinder while rotating the handle.
Use STANDARD-cone for traditional roasts or Pour Over, use ETZI-cone for lighter roasts.

REMOVING SINGLE DOSING CAP / HOPPER

Close bean-blocker by turning it to the front (Hopper). Open locking levers.
Lift off cap / hopper and place it on its lid.
Micro 1
The macro adjust includes 16 steps (à 0.1mm).
To move from coarse (16) to fine (1), turn the
macro- (top) ring to the right (Direction FINE).
To move from fine to coarse, turn the macro ring
to the left (Direction COARSE). The pointer
indicates your macro-setting. The micro adjust
(bottom ring) ranges from coarse (11) to fine (1)
steplessly (0.01mm) and allows for even more
precise grind settings (Click 1 on macro ring
serves as reference point for the micro ring).
