- Page 1 AQUA T SERIES UNDERGROUND WATER FINDER Operation Manual...
- Page 2 AQUA-T SERIES OPERATION MANUAL Underground Water Finder ACKNOWLEDGMENT: Results are instantly shown on the screen when you need them most. If you need additional training, a second opinion on the data, or wish to seek out our expert advice on a course of action?
-
Page 3: Table Of Contents
AQUA-T SERIES OPERATION MANUAL Underground Water Finder TABLE OF CONTENTS Product Overview & What’s Included Technical Specifications Introduction & Working Principle Advantages Handheld Host Device Getting Started Grid and Cross Method Advised Measurement Approach Operation Process Measurement: Preparatory work How To Analyze The Data... -
Page 4: Product Overview & What's Included
AQUA-T SERIES OPERATION MANUAL Underground Water Finder PRODUCT OVERVIEW & WHAT’S INCLUDED: Handheld Host Device Electrode cable M N Connector Handles Copper electrode... -
Page 5: Technical Specifications
AQUA-T SERIES OPERATION MANUAL Underground Water Finder TECHNICAL SPECIFICATIONS: Model Cha- Depth Accuracy Frequency Other nnel • Automatic noise reduction with strong anti-interference ability. • Interactive and DC12V Single, triple Industrial user-friendly interface, 4000mAh and 33- AQUA-T1 0.001mv 7-inch HD... -
Page 6: Introduction & Working Principle
INTRODUCTION & WORKING PRINCIPLE: The AQUA-T Series is a geophysical prospecting device powered by natural electric fields, designed to detect underground water. It measures changes in resistivity in rocks and minerals using the Earth's natural electric field, providing a simple and lightweight solution for water detection. - Page 7 AQUA-T SERIES OPERATION MANUAL Underground Water Finder High Performance and Accuracy: Offers a measurement resolution of up to 0.001mV and a precision level of ±2%. This system ensures high stability and matches abnormity curves observed with traditional geo-electrical equipment across various field surveys.
-
Page 8: Handheld Host Device
AQUA-T SERIES OPERATION MANUAL Underground Water Finder HANDHELD HOST DEVICE: High Measurement Speed and Efficiency: System Reset Button Memory Card Test Light M N Port USB Port Power Light Power Switch LCD Screen 1. LCD Screen: Shows different operational states and measurement outcomes, including measurement data, curve graphs, and profile maps pertinent to the instrument's... -
Page 9: Getting Started
AQUA-T SERIES OPERATION MANUAL Underground Water Finder 3. M N Port: Input terminal for the M and N electrode connectors. 4. USB Port: Establishes a connection between the host machine and a computer using a connection cable or links to an Android mobile phone with an OTG cable to transfer data files, curves, and profile maps. - Page 10 AQUA-T SERIES OPERATION MANUAL Underground Water Finder 1. Single Frequency Measurement State: Once you are on the main screen, double-tap on "single-frequency" to access single-frequency measurements. This action allows you to perform operations associated with single-frequency measurements, as illustrated in the figure below: i.
- Page 11 AQUA-T SERIES OPERATION MANUAL AQUA-T SERIES OPERATION MANUAL Models: AQUA-T1/AQUA-T3/AQUA-T5 Underground Water Finder iii. Options: "Select the 'Options' button, triggering the appearance of a dialogue box labelled 'Options,' as depicted in Figure below; The device can save up to 999 measurement lines, with each line capable of storing 999 measurement sites.
- Page 12 AQUA-T SERIES OPERATION MANUAL Underground Water Finder iv. Delete: In cases of accidents or unresolved data anomalies during the measurement process, it may be necessary to remove data from the previous measuring site. To achieve this, click on the 'delete' button, which will remove the last column in the table.
- Page 13 AQUA-T SERIES OPERATION MANUAL Underground Water Finder 2. Three Frequency Measurement State: Enter the Three-frequency measurement state, LCD display is shown below; Line Test, Delete, Return, Record, the function of recording introduced during the Single Frequency measurement state. Choices: Click the "Options" button to open the "Options" dialogue box (as seen in Figure).
- Page 14 AQUA-T SERIES OPERATION MANUAL Underground Water Finder 3. Profile Survey Measurement State: Enter profile survey measurement state, LCD display is shown below; To access the Single Frequency Measurements, begin by selecting 'Line Test' from the main screen. Then, click on the 'Options' button to open the 'Options' dialogue box.
