AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector TABLE OF CONTENTS Each Unit Includes Technical Speci�cations Introduction Working Principle Getting Started Operation Instructions Safety Instructions Maintenance...
Page 3
Multi-Sensor Acoustic Pipe Leak Detector THANK YOU! Dear customer: Thank you for purchasing the AQUA-L Series Multi-Sensor Acoustic Pipe Leak Detector! We always endeavor to bring you products that let you live life on your terms. The AQUA-L Series is our newly updated and multi-functional acoustic pipe leak detector that is used to detect leaks in underground indoor and outdoor water piping, fire piping, heating systems, underground heating floor piping/systems, etc.
Page 4
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector ACKNOWLEDGMENT: Our leak detection equipment is specifically made to produce accurate and detailed readings. Results are instantly shown on screen when you need them most. If you need additional training, a second opinion on the data, or wish to seek out our...
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector EACH UNIT INCLUDES: Aqua-L7 Aqua-L1 • Display Screen • Display Screen • Wall sensor • Wall sensor Medium outdoor Sensor • • Indoor floor sensor • Large outdoor Sensor Note: Each unit includes the user manual &...
The AQUA-L Series is our premium range of multi-sensor acoustic pipe leak detectors. Designed by geotechnical engineers and hands-on technology experts, the AQUA-L Series offers exceptional precision, ease of use, and accessibility that you can truly count on. Its impressive ability to penetrate a large variety of surface areas to a maximum depth of 5 meters, can reveal a pipe leak within walls and below the ground from the bathroom to ovals and fields to carparks, major roads and highways.
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector GETTING STARTED: 1. Preparation: For detecting a pipe leak in an outdoor environment: a. Confirm that a pipe leak is in fact present. This can be done by tracking water loss via a water main/water meter. Unexplained water puddles also indicate a possible burst within a pipeline.
Page 9
Multi-Sensor Acoustic Pipe Leak Detector 2. Sensor selection: Our “AQUA-L Series” offers a variety of sensors. It is very important to choose the correct sensor for detecting a leak. The sensors included in the kit (depending on the model) are;...
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector Step: 3 Connect the noise-cancelling headphones to the display screen via the provided AUX cable and place it comfortably over your head. (AUX allows for instantaneous sound). Note: The above steps are for general use and should be followed before operating the product.
Page 11
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector b. Press the “Outdoor” option to perform different functions for outdoor use, as shown in the figure below; AQUA-L7 Sensor detecting Battery Time Note: Select the appropriate sensors according to different outdoor detection environments for example “Medium Sensor”...
Page 12
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector Choose the correct options according to the actual situations like; a. Select the soil texture e.g., "Soft” or “Hard". b. Select the pipe material e.g., “Plastic” or “Metal” or “Unknown” according to the detecting environment.
Page 13
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector AQUA-L7 AQUA-L7 • In the suspected leakage area, start detection from the first point, and click any position in the spectrum bar the signal value will be displayed on the top of the spectrum bar.
Page 14
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector e. To record the leakage sound on the spot, select the “Recording” option, the following page will appear; AQUA-L7 Click the “MIC” option, to turn on the user’s voice recording. • Click the “Recording” button to start the voice recording, to stop click the •...
Page 15
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector 2. For Indoor Operation: These preparations are mainly used for indoor operations and follow the steps below for indoor operation; a. Press the “Indoor” option to perform different functions for indoor use.
Page 16
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector • Press down on the knob switch, to receive the sound. • Pay attention to the sound volume and observe the spectrum change on the screen. • When the spectrum on the “display screen” is high and the sound has significantly increased, the area can be identified as a suspected leak point.
Page 17
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector d. To record the leak sound on the spot, select the “Recording” option, following page will appear on the screen; AQUA-L7 AQUA-L7 Click the “MIC” button, to turn on the user’s voice recording.
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector Adjust the date in the “Date Settings” section. • Adjust the time in the “Time Settings” section. • Adjust the “Brightness” in the “Brightness settings” section by moving the point • from left to right.
AQUA-L SERIES MANUAL Multi-Sensor Acoustic Pipe Leak Detector MAINTENANCE: • Do not throw or drop the device. • To reduce the risk of damage to the electric plug and cord, pull by plug rather than by cord when disconnecting the unit.
