Garmin BlueNet Installation Instructions

Network device stacking bracket

GARMIN BLUENET

NETWORK DEVICE STACKING BRACKET

™

INSTALLATION INSTRUCTIONS

Important Safety Information

WARNING

See the Important Safety and Product Information guide in the product box for product warnings and other

important information.

Failure to install this device according to these instructions could result in personal injury, damage to the vessel

or device, or poor product performance.

CAUTION

To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,

cutting, or sanding.

NOTICE

When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.

• Drill

• Drill bit (size varies based on surface material and screws used)

• Mounting hardware applicable to surface.

You can use this bracket to install a Garmin BlueNet 30 gateway and a Garmin BlueNet 20 switch stacked one

above the other to more-efficiently use space on your boat. When selecting a location to install the bracket and

Garmin BlueNet devices, observe these considerations.

• You must mount the bracket and Garmin BlueNet devices in a location that meets the submersion and

ventilation requirements in the installation instructions provided with the Garmin BlueNet devices.

• You can install this bracket in various orientations on many surface angles.

September 2023

GUID-792F86B9-4D14-42E2-AF63-8B6CAFCF9B98 v1

Table of Contents

Do you have a question about the BlueNet and is the answer not in the manual?

Page 1 Mounting Considerations You can use this bracket to install a Garmin BlueNet 30 gateway and a Garmin BlueNet 20 switch stacked one above the other to more-efficiently use space on your boat. When selecting a location to install the bracket and Garmin BlueNet devices, observe these considerations.
Page 2 Securing the Bracket to the Mounting Surface You should secure the bracket to the mounting surface before you attach the devices to the mounting bracket. NOTE: M4 self-tapping pan head stainless steel screws are included to secure the bracket to the surface. If they are not long enough for your needs or if you would prefer a different type of stainless steel pan head mounting hardware for your mounting surface, you should supply the hardware.
Page 3 © 2023 Garmin Ltd. or its subsidiaries Garmin ® and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. Garmin BlueNet ™ is a trademark of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin.
