- Page 1 Solar HVAC - Model “Z” Residential Mini-Splits and Mounting Kits I/O/M manual PD 07/25/2023 - v 1.00 PN IOM-0052...
-
Page 2: General Description
The information, specifications and parameter are subject to change due to technical modification or improvement without any prior notice. The accurate specifications are presented on the nameplate label. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 3: Table Of Contents
Appendix 1 - Celcius-Fahrenheit Comparison ....................68 Appendix 2 - Pipe Length and Gas Charging ....................68 Appendix 3 - Pipe Flaring ..........................69 Appendix 4 - Thermistor Temperature Characteristics ................70 - 72 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 4: Safety Information
May cause minor to severe burning. Failure to follow this electrical suppl y. Caution could result in property damage or personal injur y. Do not touch top of compresso r. iAIRE, LLC iAIRE Zero Solar HVAC I/O/M iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 5: Part Number And Description
Through a patented process, ambient light is converted to thermal energy which reduces the energy demand on the compressor. Units come with a 1-year parts warranty. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M PNS-0030 PD 07/02/2023 - v 1.03... -
Page 6: Btu Heat Pump Dimensions
SHMSPZ-09 | Solar HVAC Model “Z” Mini-Split Dimensions Indoor Unit Outdoor Unit Model in (mm) 31.93 11.5 8.07 28.15 11.42 19.61 21.11 13.73 12.62 1.97 2.48 SHMSPZ-09 (811) (292) (205) (715) (290) (498) (536) (349) (321) (50) (63) Intdoor Unit:... - Page 7 SHMSPZ-09 | Solar HVAC Model “Z” Mini-Split Dimensions (cont’d) 12.88 23.88 8.81 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 8: Btu Heat Pump Specifications
SHMSPZ-09 | Solar HVAC Model “Z” Mini-Split Specifications Electrical - Mechanical Specifications Control type remote Power supply 208/230V~/60Hz/1P Rated cooling capacity (95F/35C) Btu/h 9000 "Rated Cooling (95F/35C)" EER2 (95F/35C) Btu/W.h SEER2 Btu/W.h Rated Heating Btu/h 10000 capacity(47F/8.3C) HSPF2 Rating (Region IV) Btu/W.h... - Page 9 SHMSPZ-09 | Solar HVAC Model “Z” Mini-Split Specifications (cont’d) Weight and Packing Dimensions 811x292x205 Indoor inch 31.92x11.49x8.07 715x290x498 Net dimensions (W x D x H) Outdoor inch 28.14x11.42x19.61 603.76x324.36x225.3 Solar Box inch 23.77x12.77x8.87 Indoor 19.8 Net weight Outdoor 48.5 11.36363636...
-
Page 10: Btu Heat Pump Dimensions
Outdoor Unit Model in (mm) 31.93 11.5 8.07 28.15 11.42 19.61 21.11 13.73 12.62 1.97 2.48 SHMSPZ-12 (811) (292) (205) (715) (290) (498) (536) (349) (321) (50) (63) Intdoor Unit: Outdoor Unit: iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 11 SHMSPZ-12 | Solar HVAC Model “Z” Mini-Split Dimensions (cont’d) 12.88 23.88 8.81 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 12: Btu Heat Pump Specifications
Size x Core number 4×16AWG inches 3/8'' Connecting Pipe Liquid inches 1/4'' Maximum Line Length (m/ft) 15 / 50 Maximum Height Difference Between Indoor and Outdoor (m/ft) 10 / 33 SUB-0100-SHMS-P1 PD 02/03/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 13 Unit should be UL 1995 listed Unit should be OG-100 Certified to the Solar Certification on ICC901/SRCC100 Face Solar Panels south for optimal performance *Gross = Net Weight + Shipping Box SUB-0100-SHMS-P1 PD 02/03/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 14: Btu Heat Pump Dimensions
Outdoor Unit Model in (mm) 39.76 12.4 8.66 30.71 13.74 23.82 23.03 16.53 15.19 1.97 2.48 SHMSPZ-18 (1010) (315) (220) (780) (349) (605) (585) (420) (386) (50) (63) Intdoor Unit: Outdoor Unit: iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 15 SHMSPZ-18 | Solar HVAC Model “Z” Mini-Split Dimensions (cont’d) 12.88 39.63 8.81 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 16: Btu Heat Pump Specifications
Size x Core number 4×16AWG inches 3/8'' Connecting Pipe Liquid inches 1/4'' Maximum Line Length (m/ft) 20 / 65 Maximum Height Difference Between Indoor and Outdoor (m/ft) 15 / 49 SUB-0100-SHMS-P.5 PD 02/03/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 17 Unit should be UL 1995 listed Unit should be OG-100 Certified to the Solar Certification on ICC901/SRCC100 Face Solar Panels south for optimal performance *Gross = Net Weight + Shipping Box SUB-0100-SHMS-P.5 PD 02/03/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 18: Btu Heat Pump Dimensions
