- Page 1 FLEXLOCK ™ USERS MANUAL...
- Page 2 EN14225-2. INTENDED USAGE The FlexLock™ system is designed for sealing wrists on diving drysuits. The system consists of two parts a flexible suit ring and a silicone wrist seal. The silicone seal, specially designed for the system, is mounted in the suit ring by being securely clamped inside the ring.
- Page 3 -2°C - 35°C SYSTEM PARTS Locking edge Outer part Groove Inner part 1.Warm Cuff 2. White edge on silicone seal 3. Flexlock ring 4. Silicone WristSeal 2. White edge on silicone seal 4. Silicone WristSeal FlexLock Manual 231115 Waterproof Diving Intl AB...
- Page 4 SEAL REPLACEMENT 1. Expose the FlexLock ring by folding back 2. Open up the transparent ring by folding the warm cuff. back the outer part completely. Remove the seal. 3. Ensure the sealing area in the ring and the 4. Place bottom of the seal above the groove, bottom part of the silicone seal are completely as close to the transparent ring as possible.
- Page 5 12. Pull the seal firmly a few times and check the outer ring at this location and push the the white line again. seal inwards. Let the outer ring down and check that the white line is straight. FlexLock Manual 231115 Waterproof Diving Intl AB...
- Page 6 The warranty will not apply if the equipment sold was used or maintained contrary to the conditions detailed in this manual. The warranty becomes void if the Flexlock System is modified by a person or workshop not authorized by Waterproof.
- Page 8 WATERPROOF DIVING INTERNATIONAL AB Industrivägen 39, 433 61 Partille, Sweden Ph +46 31 336 82 70 info@waterproof.eu www.waterproof.eu...