- Page 15 AQUA-T SERIES OPERATION MANUAL Underground Water Finder Profile Curve: In the ongoing survey line, each measuring point automatically generates a curve by the system. After the measurement is complete, you can adjust the size by clicking on the "+" icon. To save the curve and its associated data, click the "Export" button.
- Page 16 AQUA-T SERIES OPERATION MANUAL Underground Water Finder The folder within the profile survey is organized by line numbers, such as 'L1,' 'L2,' 'L3,' and so forth. Once the measurement is finished, easily access the 'File Export' and 'Profile' options for the curve. Inside each line folder, find three files: 'System volume inf,' 'Profile Survey,' and 'Three Freq.' Connect the device to your computer...
- Page 17 AQUA-T SERIES OPERATION MANUAL Underground Water Finder Language & Time screen AQUA-T5 About Touch Calibration screen...
-
Page 18: Grid And Cross Method
AQUA-T SERIES OPERATION MANUAL Underground Water Finder GRID AND CROSS METHOD: Geophysical survey lines are usually positioned perpendicular to the area being examined, allowing for the identification of tectonic crushed zones and their distinct physical attributes on both sides of the boundary. These zones exhibit clear contrasts, highlighting differences in crushing width and unique extensions. -
Page 19: Advised Measurement Approach
AQUA-T SERIES OPERATION MANUAL Underground Water Finder Note: It is advisable to insert the rods into dampened soil for each placement. Before tapping the "Record" button, tap the "Line Test" button to confirm proper grounding. The “green light” indicator will illuminate upon successful grounding (connection between the two rods), allowing the measurement process to proceed. -
Page 20: Operation Process
AQUA-T SERIES OPERATION MANUAL Underground Water Finder Grid Method: OPERATION PROCESS: Wiring direction & Location: Take a tape measure and measure 10 meters. Mark the starting point as 0 meters. The MN two-electrode rods should be distanced 10 meters apart, with both MN electrodes moving 1 meter after measuring each point. -
Page 21: Measurement: Preparatory Work
AQUA-T SERIES OPERATION MANUAL Underground Water Finder (Note: It is recommended to take measurements and scans at a 10 meter MN equidistance, with both MN electrodes moving 1 meter between each scan. This is because the water detector was designed for a 10 meter MN equidistance, and altering the MN equidistance affects the measurement depth.) - Page 22 AQUA-T SERIES OPERATION MANUAL Underground Water Finder 2. Three Frequency: (General testing) In the three-frequency mode, 170Hz is used for shallow levels, 67Hz for middle levels, and 25Hz for deep levels, but the depth in this mode cannot be directly determined.
- Page 23 AQUA-T SERIES OPERATION MANUAL Underground Water Finder Measurement Points: It is advisable to measure at least 15 points for each line, but no more than 30 points for optimal completion of the geological scan (15 points provide a comprehensive view).
-
Page 24: How To Analyze The Data
AQUA-T SERIES OPERATION MANUAL Underground Water Finder For measurements, we recommend the following approach: Divide the measurement area into three parallel lines, all starting at the same point. Each line should be a distance of 1 meter apart. The three parallel lines display similar profile maps of the underground geological structure. - Page 25 AQUA-T SERIES OPERATION MANUAL Underground Water Finder From the curve below, identify the "V" pattern characterised by a significant number of falling curves. Low values indicate low potential difference data, suggesting a higher probability of water. In the example provided, observe the "V" pattern at both point 4 and point 8.
- Page 26 AQUA-T SERIES OPERATION MANUAL Underground Water Finder From the provided map: • Blue: Represents low values, indicating a high probability of water presence. • Yellow: Indicates medium values, suggesting a higher probability of encountering rock. • Red: Signifies high values, implying the possibility of a cave or hard rock.
- Page 27 AQUA-T SERIES OPERATION MANUAL Underground Water Finder Analysis: The customer drilled a water well at Point 8, reaching water at a depth of 60 meters. The final well depth is 150 meters, and the well yields a water quantity of 24 cubic meters per hour.
-
Page 28: Safety Instructions
AQUA-T SERIES OPERATION MANUAL Underground Water Finder SAFETY INSTRUCTIONS: Read the operating instructions and act accordingly. • Unpack the product carefully. • Store the product in a dry place out of reach of children. • If the cord becomes damaged, unplug it immediately and turn the device off. - Page 29 WWW.AQUALD.COM...