Outdoor Unit Model in (mm) 46.93 14.17 10.24 33.27 14.96 27.52 24.95 17.99 16.54 1.97 2.48 SHMSPZ-24 (1192) (360) (260) (845) (380) (699) (634) (457) (420) (50) (63) Intdoor Unit: Outdoor Unit: iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 19 SHMSPZ-24 | Solar HVAC Model “Z” Mini-Split Dimensions (cont’d) 12.88 39.63 8.81 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 20: Btu Heat Pump Specifications
Size x Core number 4×16AWG inches 1/2" Connecting Pipe Liquid inches 1/4'' Maximum Line Length (m/ft) 20 / 65 Maximum Height Difference Between Indoor and Outdoor (m/ft) 15 / 49 SUB-0100-SHMS-P2 PD 02/03/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 21 Unit should be UL 1995 listed Unit should be OG-100 Certified to the Solar Certification on ICC901/SRCC100 Face Solar Panels south for optimal performance *Gross = Net Weight + Shipping Box SUB-0100-SHMS-P2 PD 02/03/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 22: Btu Heat Pump Dimensions
Outdoor Unit Model in (mm) 46.93 14.17 10.24 35.83 14.17 31.5 26.87 17.05 15.67 1.97 2.48 SHMSPZ-36 (1192) (360) (260) (910) (360) (800) (683) (433) (398) (50) (63) Intdoor Unit: Outdoor Unit: iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 23 SHMSPZ-36 | Solar HVAC Model “Z” Mini-Split Dimensions (cont’d) 18.88 40.71 8.86 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 24: Btu Heat Pump Specifications
Size x Core number 4×16AWG inches 5/8'' Connecting Pipe Liquid inches 1/4'' Maximum Line Length (m/ft) 30 / 98 Maximum Height Difference Between Indoor and Outdoor (m/ft) 20 / 65 SUB-0100-SHMS-P3 PD 02/03/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 25 Unit should be UL 1995 listed Unit should be OG-100 Certified to the Solar Certification on ICC901/SRCC100 Face Solar Panels south for optimal performance *Gross = Net Weight + Shipping Box SUB-0100-SHMS-P3 PD 02/03/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 26: Installation Clearances
SHMSPZ-xx | Solar HVAC Model “Z” Mini-Split Clearances iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 27: Mounting Kit Part Numbers And Description
Solar Boxes are ordered separately. Customer must provide their own lagging and plumbing hardware. Wall Mounted Floor Mounted Roof Mounted SUB-0029-Z5DF PD 02/18/23 V02.06 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M PNS-0032 PD 06/27/2023 - v 1.00... -
Page 28: Ton Mounting Kit Dimensions
27 7/16" 21 7/8" back strut channel to 696.7mm 3 5/16" 556mm mount to any wall. 83.9mm Approximate “Minimum” Angle Approximate “Maximum” Angle SUB-0030-SLR-MNT-1.25 PD 06/29/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 29: Ton Mounting Kit Dimensions
41 3/16" 29 13/16" to any position along 1045.9mm 3 7/16" 757.7mm back strut channel to 87.6mm mount to any wall. Approximate “Minimum” Angle Approximate “Maximum” Angle SUB-0030-SLR-MNT-2.50 PD 06/29/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 30: Ton Mounting Kit Dimensions
41 11/16" 30 1/8" to any position along 1058.4mm back strut channel to 765.6mm 3 7/16" mount to any wall. 87.6mm Approximate “Minimum” Angle Approximate “Maximum” Angle SUB-0030-SLR-MNT-3.75 PD 06/29/23 V01.00 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 31: Wiring Diagrams
Air Conditioner Service Manual 3. Electric Diagram Wiring Diagrams 3.1 Wiring diagram MODEL: 9K, 12K, 18K, 24K _ Power Supply from Indoor INDOOR UNIT： OUTDOOR UNIT θ θ θ iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 32 Air Conditioner Service Manual Wiring Diagrams (cont’d) MODEL: 9K, 12K, 18K, 24K _Power Supply from Outdoor INDOOR UNIT： OUTDOOR UNIT： iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 33 Air Conditioner Service Manual Wiring Diagrams (cont’d) INDOOR UNIT： OUTDOOR UNIT： θ θ θ iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 34 Air Conditioner Service Manual Wiring Diagrams (cont’d) INDOOR UNIT: OUTDOOR UNIT： ¦ ب ¦ ب ¦ ب ،« iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 35 Air Conditioner Service Manual 4. Electric Diagram Wiring Diagrams (cont’d) 4.1 Wiring diagram INDOOR UNIT ： MODEL： 36000BTU(230V/60Hz) OUTDOOR UNIT： MODEL:36000BTU(230V/60Hz) iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 36: Pcb Layouts - High Voltage
