  • Page 1 VIDEO SETUP AIRFIX DRAW ALIGNER 02-09 / 40-44 AIRFIX DRAW ALIGNER G 10-16 / 40-44 17-24 / 40-44 25-31 / 40-44 32-39 / 40-44 73502 27/07/2023 Find more languages of user manuals www.gys.fr...

  • Page 2: General Instructions

    Slips, trips and falls are a major cause of serious injury and death. Beware of loose cables on the floor. Always use the tool at a safe distance from people and objects in or around the work area. The Airfix Draw Aligner is intended for use indoors in a well-lit environment, on a flat and smooth floor.

  • Page 3: Pulling Capacity

    AIRFIX DRAW ALIGNER instructions PULLING CAPACITY The Airfix Draw Aligner is designed to pull up to 350kg across its full height with a manual rope winch. The cord has a tensile strength limit of 1.5 T. UNPACKING AND UNLOADING The packaging contains the user and maintenance manual for the unit. On delivery, check for external transport da- mage.
  • Page 4 Operating manual Translation of the original AIRFIX DRAW ALIGNER instructions ASSEMBLY OF THE SEAL Fit the seal, starting at the mark on the plate. Pinch the gasket into place in the groove. Be careful not to stretch the seal. Check that the seal is correctly inserted in the groove.
  • Page 5 Operating manual Translation of the original AIRFIX DRAW ALIGNER instructions ASSEMBLY Screw M10x25: 8 Safety washer M10: 8 Screw the left and right brackets to the base of the co- lumn using an H8 spanner. Be careful to position the column with the notches on the right side, see image.

  • Page 6: Installation

    INSTALLATION: To ensure maximum adhesion to the floor, it is essential to position the Airfix Draw Aligner in a clean area (free of dust liquids or other contaminants) with no cracks or joints between the tiles to ensure maximum vacuum performance.

  • Page 7: Maintenance

    Always keep a minimum of 3 wraps around the winch spool. MAINTENANCE Dust removal can be done with a compressed air blow gun before cleaning. Clean the Airfix Draw Aligner with a suitable cleaning product for painted steel surfaces. Follow the product’s cleaning instructions. Wipe the Airfix Draw Aligner with a cloth after cleaning.

  • Page 8: Technical Specifications

    To dismantle the Airfix Draw Aligner, refer to the assembly section and reverse the order. This product must be disposed of in accordance with the current environmental and disposal guidelines of the country...
