GIANT CRUSHER
6+
CONTENTS
1 Giant Crusher Truck
1 Remote Control
1 USB-C Cable
1 Sheet of Reusable Flag Decals
BATTERY INSTALLATION
Power Button
Forward/Backward
Joystick
1. The remote control requires 3 AAA 1.5V batteries (not included).
2. Use a tool to press and hold the battery release button on the back of the
remote control.
3. Slide down the battery cover.
4. Insert batteries as indicated in the diagram.
5. Slide the battery cover back into place securely.
Sharper Image® name and logo (including the 77 logo) are trademarks or
registered trademarks. Distributed by and © 2022 MerchSource, LLC. Irvine,
CA 92618. All rights reserved.
Model Number: 1015453
Power Indication LED
Left/Right Joystick
Battery Cover Release Button
REMOTE OPERATION
1. Push the left joystick forward to make the vehicle move forward or pull
back to make the vehicle reverse. The headlights will light up when the
vehicle is moving forward.
2. Push the right joystick left or right to turn the vehicle left or right.
3. Drive and climb over obstacles with the power of 4-wheel drive.
CHARGING THE BATTERY
OPEN
ON/OFF
Removable
Removable
Rechargeable
Rechargeable
Battery
Battery
CHARGING
PORT
The truck uses a replaceable rechargeable battery. If the battery no longer
stays charged, dispose of it properly according to local disposal
requirements.
CAUTION: If the rechargeable battery leaks fluid, dispose of the vehicle
immediately. Do not allow fluid to come in contact with skin or eyes.
1. Make sure the power switch located at the bottom of the truck is turned
to the o position. The battery pack must be installed in the truck.
2. Insert the USB-C charging cable into the port located at the bottom of the
truck.
IMPORTANT: Do not use excessive force when connecting the USB-C
cable. If there is resistance, check alignment and try again.
3. Connect the other end of the USB-C charging cable into your charging
source. The red light indicator turns on while the truck is charging and is
green when the truck is fully charged.
4. Note: The average charging time is approximately 2 hours (via 5.0V/2A
USB wall charger).
5. The LED indicator on the remote will begin to flash when the truck' s
battery needs to be recharged. The truck will run for up to 15 minutes on
a full charge.
1-800-374-2744
Printed in China
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sharper Image GIANT CRUSHER 1015453
Summary of Contents for Sharper Image GIANT CRUSHER 1015453
- Page 1 4. Insert batteries as indicated in the diagram. 5. Slide the battery cover back into place securely. Sharper Image® name and logo (including the 77 logo) are trademarks or registered trademarks. Distributed by and © 2022 MerchSource, LLC. Irvine, CA 92618. All rights reserved.
- Page 2 GIANT CRUSHER PAIRING MAINTENANCE The truck utilizes an automatic 2.4GHz digital channel selection system that If dirt or water gets inside the wheels/tires, you can remove the orange allows up to 10 individual players to race side by side in the same wireless tread to empty it out.
Need help?
Do you have a question about the GIANT CRUSHER 1015453 and is the answer not in the manual?
Questions and answers
My battery pack will not show green.
If the battery pack does not show green, allow the battery to cool to room temperature before charging. Charge it on a non-flammable surface away from flammable materials. If the battery becomes hot, swells, smokes, or gives off a strong odor, discontinue charging immediately.
This answer is automatically generated
My battery is green but I get no power
If your Sharper Image GIANT CRUSHER 1015453 is not powering on even though the battery indicator is green, consider the following possible reasons and solutions:
1. Battery Installation – Ensure the batteries are inserted correctly according to the polarity diagram.
2. Battery Type – Use only alkaline batteries as recommended. Avoid mixing old and new batteries or different types (alkaline, carbon-zinc, or rechargeable).
3. Battery Condition – Even if the indicator is green, the battery may not have enough power. Try replacing the batteries with fresh ones.
4. Power Switch – Confirm that the RC truck and remote control are both turned on.
5. Syncing Issue – If multiple players are using RC vehicles, ensure the syncing process is completed correctly.
6. Interference or Signal Issues – If there are connectivity problems, turn off all RCs and remote controls, then restart the syncing process.
7. Physical Damage – Inspect the truck and remote for any visible damage that could prevent operation.
If none of these steps resolve the issue, the device may need further troubleshooting or repair.
This answer is automatically generated
Need the replacement piece that holds the back wheel on. White piece - it is cracked.
What replacement battery pack and charging cord do i need for my son's RC GIANT CRUSHER sharper image 1015454 (960138A23201) lost them in our recent move!
My son has had this for his birthday but the steering does not work at all?!