DC fan motor connection IDU/ODU wiring connection --N connector Power supply --N connector Anion connector IDU/ODU communication wiring Left-Right swing connector Up-Down swing connector Display Emergency button Temperature sensor connection WIFI connection iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 37 IDU/ODU wiring connection --N connector Power supply --N connector Anion connector IDU/ODU communication wiring Left-Right swing connector 10 Up-Down swing connector 11 Display 12 Emergency button 13 Temperature sensor connection 14 WIFI connection iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 38 PCB Layouts (cont’d) Air Conditioner Service Manual PCB type: A010403 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 39 9K, 12K PCB type: A010313 Mainly relay Fuse L, N & 1 (communication) wiring 4-way valve Heater motor connector Electronic expansion valve Discharge sensor connector OAT/OPT sensor connector LED5 PCB type: A010386 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 40 Electronic expansion valve AC/DC motor connector Heater 4-way valve LED5 Communication wiring Fuse L , N line Mainly relay LED1-LED4 Note: OAT: Outdoor Ambient Temperature OPT: Outdoor pipe temperature iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 41: Remote Control
ODU PCB Mainly relayRY- DC Motor connector CN12-2 Electronic expansion valveCN7 Discharge sensor connector OAT/OPT sensor connector LED5 AC Motor connector P9 LED1-LED4 Note: OAT: Outdoor Ambient Temperature OPT: Outdoor pipe temperature iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 42 SLEEP function Health function I FEEL function heating function Signal indicator Gentle wind Child-Lock Display ON/OFF The display and some functions of the remote control may vary according to the model. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 43 The shape and position of buttons and indicators may vary according to the model, but their function is the same. The unit confirms the correct reception of each button with the beep. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 44: Electronic Controller Information
1). While unit: a. switched off. b. under protection. c. to the set temperature. After compressor ceased, the fan motor stops working according to the temperature of OPT and OAT, the max iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 45 RT-CRT≤－1℃(-1.8℉) and compressor works in lowest frequency for 10 min continuously, The compressor stops operation. 3). The compressor frequency control: Based on relation of RT & ST, and the changing speed of RT. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 46 Defrosting start up: Compressor stops working, and re-starts to working after 50s delay; Conditions for quitting defrosting After defrosting 60s, and OAT≥12℃(53.6℉); or OAT＜－5℃(-41℉), and OPT ≥8℃(46.4℉) for 80s continuously; or iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 47 5.2.5.3. ODU always OFF. ℉) δt goes up ℃( δt comes down 4℃(7.2) 4(7.2) High fan 2(3.6) Mid fan ℉) 2℃(3.6 0(0) Low fan iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 48 In the process of operation, once the compressor runs continuously more than 6 min, the counter of over load stop-working protection will be reset to zero and start a new counting process. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 49 The failure and times for protection will eliminate immediately once the unit to be switched off, or changed to fan iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 50 1) Cooling mode. 2) set temperature to 30℃. 3) Mid-fan speed. by press ECO button 7 times within 8s, the unit will change to calibration test mode, and the buzzer sounds 3 times. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 51: 24K Installation And Maintenance
3) When installing the indoor unit and outdoor unit, a sufficient fixing bolt must be installed, make sure the installation supporter is firm. 4) Ware safety belt if the height of working is above 2m. 5) Use equipped components or appointed components during installation. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 52 )) 2 Where: is the allowable maximum charge in a room, in kg; M is the refrigerant charge amount in appliance, in kg; is the required minimum room area, in m2; iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 53 It is a must to do the safety inspection before maintaining or repairing an air conditioner using combustible refrigerant in order to ensure that the fire risk is reduced to minimum. 1) Installation Safety Installation Safety Principles Site Safety Open Flames Prohibited Ventilation Necessary iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 54 10%. Detector C) The concentration detectors should be calibrated regularly. D) It is necessary to check and confirm the functions before using the concentration detectors. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 55 At the time of maintenance, it is necessary to ensure well-ventilation on the site. It is prohibited to use fire including welding, smoking or other purposes. It is prohibited to use mobile phones. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 56 It is necessary to ensure that the maintenance location is well-ventilated. Before welding the outdoor unit, it is a must to confirm that the refrigerating system has been drained iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 57 LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 58: 24K Tools And Accessories
Safety Glasses Wrench Flat blade) Manifold Torque Work Gloves Wrench Gauges Hex Keys Level Refrigerant Scale Allen Wrenches Drill & Drill Flaring Micron Gauge Bits tool Clamp on Hole Saw Meter iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 59: 36K Installation And Maintenance
Install the indoor unit at a height of at least 2.5m from the ground. Minimum space to be left (mm) showing in the iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 60 (see name plate on the unit) and according to all current national safety code requirements. 5).The cable connecting the outdoor and indoor units must be suitable for outdoor use. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 61 When extending the rolled pipe, straighten the pipe by unwinding it gently as shown in the picture. Extending the rolled pipe iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 62 3. For the electrical connections, see the wiring diagram on the back of the cover 4. Fasten the cables with a cable-clamp. 5. An efficient earth connection must be ensured. 6. Replace the covers. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 63 Liquid valve gas valve service port nut protection caps iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
-
Page 64: Mounting Kit General Assembly Instructions
20.000in 508mm DETAIL C SCALE 1 : 8 BLT HHCS 3_8-16X1 GR5 ZP LW 3/8 FW 3/8" Strut Chnl Brkt, Elbow, 5-3/8" x 3-1/2", ZP DETAIL B SCALE 1 : 8 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 65: Mounting Kit Floor And Roof Assembly Instructions
To mount Solar Box to a floor or roof, lay the frame with the cross braces on the bottom facing downward. Assembly of components are exactly the same as the wall mounting configuration; see previous page for detailed instructions. Wall Mounted Floor Mounted Roof Mounted iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 66: Vacuum And Leakage Testing
Press MODE button the select AUTO, COOL, DRY, FAN and HEAT to check whether the operation is normal or not. If ambient temperature is lower than 16°C(60.8℉), the air conditioner can’t start cooling. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 67: Mini-Split Plumbing Diagram
SOLAR HVAC MINI-SPLIT SCH-0019-P HP PIPING DIAGRAM Solar HVAC Mini-Split Plumbing Diagram REVISION: V0 0 1 1 . . 0 0 0 0 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 68: Appendix 1 - Celcius-Fahrenheit Comparison
Standard length Model length (m/inch) charging: Xg= B * (A-5m/196inch) (m/inch) 9000BTU 3.0/118.2 15/591 20g/m(0.018oz/inch) 12000BTU 15/591 3.5/137.9 20g/m(0.018oz/inch) 18000BTU 15/591 5.0/197 30g/m(0.026oz/inch) 24000BTU 15/591 5.0/197 30g/m(0.026oz/inch) 36000BTU 15/591 5.0/197 30g/m(0.026oz/inch) iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 69: Appendix 3 - Pipe Flaring
Firmly hold copper pipe in a die in the dimension shown in the table above. D. Check 1) Compare the flared work with figure below. 2) If flare is noted to be defective, cut off the flared section and do flaring work again. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... -
Page 70: Appendix 4 Thermistor Temperature Characteristics
1.459 94(201.2) 0.535 0.475 5(41) 11.378 3.452 50(122) 2.032 1.425 95(203) 0.521 0.463 6(42.8) 10.893 3.406 51(123.8) 1.965 1.391 96(204.8) 0.507 0.452 7(44.6) 10.431 3.358 52(125.6) 1.901 1.357 97(206.6) 0.493 0.441 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M... - Page 71 111.3 124.4 41(105.8) 10.21 10.85 95(203) 1.493 1.549 1.604 -12(-53.6) 105.6 131.7 42(107.6) 9.231 9.813 10.42 96(204.8) 1.448 1.502 1.558 -11(-51.8) 100.3 111.9 124.7 43(109.4) 8.878 9.43 97(206.6) 1.404 1.458 1.512 iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
- Page 72 -3(37.4) 66.96 74.11 81.96 51(123.8) 6.548 6.912 7.289 105(221) 1.105 1.153 1.202 R—Resistance Resistance at 25℃(77℉):20 kΩ TH3: Outdoor unit discharge pipe sensor Before measuring resistance, disconnect connectors as shown above. iAIRE, LLC SHVAC Residential Mini-Split and Mounting Kit I/O/M...
